Page 1: Air Conditioner
WINDOW AIR CONDITIONER INSTALLATION OPERATION CATALOG NO. PRODUCT CODE CATALOG NO. PRODUCT CODE WA18ZR 420-0068 WA24ZM 420-0072 WA24ZR 420-0071 950-0052-revB 1-10-07 Page 1 of 17... -
Page 2: Table Of Contents
TABLE OF CONTENTS AIR CONDITIONER SAFETY………………………………………………….….2 INSTALLATION REQUIREMENTS………………………………………………3 INSTALLATION INSTRUCTIONS………………………………………………..5 THRU-THE-WALL CABINET INSTALLATION…………………………………9 AIR CONDITIONER USE…………………………………………………………11 AIR CONDITIONER CARE……………………………………………………….13 TROUBLESHOOTING………………………………………………………….…14 SPECIFICATIONS…………………………………………………………………16 WARRANTY………………………………………………………………………...17 TECHNICAL SUPPORT IF YOU NEED TECHNICAL SUPPORT, PLEASE CALL (705) 504-8590 BETWEEN THE HOURS OF 8:00 A.M. and 5:00 P.M. -
Page 3: Installation Requirements
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow these basic precautions: • • Plug into a grounded 3 prong outlet. Do not use an extension cord. • • Do not remove ground prong. - Page 4 Recommended Grounding Method _____________________________________ WINDOW INSTALLATION This air conditioner must be grounded. This air _____________________________________ conditioner is equipped with a power supply Window Opening Measurements: cord having a grounded 3 prong plug. To • minimize possible shock hazard, the cord must 30”...
-
Page 5: Installation Instructions
To Test your power supply cord: • The power supply cord must be replaced if 1. Plug power supply cord into a grounded 3 it fails to trip when the test button is prong outlet. pressed or fails to reset. 2. - Page 6 ________________________________________________________________________________________ Window Installation (on some models) NOTES: • Handle air conditioner gently. • Be sure your air conditioner cabinet does not fall out of the opening during installation or removal. • The place where the power cord exits the air conditioner should be no more than 4 ft (122 cm) from a grounded 3 prong outlet.
- Page 7 Install Cabinet into Window Attach Side Curtains to Window Frame • 1. Pull Left-hand curtain out until it fits into window Handle air conditioner gently. • channel. Use a 3/32” drill bit to drill a starter hole Be sure your air conditioner cabinet does through the hole in the curtain housing and into the not fall out of the opening during lower window sash.
- Page 8 2. Insert air conditioner into cabinet. 2. Using #10 x 7/8” pan-head Phillips screws, attach bracket to cabinet. Repeat for other bracket. 3. Turn the adjustment bolt for each bracket until the bolt touches the wall. 4. Turn the locking nut on adjustment bolt to lock in positions.
-
Page 9: Thru-The-Wall Cabinet Installation
Through-the-Wall Cabinet Installation • NOTES: Use 1” (2.5cm) or thicker lumber for wood • Handle air conditioner gently. frame. • Be sure your air conditioner does not fall out of 4. Apply wood preservative to the outside the opening during installation or removal. •... - Page 10 3. Use a level to check that the unit is level side 6. Insert air conditioner into cabinet. to side. 4. Check that air conditioner cabinet is tilted to the outside so that water will run to the outside. 5. Reuse the insulation to seal opening between cabinet and frame.
-
Page 11: Air Conditioner Use
8. Timer/Delay pad – Used to select the amount of Model WA18ZR time before the air conditioner turns off (when on), or the amount of time before the air conditioner turns on (when off). - Page 12 Do not let any liquid in the remote controller or put the remote controller under direct sunlight or any place where it is very hot. • Replace two AAA batteries once a year, or as required. Model WA18ZR Model WA24ZR Page 12 of 17...
-
Page 13: Air Conditioner Care
____________________________________________________________________________________________ Manual Controls Features and appearance may vary. Model WA24ZM Controls For Quieter & Nighttime Cooling – Select Low Cool with the TEMPERATURE control at midpoint. The air conditioner controls are located behind the control panel doors. Press to open and close the TEMP Control door. -
Page 14: Troubleshooting
Repairing Paint Damage 3. Use a vacuum cleaner to clean air filter. If air filter is very dirty, wash it in warm water with a Check once or twice a year for paint damage. This is mild detergent. Do not wash air filter in the very important, especially in areas near oceans or dishwasher or use any chemical cleaners. - Page 15 __________________________________________ The louvers are blocked. Install the air conditioner Air conditioner seems to run too much in a location where the louvers are free from curtains, __________________________________________ blinds, furniture, etc. The current air conditioner replaced an older model. The use of more efficient components may The outside temperature is below 65ºF (18ºC).
-
Page 16: Specifications
TECHNICAL SPECIFICATIONS MODEL WA18ZR WA24ZR WA24ZM BTU Cooling 18,000 24,000 24,000 BTU Heating Dehumidification (Pints/Hour) Airflow (cfm) Voltage 208/230 VAC 208/230 VAC 208/230 VAC Amps Cooling 12.57 13.1/12.1 13.1/12.1 Amps Heating Watts Cooling 1810 / 1850 2710 / 2740 2710 / 2740... -
Page 17: Warranty
WARRANTY International Refrigeration Products warrants that the product supplied is free from defects in material and workmanship. This warranty is valid as long as this product is properly handled, installed, operated and serviced in accordance with the Installation and Operating Instructions shipped with this unit, and the warranty card is completed and mailed no later than 30 days after date of purchase.
