953-0002-revC
PTAC Air Conditioners w/electric heat
MODEL
PTAC09CH3ZX
PTAC12CH3ZX
PTAC12CH5ZX
PTAC15CH3ZX
PTAC15CH5ZX
PTAC Heat Pump models w/electric heat
MODEL
PTAC09CH3ZX
PTAC12CH3ZX
PTAC12CH5ZX
PTAC15CH3ZX
PTAC15CH5ZX
PTAC SERVICE MANUAL
HEAT/COOL BTU
9,600
12,000
12,000
15,000
15,000
HEAT/COOL BTU
9,000
12,000
12,000
15,000
15,000
PAGE 1
07/06/09
ELECTRIC HEAT (WATTS)
3,000
3,000
5,000
3,000
5,000
ELECTRIC HEAT (WATTS)
3,000
3,000
5,000
3,000
5,000
Advertisement
Related Manuals for Seabreeze PTAC09CH3ZX
Summary of Contents for Seabreeze PTAC09CH3ZX
- Page 1 953-0002-revC 07/06/09 PTAC SERVICE MANUAL PTAC Air Conditioners w/electric heat MODEL HEAT/COOL BTU ELECTRIC HEAT (WATTS) PTAC09CH3ZX 9,600 3,000 PTAC12CH3ZX 12,000 3,000 PTAC12CH5ZX 12,000 5,000 PTAC15CH3ZX 15,000 3,000 PTAC15CH5ZX 15,000 5,000 PTAC Heat Pump models w/electric heat MODEL HEAT/COOL BTU...
- Page 2 953-0002-revC 07/06/09 1. Function of the Control Board (PC board) 1.1 Cooling The indoor temperature is monitored by the room temperature sensor. The temperature is ● controlled by the cyclic switch of the compressor under which is controlled by the Control Board.
- Page 3 953-0002-revC 07/06/09 way valve will open when the compressor starts. In the defrost mode, the outside blower fan stops and the four-way valve will close. The ● compressor will stop for 2 minutes before restarting defrost process. In the heating mode, the Blower fan will run at the set speed while the electric heater is ●...
- Page 4 953-0002-revC 07/06/09 When Heat Pump and electric heat is working the system will operate as follows: (Tp= Indoor coil temperature, Tr=Room temperature, Ts=Temperature setpoint) 1. If Tp≥78 and Tp≥Tr+9ºF, Blower fan will start and run. ℉ 2. Tp≤64 or Tp T r+9ºF Blower fan will stop (to eliminate cold air draft) ℉...
- Page 5 953-0002-revC 07/06/09 Room temperature When in heat mode the Heat pump function operates exclusively to provide heat. If the demand for heat is greater than the Heat Pump can supply, the electric heat strips will activate to supplement the heat pump. The heat strips will only work between 73.4 and 78.8 ºF. If the setpoint is within this range, when the room temperature becomes satisfied, the Electric heat will shut off.
- Page 6 953-0002-revC 07/06/09 Unit is turned off or mode is changed during the defrost cycle. ③ 1.6 Fan Mode In the fan mode, the compressor and the condenser fan is off, and the indoor blower fan will operate at the set speed. 1.7 Automatic mode Automatic mode: ●...
- Page 7 953-0002-revC 07/06/09 In cool mode, if the unit displays “E4”, this indicates that the indoor coil is not less than the room temperature – 5.4ºF for over 5 minutes. Unit will enter protect mode and shut down. When unit is started in heat mode, if the compressor runs for more than 20 minutes and the coil temperature has not reached sufficient temperature, the Unit will enter protect mode, display “E4”, and shutdown.
- Page 8 953-0002-revC 07/06/09 2.0 Schematic diagrams. PTACC9CH3ZX PAGE 8...
- Page 9 953-0002-revC 07/06/09 PTAC09HP3ZX PAGE 9...
- Page 10 953-0002-revC 07/06/09 PTAC12CH3ZX PAGE 10...
- Page 11 953-0002-revC 07/06/09 PTAC12CH5ZX PAGE 11...
- Page 12 953-0002-revC 07/06/09 PTACHP3ZX PAGE 12...
- Page 13 953-0002-revC 07/06/09 PTAC15CH3ZX PAGE 13...
- Page 14 953-0002-revC 07/06/09 PTAC15CH5ZX PAGE 14...
- Page 15 953-0002-revC 07/06/09 PTAC15HZ3ZX IF YOU NEED TECHNICAL SUPPORT, PLEASE CALL 704-504-8590 BETWEEN THE HOURS OF 8:00 A.M. AND 5:00 P.M. PLEASE HAVE YOUR EQUIPMENT MODEL NUMBER ANDSERIAL NUMBER AVAILABLE WHEN YOU CALL. http://www.irproducts.biz PAGE 15...
