User Guide

Setting Up Your VueZone

Connect the gateway to your network
1. Connect the Ethernet cable to the Ethernet port on the gateway and an available LAN port on your
router.*
2. Connect the power adapter to the gateway and power outlet. The blue Power LED will be on.
3. The blue Internet LED will flash continuously if you have a valid connection. The initial flash may take
up to 2 minutes.
*If you are installing a network for the first time, please follow the network installation instructions for your router first.
Tip: If you need troubleshooting help, go to VueZone.com/install for answers and links to VueZone
support.
Installing camera battery
These instructions apply for all VueZone cameras.
1. Slide circular battery latch towards camera back, and press down on the bottom of the gray door to
remove.
2. Insert battery; be sure to following the polarity indication on the sticker inside the camera.
3. Snap battery door back in place by inserting the top portion of the door first and clicking the bottom
portion into place.
Tip: Wait until Step 3 to turn camera power on for synching with the VueZone gateway.
Syncing cameras to the VueZone gateway
Before syncing, confirm that the Internet LED light on front of the VueZone gateway is still flashing con-
tinuously. If not, go to VueZone.com/install to troubleshoot, or contact VueZone support.
1. Place camera within 12 inches of the VueZone gateway and slide the camera power switch to the
ON position (green dot showing).
2. Press and release the "Sync" button on the top of the VueZone gateway. The blue "Sync" LED light
will turn on for 45 seconds.
3. During this time, the camera will sync to the VueZone gateway. You'll see the LED light on the front
of the camera flash for 5 seconds to confirm sync.
4. If you cannot complete the camera sync in 45 seconds, the "Sync" button must be pressed again.
5. Once synced, the camera can be viewed and positioned.
Tip: For the VueZone motion detection cameras – every time the power is turned ON, it requires 2
minutes for the sensor to warm up and begin operating.
Registering your VueZone
1. Locate your VueZone Gateway Number (VGN) number on the bottom of the box your system came
in, the VueZone gateway or printed in the Quick Install Guide.
2. Go to my.VueZone.com and click the Register Now button.
3. Follow the on-screen instructions to register your system.
