To:
1.
Date of 1
2.
Date of Revision (1
3.
Customer's Part Name:
4.
Customer's Part Number:
5.
AEenergy's Part Name: AE8867220PMHRE
6.
AEenergy's Part Number: AE260-08
7.
Customer's Approval
8.
Supplier
Advanced Electronics Energy Limited
Unit 7,12F,Chevalier Commercial Center,
No.8 Wang Hoi Road, Kowloon Bay,
Hong Kong
Specification Number: AE8867220PMHRE-FPS-Spec1 Version 1
Product Specifications
st
Issue: 2006-05-30
st
):
Page 1/ 13
Advertisement
Table of Contents
Summary of Contents for AEenergy AE8867220PMHRE
-
Page 1: Product Specifications
Customer’s Part Name: Customer’s Part Number: AEenergy’s Part Name: AE8867220PMHRE AEenergy’s Part Number: AE260-08 Customer’s Approval Supplier Advanced Electronics Energy Limited Unit 7,12F,Chevalier Commercial Center, No.8 Wang Hoi Road, Kowloon Bay, Hong Kong Specification Number: AE8867220PMHRE-FPS-Spec1 Version 1 Page 1/ 13... - Page 2 AEenergy Li Polymer Rechargeable Battery Product Specifications – AE8867220PMHRE Revision History Date Description Checked By Approved By 2006-05-30 First Issue Specification Number: AE8867220PMHRE -FPS-Spec1 Version 1 Page 2/13...
-
Page 3: Table Of Contents
AEenergy Li Polymer Rechargeable Battery Product Specifications – AE8867220PMHRE Contents Scope System Cell Model Cell Model Number Ratings Battery Performance Delivery Condition AEenergy Lithium Ion Polymer Battery Handling Guideline Remarks Appendix 1 Battery Drawing Specification Number: AE8867220PMHRE -FPS-Spec1 Version 1 Page 3/13... -
Page 4: Scope
AEenergy Li Polymer Rechargeable Battery Product Specifications– AE8867220PMHRE 1. Scope This specification shall be applied to Lithium ion polymer battery- model number AE8867220PMHRE manufactured by Advanced Electronics Energy Ltd. Hong Kong. 2. System: Rechargeable Lithium-ion Polymer Battery 3. Cell Model : AE8867220P 4. -
Page 5: Battery Performance
The cell shall be charged at a constant current of 4850mA(0.5C) to 4.2V and then at constant voltage of 4.2V with a charging time of 3.5 hours or 194mA(0.02C) cut off . Specification Number: AE8867220PMHRE -FPS-Spec1 Version 1 Page 5/13... - Page 6 1940mA (0.2C) and a cut-off voltage of 2.75V after standard charge (Section 6.3.1.). 6.3.9. Internal Impedance: 24mΩ max The internal impedance shall be measured at a since wave alternative current process of 1kHz after the standard charge. Specification Number: AE8867220PMHRE -FPS-Spec1 Version 1 Page 6/13...
-
Page 7: Delivery Condition
After standard charge (Section 6.3.1.), the battery is placed in an oven and is heated up at a rate of C until the temperature reaches 130 C. The oven shall be maintained at 130 C for 60 minutes. 7. Delivery Condition: about 50% charged. Specification Number: AE8867220PMHRE -FPS-Spec1 Version 1 Page 7/13... -
Page 8: Aeenergy Lithium Ion Polymer Battery Handling Guideline
8.7 Discharging Battery Discharge battery at the max current specified in this specification. If you plan to discharge battery at a higher current than the max current, please consult AEenergy. Avoid discharge the battery below 2.75V for each cell. Do not over-discharge the battery. Over-discharging can damage the performance of the battery. It should be noted that the cell/battery would be at an over-discharged state by its self-discharge characteristics in case the cell is not used for long time. - Page 9 No cell movement is allowed in the battery housing. The ultrasonic head shall not directly/ or indirectly pressed the cell if you need to enclose the battery housing by ultrasonic method. Please consult AEenergy for designing the ultrasonic head.Avoid designing airtight battery housing.
-
Page 10: Remarks
Do not put the battery into microwave, washing machine or drying machine. Do not use a damaged battery. 8.21 Others AEenergy shall make no liability for problems that occur when the above specifications are not followed. 9. Remarks If any matters with this specification arises, it shall be revised by mutual agreements. -
Page 11: Appendix 1 Battery Drawing
AEenergy Li Polymer Rechargeable Battery Appendix 1 Battery Drawing Specification Number: AE8867220PMHRE -FPS-Spec1 Version 1 Page 11/13...
