KLV-S26A10/S32A10/S40A10

SERVICE MANUAL

Display Unit
Power Requirements:
220 V AC, 50 Hz
Screen Size:
KLV-S40A10: 40 inches (approx. 101.6 cm)
KLV-S32A10: 32 inches (approx. 81.3 cm)
KLV-S26A10: 26 inches (approx. 66 cm)
Display Resolution (horizontal × vertical):
1366 pixels × 768 lines
Power Consumption:
KLV-S40A10: 260 W
KLV-S32A10: 170 W
KLV-S26A10: 110 W
Standby Power Consumption:
KLV-S40A10: 0.6 W
KLV-S32A10: 0.5 W
KLV-S26A10: 0.5 W
Dimensions (w × h × d):
KLV-S40A10:
Approx. 999 × 740 × 370 mm (with stand)
Approx. 999 × 693 × 102.5 mm (without stand)
KLV-S32A10:
Approx. 792 × 608 × 309 mm (with stand)
Approx. 792 × 564 × 99 mm (without stand)
KLV-S26A10:
Approx. 658 × 517 × 309 mm (with stand)
Approx. 658 × 474 × 90 mm (without stand)
SPECIFICATIONS
Weight:
KLV-S40A10:
Approx. 32.5 kg (with stand)
Approx. 26.5 kg (without stand)
KLV-S32A10:
Approx. 19.8 kg (with stand)
Approx. 16 kg (without stand)
KLV-S26A10:
Approx. 16.3 kg (with stand)
Approx. 12.5 kg (without stand)
Panel System
LCD (Liquid Crystal Display) Panel
TV System
D/K, I, B/G, M
Color System
PAL, PAL60, SECAM, NTSC 4.43, NTSC 3.58
Antenna
75 ohm external terminal
China Model
WAX
CHASSIS
LCD Color TV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KLV-S26A10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony KLV-S26A10

Summary of Contents for Sony KLV-S26A10

  • Page 1: Service Manual

    KLV-S40A10: 40 inches (approx. 101.6 cm) Approx. 19.8 kg (with stand) KLV-S32A10: 32 inches (approx. 81.3 cm) Approx. 16 kg (without stand) KLV-S26A10: 26 inches (approx. 66 cm) Display Resolution (horizontal × vertical): KLV-S26A10: 1366 pixels × 768 lines Approx. 16.3 kg (with stand) Approx.
  • Page 2 Headphones i Stereo minijack Sound Output KLV-S40A10: 8.5 W + 8.5 W KLV-S32A10: 8.5 W + 8.5 W KLV-S26A10: 8.5 W + 8.5 W Optional accessories • Wall-Mount Bracket KLV-S40A10: SU-PW2 KLV-S32A10, KLV-S26A10: SU-WL31 Design and specifications are subject to change without notice.
  • Page 3 2. Check the interboard wiring to ensure that no wires are OPERATION. REPLACE THESE COMPONENTS WITH “pinched” or contact high-wattage resistors. SONY PARTS WHOSE PART NUMBERS APPEAR AS 3. Check that all control knobs, shields, covers, ground straps, SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- and mounting hardware have been replaced.

  • Page 4: Table Of Contents

    6-2-5. CHASSIS-4 ............ 6-12 2-1-10. H3 BOARD AND SPEAKER REMOVAL ..2-5 6-2-6. LCD PANEL ..........6-13 2-1-11. LCD PANEL REMOVAL ......2-6 6-3. PACKING MATERIALS (KLV-S26A10) ..6-14 2-2. KLV-S40A10 ............. 2-7 6-4. PACKING MATERIALS (KLV-S32A10) ..6-15 2-2-1. STAND ASSY REMOVAL ......2-7 6-5.
