Page 1: Service Manual
SERVICE MANUAL CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KV-ES29M61 RM-916 THAILAND SCC-U33A-A KV-ES29N90 RM-958 TAIWAN SCC-P37A-A MUTING DISPLAY DRC-MF POWER VIDEO MODE JUMP ENTER TV/VIDEO FREEZE SWAP TWIN MENU PIP CH ZOOM ZOOM LEFT RIGHT...
Page 2 CARBON PAINTED ON THE CRT, AFTER REMOVING THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE ANODE. THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. – 2 –...
Page 3 CARBON PAINTED ON THE CRT, AFTER REMOVING THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE ANODE. THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. – 3 –...
Page 4: Table Of Contents
KV-ES29M61/ES29N90 RM-916 RM-958 TABLE OF CONTENTS Section Title Page Section Title Page SELF DIAGNOSIS FUNCTION 6. DIAGRAMS ........ 5 6-1. Block Diagram ............93 1. GENERAL ................ 9 6-2. Frame Schematic Diagram ........111 6-3. Circuit Boards Location ........114 2.
Page 5: Self Diagnosis Function
KV-ES29M61/ES29N90 RM-916 RM-958 SELF DIAGNOSTIC FUNCTION The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER lamp will automatically begin to flash. The number of times the lamp flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER lamp flash indicators is listed in the instruction manual for the user’s knowledge and reference.
Page 6: Rm-916 Rm
KV-ES29M61/ES29N90 RM-916 RM-958 DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT 2 times 3 times Lamp ON 0.3 sec. Lamp OFF 3 sec. Lamp OFF 0.3 sec. 4 times 5 times 6 times 7 times STANDBY/SLEEP lamp Diagnostic Item Flash Count* +B overcurrent...
Page 7 KV-ES29M61/ES29N90 RM-916 RM-958 SELF-DIAGNOSTIC SCREEN DISPLAY For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurances of failure for confirmation on the screen:...
Page 8 KV-ES29M61/ES29N90 RM-916 RM-958 SELF-DIAGNOSTIC CIRCUIT IC4301 IC001 IC003 RGB JUNGLE OVP OCP SYSTEM MEMORY FROM IKIN CRT (IK) [H] IC6801 XRAY [V] D6806/D6801 V PROT CXA2100Q IC004 MEMORY [+B overcurrent ªOCPº] Occurs when an overcurrent on the +B(135) line is detected by Q6610 and Q6609.
Page 9 AUDIO VIDEO DIGITAL IN (MONO) (DOLBY DIGITAL/PCM) VIDEO IN VIDEO OUT...
Page 10 (MONO) AUTO PROGR (MONO) AUTO PROGR AUTO PROGR DIGITAL IN (DOLBY DIGITAL/PCM) (MONO) PUSH PU SH …4 ≥ (MONO) AUTO PROGR...
Page 11 R-AUDIO-L VIDEO (MONO) LINE OUT DIGITAL IN (DOLBY DIGITAL/PCM) R-AUDIO-L VIDEO OPTICAL COAXIAL COMPONENT VIDEO OUT S VIDEO OUT LINE OUT DIGITAL OUT...
Page 12 DRC-MF MENU ENTER — — PROGR + JUMP SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER JUMP...
Page 13 MENU ENTER — — PROGR + DRC-MF JUMP SOUND MODE MODE SURROUND PROGR FAVORITE INDEX JUMP MENU PROGR SOUND MODE MODE SURROUND ENTER PROGR FAVORITE INDEX PRESET VTR 1 2 3 DVD MENU PROGR ENTER DRC-MF PRESET VTR 1 2 3 DVD VIDEO TITLE PROGR +...
Page 14 SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER PRESET VTR 1 2 3 DVD...
Page 15 DRC-MF JUMP SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR JUMP ENTER SOUND PRESET VTR 1 2 3 DVD MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER 1.PR 01 2.PR 03 3.PR 04 7.PR 12 6.PR 10 5.PR 08 4.PR 06...
Page 16 DRC-MF VIDEO TITLE PROGR + PROGR – SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER...
Page 17 JUMP SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER PRESET VTR 1 2 3 DVD...
Page 18 DRC-MF DRC-MF JUMP JUMP SOUND SOUND MODE MODE SURROUND MODE MODE SURROUND PROGR PROGR FAVORITE INDEX FAVORITE INDEX...
Page 19 DRC-MF VIDEO TITLE PROGR + PROGR – SOUND MODE MODE SURROUND PROGR FAVORITE DRC-MF INDEX MENU PROGR ENTER PRESET VTR 1 2 3 DVD JUMP SOUND MODE MODE SURROUND P166 SECTEXT FR1 MAR 03:59:09 From Singapore Dep/Arr Flight Alrcraft To PARIS 220/0588 SQ28 2130/1225...
Page 20 DRC-MF VIDEO TITLE PROGR + PROGR – SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER PRESET VTR 1 2 3 DVD...
Page 22 SOUND MODE MODE SURROUND A / V CONTROL PROGR DRC-MF: DRC1250 FAVORITE INDEX PICTURE MODE: DYNAMIC SOUND MODE: DYNAMIC SURROUND: OFF DIGITAL IN : OFF MENU PROGR ENTER MU L T I P I C T URE PRESET VTR 1 2 3 DVD P I P : OF F PIP POSITION...
Page 23 MENU PROGR ENTER...
Page 24 DRC-MF VIDEO TITLE PROGR + PROGR – SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER PRESET VTR 1 2 3 DVD...
Page 25 DRC-MF JUMP SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER PRESET VTR 1 2 3 DVD...
Page 26 JUMP SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER...
Page 27 JUMP...
Page 28 PROGR FAVORITE INDEX MENU PROGR ENTER PRESET VTR 1 2 3 DVD...
Page 32 DRC-MF MENU ENTER – – PROGR + JUMP SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR (MONO) AUTO PROGR ENTER PRESET VTR 1 2 3 DVD DRC-MF VIDEO TITLE PROGR + PROGR – SOUND MODE MODE SURROUND PROGR FAVORITE INDEX...
Page 33 DRC-MF JUMP SOUND MODE MODE SURROUND PROGR FAVORITE INDEX MENU PROGR ENTER PRESET VTR 1 2 3 DVD DRC-MF VIDEO TITLE PROGR + PROGR – SOUND MODE MODE SURROUND PROGR FAVORITE INDEX...
Page 41: Service Jig
KV-ES29M61/ES29N90 SECTION 3 RM-916 RM-958 SERVICE JIG 3-1. JIGS REQUIRED FOR SERVICING REF NO. DESCRIPTION PART NO. REMARK TOOL (20P), SERVICE 3-702-763-01 For A to V board extension TOOL (40P), SERVICE 3-702-764-01 For A to E board extension TOOL (50P-A), SERVICE...
Page 42: Set-Up Adjustments
KV-ES29M61/ES29N90 SECTION 4 RM-916 RM-958 SET-UP ADJUSTMENTS The following adjustments should be made when a complete Perform the adjustments in the following order : realignment is required or a new picture tube is installed. 1. Beam Landing These adjustments should be performed with rated power 2.
Page 43: Convergence Adjustment
KV-ES29M61/ES29N90 RM-916 RM-958 4-2. CONVERGENCE ADJUSTMENT V. STAT Preparation : Before starting this adjustment, adjust the focus, horizontal size and vertical size. Set the PICTURE 70% and BRIGHTNESS 0%. Cross hatch / Dot pattern. (1) Horizontal and Vertical Static Convergence H.
Page 44 KV-ES29M61/ES29N90 RM-916 RM-958 BMC (Hexapole) Magnet. (2) Dynamic Convergence Adjustment If the red, green and blue dots are not balanced or aligned, then Preparation: use the BMC magnet to adjust in the manner described below. Before starting this adjustment, adjust the horizontal static convergence and the vertical static convergence Set the PICTURE and BRIGHTNESS to normal.
Page 45: Focus Adjustment
KV-ES29M61/ES29N90 RM-916 RM-958 (3) Screen-corner Convergence 4-3. FOCUS ADJUSTMENT Note Focus adjustment should be completed before W/B adjustment. (1) Receive digital monoscope pattern. (2) Set "A/V CONTROL" to "STANDARD". a-d : screen-corner (3) Adjust FOCUS VR so that the center of the screen becomes misconvergence justfocus.
Page 46: G2 (Screen) And White Balance Adjustments
KV-ES29M61/ES29N90 RM-916 RM-958 3. SUB PICTURE BRIGHTNESS ADJUSTMENT 4-5. G2 (SCREEN) AND WHITE BALANCE 1) Tune RF PAL white signal at program No. 1 and No. 2. ADJUSTMENTS 2) Select “TWIN PICTURE” mode. 3) Receive different RF PAL white signals in MAIN and Sub 1.
Page 47: Circuit Adjustments
KV-ES29M61/ES29N90 SECTION 5 RM-916 RM-958 CIRCUIT ADJUSTMENTS 5-1. ADJUSTMENTS WITH COMMANDER Service adjustments are made with the RM-916 and RM-958 that comes with this unit. 1, 4 Select the adjustment item. a. ENTERING SERVICE MODE 3, 6 Raise/lower the data value.
Page 48: Adjustment Method
KV-ES29M61/ES29N90 RM-916 RM-958 5-2. ADJUSTMENT METHOD Item Number 00 of device GEO Use the same method for all Items. Use 1 and 4 to select the This explanation uses H-Position as an example. 1. Select “GEO 00 VSZ” with the 1 and 4 buttons.
Page 62 KV-ES29M61/ES29N90 RM-916 RM-958 Abbreviation: Eco Mode V-Compressed Mode Non-Compressed Mode Surround VDD = Virtual Dolby Digital Virtual Dolby Prologic Tru Surround Simulated NOTE • shaded items are fixed data. • no data • Standard data listed on the Adjustment Item Table are reference values, therefore it may be different for each model and for each mode.
Page 63: Picture Quality Adjustments
KV-ES29M61/ES29N90 RM-916 RM-958 5-3. PICTURE QUALITY ADJUSTMENTS 1. NTSC VIDEO INPUT -H-TRAPIZIUM ADJUSTMENT Input signal ; NTSC color bar, 75% to Video 1. [TWIN] mode, [Service] mode. 1. Input a cross hatch/dot signal. 2. Adjust DAC 4 HTR to make H-Trapizoid distortion best.
Page 64 KV-ES29M61/ES29N90 RM-916 RM-958 2. NTSC RF INPUT 3. PAL RF INPUT Input signal ; NTSC RF color bar, 75%. Input signal ; PAL RF color bar, 75%. [TWIN] mode, [Service] mode. [TWIN] mode, [Service] mode. (i) SUB CONTRAST (i) SUB CONTRAST...
Page 65: Deflection Adjustment
KV-ES29M61/ES29N90 RM-916 RM-958 FOR DRC 100 MODE 5-4. DEFLECTION ADJUSTMENTS 12. Set to DRC 100 mode. 13. Repeat Step 5, Step 6 and Step 7. FOR DRC 1250 14. Write “DAC 00 HCT DRC 100 Mode” as “DAC 00 HCT DRC 1.
Page 66: A Board Adjustment After Ic003 (Memory) Replacement
KV-ES29M61/ES29N90 RM-916 RM-958 5-5. A BOARD ADJUSTMENT AFTER IC003 (MEMORY) REPLACEMENT When replacing IC003 and IC004 (MEMORY), be sure to change IC001 (µ-COM) to the following at the same time. MODEL IC001 (µ-CON) KV-ES29M61 CXP750096-013Q KV-ES29N90 CXP750096-018Q 1. Enter to Service Mode.
Page 67: Picture Distortion Adjustment
KV-ES29M61/ES29N90 RM-916 RM-958 5-6. PICTURE DISTORTION ADJUSTMENT (1) PICTURE DISTORTION ADJUSTMENT (2) Item Number 00 – 0B H-TRAPEZOID (DAC 4 HTR) GEO 0 VSZ (V SIZE) GEO 1 VPS (V POSITION) GEO 2 VLN (V LINEARITY) GEO 3 SCO (VERTICAL S-Correction)
Page 68 KV-ES29M61/ES29N90 RM-916 RM-958 MEMO – 92 –...
Page 69: Diagrams
KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 SECTION 6 RM916 RM-958 RM916 RM-958 RM916 RM-958 RM916 RM-958 DIAGRAMS 6-1. BLOCK DIAGRAM T6602 MAIN (CRT DRIVE) CONVERTER CN6800 VPROT V PROT Q6811, Q6819 Q6820, Q6821 +17V AUDIO D6801 17V RECT –17V AUDIO D6634 PUMP UP VSAW–...
Page 70 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 RM916 RM-958 RM916 RM-958 RM916 RM-958 RM916 RM-958 TO H2 BOARD TO H1/H3 BOARD TO J BOARD CN4101 CN4500 CN1934 CN1901/CN1980 CN8304 CN1195 CN1190 CN1180 EXTRA PARABOLA EXTRA-PARA R_OUT R OUT H DEFL HS_IN G_OUT G OUT...
Page 71 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 RM916 RM-958 RM916 RM-958 RM916 RM-958 RM916 RM-958 TO VM BOARD (TOP KEY) CN1980 S1972 STBY TO A BOARD CN1190 (LED, SIRCS RECEIVER) KEY 1 OUT S1973 CN6101 PRG+ CN1901 IC1901 S1974 REMOTE SENSOR IC6104 PGRM-...
Page 72 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 RM916 RM-958 RM916 RM-958 RM916 RM-958 RM916 RM-958 (YCT, COMB FILTER, CN8304 Y MAIN OUT IC8306 VIDEO/AUDIO-IN/OUT) U MAIN OUT MAIN COLOR DECODER V MAIN OUT V PULSE MAIN OUT IC8308 H PULSE MAIN OUT IC8312...
Page 75: Circuit Boards Location
6-2. FRAME SCHEMETIC DIAGRAMS TO SBX3005-11 CN2001 COMP V IN J8307 J8305 J8304 J8303 J8302 Y OUT J8301 C OUT KB KG A GND CN8100 RESET R-SW R IN Y IN L-SW DIGITAL AUDIO CN8302 CN8303 MN/NT DSP ALIVE H.DY H.DY V.DY V.DY...
Page 76 A BOARD IC2604 PQ5EV3 CIRCUIT DC IN (V IN) DC OUT (Vo) CONTROL CIRCUIT V OUT ADJUSTMENT PIN ON/OFF CONTROL (Vc) A BOARD MARK LIST KV-ES29M61 KV-ES29N90 C101 C3302 C3337 0.04725: CHIP CN1118 – A Board (Conductor Side) – D100 MA111-(K8)
Page 77: Schematic Diagram Of A Board
(1) Schematic Diagram of A Board TO SPEAKER CN1190 CN1138 CN1195 CN1193 :S-MICRO :S-MICRO :S-MICRO TO MAGNETIC COIL TO H1(CN1901)/ TO H2 BOARD CN1934 TO H3(CN1980) TO H2 BOARD CN1932 D012 C1222 C1224 6.3V 6.3V CN1161 PROTECTOR B:CHIP B:CHIP DIP PIN IC2600 D007 C1223...
Page 78: Schematic Diagram Of D Board
(2) Schematic Diagram of D Board C6672 C6673 2200p 2200p R6660 TH6603 :FPRD C6649 JW6601 C6647 C6635 7.5MM 100p C6630 L6601 450V C6634 C6601 C6648 JW6602 7.5MM C6637 R6677 R6699 R6639 C6622 R6642 R6645 C6617 C6629 C6625 R6675 1200 470k R6657 0.0047 250V...
Page 79 D6605 D6645 IC6602 I-13 Q6810 D6621 G-11 D6812 IC6603 F-8 IC6603 G-5 D6609 D6648 Q6811 D6622 F-13 D6813 KV-ES29M61 KV-ES29N90 IC6604 E-1 D6612 IC6604 F-13 D6650 Q6812 D6624 G-10 D6814 C6602 0.033 630 0.022 400 IC6605 D-1 D6613 IC6605 D-13...
Page 80: Schematic Diagram D1 Board
(3) Schematic Diagram of D Board CN6104 CN6103 CN6102 WHITE :S-MICRO :S-MICRO TO VM BOARD TO RT COIL TO DY 135V C6352 6.5V IC6108 R6165 R6135 R6166 D6105 MB88141APF-ER RD2.7ESB2 DAC CONT :CHIP DC SHIFT R6163 R6164 M-PIN DF SW VSS1 DF PH VDD1...
Page 81 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 RM916 RM-958 RM916 RM-958 PRINTED WIRING BOARD [DF, DQP DRIVE] – D1 Board – D1 BOARD WAVEFORMS 80Vp-p (H) 0.5Vp-p 294Vp-p 8.8Vp-p 74Vp-p 6.6Vp-p 280Vp-p 8.5Vp-p – – – –...
Page 82 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 RM916 RM-958 RM916 RM-958 PRINTED WIRING BOARDS [CRT DRIVE] [VM DRIVE] [AC LINE FILTER] – C Board – – VM Board – – F1 Board – – – – –...
Page 83 :RN-CP :CHIP B DRV C9022 0.01 SECAM/NTSC C9018 F1 BOARD MARK LIST C9005 R9001 C9015 R9035 2.7k 2.2k 250V Q9010 KV-ES29M61 KV-ES29N90 Q9011 :CHIP CH:CHIP R9020 CH:CHIP :RN-CP 2SA1037AK-T146-R VDR161 ERZV14D621 TNR14V271K660 2SA1037AK-T146-R IC9002 CN9003 G DRIVE :CHIP B DRIVE TDA6111Q/N4 Note) The parts indicated as “#”...
Page 84: Schematic Diagram Of E Board
(5) Schematic Diagram of E Board L4312 :CHIP +12V +12V 9V/12V C4335 L4310 C4337 +12V +12V +12V D4311 CN4502 DAN202K R4313 C4316 R4338 L4301 4.7k :CHIP :S-MICRO C4339 C4333 L4302 :CHIP :CHIP D4313 L4305 CH:CHIP MA3062M-TX TO VM BOARD :CHIP C4334 :CHIP R4343...
Page 85 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 RM916 RM-958 RM916 RM-958 RM916 RM-958 PRINTED WIRING BOARDS [RGB OUT, DEFLECTION] E Board IC4301 CXA2100AQ – E Board (Component Side) – – E Board (Conductor Side) – 46 45 41 40 39 36 35 34 33 •...
Page 86 (6) Schematic Diagrams of H Boards TO A BOARD CN1932 CN1195 TO A BOARD CN1934 & CN1193 :S-MICRO TO J BOARD :S-MICRO CN1901 TO A BOARD CN8301 CN1190 :S-MICRO D1942 R1911 R1913 R1914 R1915 R1916 C1910 Q1901 Q1902 PROTECTOR D1930 R1917 DTC144ESA DTC144ESA...
Page 87 KV-ES29M61/ES29N90 RM916 RM-958 PRINTED WIRING BOARDS [LED, SIRCS RECEIVER] [AV INPUT, PRESET KEY, PHONE OUT] [TOP KEY] – H1 Board – – H2 Board – – H3 Board – – 153 –...
Page 88 KV-ES29M61/ES29N90 RM916 RM-958 B3 BOARD IC309, IC505 and IC506 TC7SET04F (TE85R) NC 1 IN A 2 GND 3 OUT V B3 BOARD WAVEFORMS 1.7Vp-p (H) 1.0Vp-p (H) 1.1Vp-p (H) 4.7Vp-p (V) 4.9Vp-p (V) 2.3Vp-p (V) 2.2Vp-p (V) 2.8Vp-p (V) 3.1Vp-p (V) 0.6Vp-p (H)
Page 89: Schematic Diagram Of B3 (1/6) Board
(7) Schematic Diagram of B (1/6) Board V PULSE H PULSE IC506 A5V-1 TC7SET04F(TE85R) LEVEL SHIFT Q520 -0.1 DTC144EKA-T146 R998 L511 INVERTER R557 XRST5 :CHIP WSYNC R527 :CHIP HP 100 OUT :CHIP MID BUSY YMCK MID BUSY D3.3V -0.0 L503 FL504 R598 CKD510JB1A105ST...
Page 90 (8) Schematic Diagram of B (2/6) Board PRINTED WIRING BOARDS [DRC, MID, SUB MICON, DRC/MID CONTROLLER] IVDD R687 Q601 3.3VGR IVDD ADTB 2SC1623-L5L6 IHDD :CHIP BUFFER – B3 Board (Component Side) – IHDD Q602 C639 L604 C638 2SC1623-L5L6 0.01 W13ID 0.01 W13ID C601...
Page 91: Schematic Diagram Of B3 (3/6) Board
(9) Schematic Diagram of B (3/6) Board C717 C718 FL704 A3.3V C719 C716 R710 XRST C726 C725 C724 C723 C722 C738 SDA6 SDA5 VOUT35 SDA4 VOUT34 VOUT33 C715 SDD18 VOUT32 SDD19 SDD110 VOUT31 SDD111 VOUT30 C727 VOUT29 SDD112 VOUT28 SDD113 SDD114 VOUT27 IC704...
Page 92 (10) Schematic Diagram of B (4/6) Board C823 R817 0.01 B:CHIP :RN-CP C824 C822 C821 0.01 0.01 0.01 B:CHIP B:CHIP B:CHIP R939 :CHIP VDOCIN7 SDADR3 SDDAT16 VDOCIN6 VDOCIN5 SDDAT17 VDOCIN4 SDDAT18 SDDAT19 VDOCIN3 C820 C825 0.01 B:CHIP AVCCPLL 0.01 B:CHIP AVSSPLL VDD2 C826...
Page 93 (11) Schematic Diagram of B (5/6) Board B3 BOARD IC901 CXD2309Q (LSB) R0 4LSB'S CURRENT CELLS 6LSB'S LATCHES DECODER CURRENT CELLS DECODER CLOCK (MSB) R9 GENERATOR (LSB) G0 4LSB'S CURRENT CELLS 6LSB'S LATCHES DECODER CURRENT CELLS DECODER CLOCK (MSB) G9 GENERATOR (LSB) B0 4LSB'S...
Page 94 (12) Schematic Diagrams of B (6/6) and F Boards CN1652 CN1651 TO F1 BOARD TO D BOARD CN6604 CN1602 B3 BOARD IC302 CXD2303AQ 35 41 42 62 68 22 23 11 12 71 ARTS IOGND DSYNC IOVCC A-CH A0 (LSB) PLLVCC CLKN 8-BIT...
Page 95 KV-ES29M61/ES29N90 RM916 RM-958 (13) Schematic Diagram of DH Board PRINTED WIRING BOARDS [AC SWITCH] [MAGNETIC FIELD CORRECTION] IC3807 C3801 – F2 Board – X OUT IC3805 R3846 Q3811 C3805 R3805 R3847 R3807 D3809 Q3810 R3848 R3828 R3804 R3856 R3853 R3857...
Page 96 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 RM916 RM-958 RM916 RM-958 RM916 RM-958 PRINTED WIRING BOARDS [AUDIO DSP] – A1 Board (Component Side) – – A1 Board (Conductor Side) – A1 Board IC8103 AK4524 AINL DGND DATT AINR LRCK Audio I/F BICK Controller SDTO...
Page 97: Schematic Diagram Of A1 Board
(14) Schematic Diagram of A1 Board IC8104 S-80827ANUP-EDQ- FL8100 C8147 +5.0V-AU RESET FB8109 FB8110 C8168 :CHIP X8102 C8108 C8117 :CHIP 18.432MHz B:CHIP :CHIP C8112 C8129 B:CHIP 220p C8116 0.01 R8133 B:CHIP B:CHIP B:CHIP R8206 2200p 2.2M C8134 C8135 B:CHIP :CHIP :CHIP C8142 B:CHIP...
Page 98: Schematic Diagrams Of Bc4 And V Boards
(15) Schematic Diagrams of BC4 and V Boards R1835 R1838 Q1804 :CHIP R1813 2SA1037 :CHIP C2095 R2113 R1814 R BUFFER CH:CHIP :CHIP :RN-CP R1819 C1818 :CHIP R1839 R1836 :CHIP :CHIP :CHIP (Y/C SEP) IC1801 :CHIP SDA5254-2 R1841 R1818 R2119 4.7k TELEDECODER C1817 :CHIP...
Page 99 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 RM916 RM-958 RM916 RM-958 RM916 RM-958 PRINTED WIRING BOARDS [Y/C SEP] [TELE TEXT] (KV-ES29M61 ONLY) – BC4 Board – – V Board – V Board IC1801 SDA5254-2B006 Capture Compare Timer Display Timing Display VTX, VPS Watchdog Acquisition...
Page 100 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 KV-ES29M61/ES29N90 RM916 RM-958 RM916 RM-958 RM916 RM-958 J Board IC8302 CXA2069Q J Board IC8306 CXA2123AQ-T6 VOUT1 J BOARD WAVEFORMS YIN1 YOUT1 TRAP1 COUT1 1.3Vp-p (H) 2.6Vp-p (H) 1.6Vp-p (H) 1.7Vp-p (H) 1.4Vp-p CIN1 CVBS1/Y1-IN X'TAL V/YOUT2 SYNC-IN BPH-FIL 1.4Vp-p (H)
Page 101: Schematic Diagram Of J Board
(16) Schematic Diagram of J Board PRINTED WIRING BOARDS [YCT, COMB FILTER, VIDEO/AUDIO-IN/OUT] – J Board (Component Side) – R8362 R8592 R8353 :CHIP C8348 R8512 R8354 :CHIP C8465 C8468 FL8313 C8464 B:CHIP B:CHIP C8334 FL8309 R8557 R8588 R8595 :CHIP :CHIP R8505 R8511 R8589...
Page 102: Semiconductors
6-5. SEMICONDUCTORS DIODE TRANSISTOR D1NS4 D1NL20U-TR DTZ-TT11-2.4B DTA144EKA-T146 2SK2036(TE85L) AK4524 TA7805S CA0005AD D10SC4M UPC1093J-1-T PQ5EV3 2SC5480-01 SDA5254-2B006 ERA38-06 S3L20UF4 DTC114EK 2SK2251-01-F19 LF50CDT-TR CA0007AD D10SBS4F CATHODE ERA85-009 2SA1037AK-T146-R MM1115XFBE NJM3404AD MARKING SIDE VIEW RD10ESB2 2SA1162-G NJM4560M TOP209P RD12ES-B1 2SC1623-L5L6 TC7WU04F UPC393C RD13ES-B2 2SC2712-YG TDA7315D013TR...
Page 103: Exploded Views
SCREW, TP+TWH 4X25 1-529-532-11 SPEAKER (5CM) 1-505-473-11 SPEAKER (12CM) * 4-071-302-01 DUCT, SPEAKER X-4036-878-2 COVER ASSY, REAR * 4-073-084-01 DUCT, CUSHION (KV-ES29N90) * 4-073-084-31 DUCT, CUSHION (KV-ES29M61) * 4-074-512-01 CUSHION (S), DGC (KV-ES29N90) * 4-074-512-31 CUSHION (S), DGC (KV-ES29M61) – 211 –...
Page 104: Chassis
* A-1346-919-A D BOARD COMPLETE (KV-ES29M61) * A-1299-092-A A1 BOARD COMPLETE(KV-ES29N90) * A-1299-172-A A1 BOARD COMPLETE (KV-ES29M61) ! 1-453-325-11 TRANSFORMER ASSY, FLYBACK (NX-4522//J1I4) * A-1342-535-A V BOARD MOUNTED (KV-ES29M61 ONLY) 1-792-458-11 CABLE, RF (KV-ES29N90) * 4-071-314-01 BRACKET, MAIN 1-790-082-11 CABLE, RF (KV-ES29M61)
Page 105: Picture Tube
REF. NO. PART NO. DESCRIPTION REMARK 4-071-308-01 DOOR, CONTROL * X-4037-516-1 HOLDER ASSY, CONTROL (KV-ES29N90) * A-1372-730-A H3 BOARD MOUNTED (KV-ES29N90) * X-4037-280-1 HOLDER ASSY, CONTROL (KV-ES29M61) * A-1372-786-A H3 BOARD MOUNTED (KV-ES29M61) 4-071-323-01 SPRING, CONE 4-071-312-02 BUTTON, TOP SW * 4-071-298-02...
Page 106: Electrical Parts List
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1299-155-A A BOARD COMPLETE (KV-ES29N90) C1202 1-107-725-11 CERAMIC CHIP 0.1MF * A-1299-173-A A BOARD COMPLETE (KV-ES29M61) C1203 1-164-505-11 CERAMIC CHIP 2.2MF **************** C1204 1-164-690-91 CERAMIC CHIP 0.0022MF * 1-555-110-00...
Page 107 C2600 1-164-004-11 CERAMIC CHIP 0.1MF D013 8-719-158-18 DIODE RD5.6SB3 D014 8-719-073-01 DIODE MA111-(K8).S0 C2601 1-164-004-11 CERAMIC CHIP 0.1MF D100 8-719-073-01 DIODE MA111-(K8).S0 (KV-ES29M61 ONLY) C2602 1-126-933-11 ELECT 100MF C2603 1-126-933-11 ELECT 100MF D300 8-719-073-01 DIODE MA111-(K8).S0 C2605 1-126-925-11 ELECT 470MF...
Page 108 IC003 8-759-527-76 IC M24C08-MN6T IC004 8-759-527-75 IC M24C04-MN6T Q001 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R Q002 8-729-230-49 TRANSISTOR 2SC2712-YG IC100 8-759-042-02 IC S-80743AL-A7-S (KV-ES29M61 ONLY) Q003 8-729-230-49 TRANSISTOR 2SC2712-YG IC1201 8-759-273-12 IC TDA7315D013TR Q004 8-729-230-49 TRANSISTOR 2SC2712-YG IC1203 8-759-553-45 IC TDA7481 Q005 8-729-026-49...
Page 109 RES,CHIP 4.7K 1/10W (KV-ES29N90 ONLY) R045 1-216-065-91 RES,CHIP 4.7K 1/10W R101 1-216-025-91 RES,CHIP 1/10W R046 1-216-033-00 RES,CHIP 1/10W (KV-ES29M61 ONLY) R047 1-216-033-00 RES,CHIP 1/10W R102 1-216-025-91 RES,CHIP 1/10W R048 1-216-073-00 RES,CHIP 1/10W (KV-ES29M61 ONLY) R049 1-216-689-11 METAL CHIP 0.50% 1/10W...
Page 110 R1259 1-216-073-00 RES,CHIP 1/10W TU101 8-598-477-10 TUNER, FSS BTF-WG411 (KV-ES29N90) R1260 1-216-029-00 RES,CHIP 1/10W TU101 8-598-452-20 TUNER, FSS BTF-WG442 (KV-ES29M61) TU3301 8-598-476-00 TUNER, FSS BTF-FG401 (KV-ES29N90) R1261 1-216-029-00 RES,CHIP 1/10W TU3301 8-598-508-10 TUNER, FSS BTF-LG436 (KV-ES29M61) R1264 1-216-041-00 RES,CHIP 1/10W...
Page 111 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C8126 1-163-021-91 CERAMIC CHIP 0.01UF 10.00%50V FB8102 1-216-295-91...
Page 112 REMARK REF. NO. PART NO. DESCRIPTION REMARK R8120 1-216-049-91 RES-CHIP 1/10W * A-1136-054-A B3 BOARD COMPLETE (KV-ES29N90) R8121 1-216-025-91 RES-CHIP 1/10W * A-1136-086-A B3 BOARD COMPLETE (KV-ES29M61) R8122 1-216-025-91 RES-CHIP 1/10W ********************* R8123 1-216-009-91 RES-CHIP 1/10W R8124 1-216-009-91 RES-CHIP 1/10W <CAPACITOR>...
Page 113 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C519 1-163-038-91 CERAMIC CHIP 0.1MF C624 1-163-021-91 CERAMIC CHIP 0.01MF...
Page 114 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C848 1-163-017-00 CERAMIC CHIP 0.0047MF FL511 1-234-177-21...
Page 115 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK L511 1-412-026-11 INDUCTOR CHIP 1UH R336 1-216-013-00...
Page 116 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R574 1-216-651-11 METAL CHIP 0.50% 1/10W R658...
Page 117 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R834 1-216-629-11 METAL CHIP 0.50% 1/10W R898...
Page 118 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R991 1-216-295-91 SHORT <CRYSTAL> R993 1-216-089-91 RES,CHIP...
Page 119 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C2062 1-104-664-11 ELECT 47MF L2005 1-412-058-11 INDUCTOR CHIP 10UH...
Page 120 REF. NO. PART NO. DESCRIPTION REMARK R2055 1-216-017-91 RES,CHIP 1/10W * A-1332-005-A C BOARD MOUNTED (KV-ES29N90) R2056 1-216-067-00 RES,CHIP 5.6K 1/10W * A-1332-034-A C BOARD MOUNTED (KV-ES29M61) R2057 1-216-049-91 RES,CHIP 1/10W ******************** R2058 1-216-057-00 RES,CHIP 2.2K 1/10W R2059 1-216-049-91 RES,CHIP...
Page 121 NL9001 1-519-526-11 LAMP, NEON <TRANSISTOR> *************************************************************** Q9001 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R * A-1346-914-A D BOARD COMPLETE (KV-ES29N90) Q9009 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R * A-1346-919-A D BOARD COMPLETE (KV-ES29M61) Q9010 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R ******************** Q9011 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R * 4-363-146-00 HEAT SINK, V.OUT 4-382-854-11 SCREW (M3X10), P, SW (+) <RESISTOR>...
Page 122 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C6617 1-161-830-00 CERAMIC 0.0047MF 500V C6806 1-107-933-11...
Page 123 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C6872 1-163-275-11 CERAMIC CHIP 0.001MF D6616 8-719-911-55...
Page 124 TRANSISTOR DTC144EKA-T146 L6808 1-406-674-11 INDUCTOR 3.3MMH Q6820 8-729-422-33 TRANSISTOR 2SD601A-Q-TX Q6821 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R Q6823 8-729-422-33 TRANSISTOR 2SD601A-Q-TX <NEON LAMP> NL6601 1-576-429-11 GAP, SPARK (KV-ES29M61) <RESISTOR> R6500 1-220-797-11 CEMENTED 0.47 <PHOTO COUPLER> R6600 1-216-295-91 SHORT R6602 1-249-417-11 CARBON 1/4W R6603 1-208-806-11 METAL CHIP 0.50% 1/10W...
Page 125 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R6667 1-249-413-11 CARBON 1/4W R6610 1-208-830-11 METAL CHIP 100K 0.50% 1/10W...
Page 126 R6865 1-216-103-00 RES,CHIP 180K 1/10W R6866 1-215-433-00 METAL 3.3K 1/4W <THERMISTOR> R6867 1-216-065-91 RES,CHIP 4.7K 1/10W TH6601!1-803-540-11 THERMISTOR, POSITIVE (KV-ES29M61) R6868 1-216-065-91 RES,CHIP 4.7K 1/10W TH6601!1-803-629-11 THERMISTOR, POSITIVE (KV-ES29N90) R6869 1-216-115-00 RES,CHIP 560K 1/10W TH6603 1-803-586-11 THERMISTOR, NTC R6870 1-216-057-00 RES,CHIP 2.2K...
Page 127 Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1343-791-A DH BOARD MOUNTED (KV-ES29N90) C6138 1-126-968-11 ELECT 100MF * A-1343-821-A DH BOARD MOUNTED (KV-ES29M61) C6139 1-107-902-11 ELECT ********************* C6140 1-126-960-11 ELECT C6201 1-126-967-11 ELECT 47MF <CONNECTOR>...
Page 128 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK D6210 8-719-109-88 DIODE RD5.6ESB1 Q6108 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R...
Page 129 3.3K 0.50% 1/10W *************************************************************** R6208 1-208-806-11 METAL CHIP 0.50% 1/10W * A-1343-743-D E BOARD MOUNTED (KV-ES29N90) R6209 1-216-099-00 RES,CHIP 120K 1/10W * A-1343-820-A E BOARD MOUNTED (KV-ES29M61) R6210 1-216-057-00 RES,CHIP 2.2K 1/10W ******************* R6211 1-216-073-00 RES,CHIP 1/10W R6212 1-216-057-00 RES,CHIP 2.2K...
Page 130 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C4327 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V C4817...
Page 131 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CHIP CONDUCTOR> JR4301 1-216-295-91 SHORT <RESISTOR> <COIL>...
Page 132 KV-ES29M61/ES29N90 RM916 RM-958 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R4361 1-216-133-00 RES-CHIP 3.3M 1/10W R4823 1-216-057-00 RES-CHIP 2.2K...
Page 133 METAL CHIP 0.5% 1/10W ************************************************************** R4912 1-208-806-11 METAL CHIP 0.5% 1/10W * A-1241-403-A F2 BOARD MOUNTED (KV-ES29N90) R4913 1-208-806-11 METAL CHIP 0.5% 1/10W * A-1241-416-A F2 BOARD MOUNTED (KV-ES29M61) R4914 1-216-057-00 RES-CHIP 2.2K 1/10W ******************** <CRYSTAL> <CONNECTOR> X4300 1-767-127-11 VIBRATOR, CERAMIC...
Page 134 REMARK REF. NO. PART NO. DESCRIPTION REMARK R1914 1-249-411-11 CARBON 1/4W * A-1372-730-A H3 BOARD MOUNTED (KV-ES29N90) R1915 1-249-429-11 CARBON 1/4W * A-1372-786-A H3 BOARD MOUNTED (KV-ES29M61) R1916 1-249-401-11 CARBON 1/4W ******************** R1917 1-247-807-31 CARBON 1/4W R1920 1-247-807-31 CARBON 1/4W <CONNECTOR>...
Page 135 0.47MF C8331 1-164-346-11 CERAMIC CHIP C8399 1-126-961-11 ELECT 2.2MF C8332 1-163-249-11 CERAMIC CHIP 82PF C8401 1-163-021-91 CERAMIC CHIP 0.01MF (KV-ES29M61 ONLY) C8402 1-164-346-11 CERAMIC CHIP C8333 1-115-340-11 CERAMIC CHIP 0.22MF C8334 1-104-664-11 ELECT 47MF C8403 1-163-037-11 CERAMIC CHIP 0.022MF C8406...
Page 136 IC8311 8-759-485-79 IC TC7SET08FU(TE85L) IC8312 8-759-485-79 IC TC7SET08FU(TE85L) D8101 8-719-073-01 DIODE MA111-(K8).S0 D8102 1-216-295-91 SHORT IC8314 8-742-175-00 HYB IC SBX3005-11 (KV-ES29M61 ONLY) D8301 8-719-158-35 DIODE RD9.1SB D8302 8-719-158-35 DIODE RD9.1SB D8303 8-719-158-35 DIODE RD9.1SB <JACK> D8304 8-719-158-35 DIODE RD9.1SB J8106...
Page 137 R8324 1-216-295-91 SHORT R8325 1-216-295-91 SHORT Q8337 8-729-230-49 TRANSISTOR 2SC2712-YG R8326 1-216-113-00 RES,CHIP 470K 1/10W Q8342 8-729-230-49 TRANSISTOR 2SC2712-YG (KV-ES29M61 ONLY) R8327 1-216-295-91 SHORT Q8343 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (KV-ES29M61 ONLY) R8328 1-216-113-00 RES,CHIP 470K 1/10W Q8344 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R R8329...
Page 138 RES,CHIP 1/10W R8389 1-216-033-00 RES,CHIP 1/10W R8449 1-216-025-91 RES,CHIP 1/10W R8390 1-208-773-11 METAL CHIP 0.50% 1/10W R8450 1-216-089-91 RES,CHIP 1/10W (KV-ES29M61 ONLY) R8451 1-216-097-91 RES,CHIP 100K 1/10W R8391 1-216-041-00 RES,CHIP 1/10W R8452 1-216-089-91 RES,CHIP 1/10W (KV-ES29M61 ONLY) R8453 1-216-097-91 RES,CHIP...
Page 139 R8524 1-216-041-00 RES,CHIP 1/10W R8525 1-216-033-00 RES,CHIP 1/10W *************************************************************** R8528 1-216-025-91 RES,CHIP 1/10W R8530 1-216-041-00 RES,CHIP 1/10W * A-1342-535-A V BOARD MOUNTED (KV-ES29M61 ONLY) ******************* R8532 1-216-041-00 RES,CHIP 1/10W R8533 1-216-041-00 RES,CHIP 1/10W R8536 1-216-025-91 RES,CHIP 1/10W <CAPACITOR> R8538 1-216-041-00...
Page 140 IC1801 8-759-652-13 IC SDA5254-2B006 ************************************************************** IC1802 8-759-239-14 IC TA78L05S IC1803 8-759-042-02 IC S-80743AL-A7-S * A-1342-515-A VM BOARD MOUNTED (KV-ES29N90) * A-1342-536-A VM BOARD MOUNTED (KV-ES29M61) ********************* <COIL> 4-382-854-11 SCREW (M3X10), P, SW (+) L1801 1-408-602-31 INDUCTOR 8.2UH <CAPACITOR> <TRANSISTOR> C5401...
Page 141 PARTITION (33-DO-1) (KV-ES29M61 ONLY) 4-073-660-01 PARTITION (33-DO-2) (KV-ES29M61 ONLY) 4-074-023-01 CUSHION (KV-ES29M61 ONLY) 4-073-656-01 BASE TRAY (KV-ES29M61 ONLY) *************************************************************** 4-074-331-01 CARTON, FOR BC4 MOUNT (KV-ES29M61 ONLY) MISCELANEOUS 4-074-333-01 SHEET, C.F.B (KV-ES29M61 ONLY). *************** 4-074-334-01 PARTITION (33-BC-1) (KV-ES29M61 ONLY) 4-074-335-01 PARTITION (33-BC-2) (KV-ES29M61 ONLY)
Page 142 CUSHION (KV-ES29M61 ONLY) *********************** 4-075-322-01 HOLDER (KV-ES29M61 ONLY) 4-075-323-01 SPACER (KV-ES29M61 ONLY) 1-418-566-11 REMOTE COMMANDER (RM-916) 4-075-320-01 CARTON FOR H3 HOLDER (KV-ES29M61 ONLY) (KV-ES29M61) 4-075-321-01 CUSHION (KV-ES29M61 ONLY) 1-418-824-11 REMOTE COMMANDER (RM-958) (KV-ES29N90) 4-075-322-01 HOLDER (KV-ES29M61 ONLY) 4-074-721-01 BATTERY COVER, REMOTE COMMANDER...
