Exploded View Parts List - LG 62SX4D-UB Service Manual

No. Part No.
120 6400GTTC02A
121 6400DTTA01A
174 6410VUH004A
300 3091V00807B
301 3550V00638A
302 4980V00D32F
303 4980V00D32E
305 3351V00028A
310 5020V01057B
400 3809V00579A
401 3809V00544A
402 3550V00269E
403 3110V00475A
404 3550V00595A
405 3550V00597A
406 3550V00596A
410 3550V00639A
430 5018V00086E
431 4980V01079A
432 4980V01080A
433 4980V01081A
501 3210V00165A
502 3210V00280A
503 4811V00152E
520 6871VMMZL7A
530 6871VPMA88J
540 6871VSMADYA
550 6871VSMS28B
560 6871VSMAEWA
570 6871VSMH07E
571 3141VSNH17E
580 6871VSME85A
600 3141VSNH18H
601 4980V00C01C
602 4980V00D11B
603 3550V00567B
610 6912B22007B
611 4814V00502C
612 3110V00477A
620 5900V06007A
622 5900V09008C
623 4980V00D73B
630 6871VSN221K
640 6316000009B
641 4930V00432A
650 6871VSMADTA
660 6871VSMAEXA
670 6871VSMH20A
671 3141VSNH97C
680 6871VSN220L
681 3500V00118A
690 6871VSME03L
700 6871VSME82A
710 6871VPMB01B
720 6871VSMW40D
722 3300V00420A
723 4980V00B42B

EXPLODED VIEW PARTS LIST

SPEAKER,FULLRANGE F30C-6622-1 16OHM 15/25W 80DB 80 NOTHING LUSTER
SPEAKER,TWEETER F20T-6624 8OHM 15/25W 84DB 50 NOTHING LUSTER
POWER CORD,UL/CSA3000MM 3P HUG BLACK VOLEX CSA 3000MM HUG BLACK 500MH 7A
CABINET ASSEMBLY,DU-62SX40D NON NB05EB PUSH
COVER,FRONT DU-62SX40D ABS, AF-303S BEST BUY
SUPPORTER,SCREEN AL RIGHT/LEFT 62SX40
SUPPORTER,SCREEN AL TOP/BOTTOM 62SX40
SCREEN ASSEMBLY,DNP LGE WLF DN-62SZ71D 1393*794*4.0 .
BUTTON,CONTROL DU-52SX40D ABS, HF-380 8KEY USA
BACK COVER ASSEMBLY,DU-62SX40D NON TOTAL ASSY FOR BEST BUY
BACK COVER ASSEMBLY,DU-62SY20 NON ,ASSY OF 3808V00535
COVER,LAMP FAN DUCT PC-ABS TN-56SZ70LR
CASE,DN-62SX40 ABS, AF-303S LAMP DUCT
COVER,LAMP DN-62SX40D HIPS 40AF SIDE
COVER,DN-62SX40D HIPS 40AF DUST CLEAN(L)
COVER,DN-62SX40D HIPS 40AF DUST CLEAN(R)
COVER,DUCT DN-62SX40D HIPS 40AF DUST COVER ASSY
MIRROR ASSY,KIT GLASS FRONTSIDE . DN-62X40D
SUPPORTER,MIRROR AL TOP,TN-62SZ70LR
SUPPORTER,MIRROR AL ,BOTTOM,TN-62SZ70LR
SUPPORTER,MIRROR AL ,SIDE,TN-62SZ70LR
FRAME,HIPS 40AF RN-48SZ40 SMPS CHASSIS
FRAME,CHASSIS HIPS 40AF DU-44SZ53D SMPS
BRACKET ASSEMBLY,REAR AV DU-52SX40D NB05CA ASSY
PCB ASSEMBLY,MAIN NB-05EB DU-52SX40D M/I
PCB ASSEMBLY,POWER SMPS NB-05EB AC INPUT M/I
PCB ASSEMBLY,SUB TUNER NB05EB DU-52SX40D M/I
PCB ASSEMBLY,SUB DIGITAL NB05EB DU-52SX40D M/I
PCB ASSEMBLY,SUB NB05EB DU-52SX40D COMP M/I
PCB ASSEMBLY,SUB,CRM MB042K HD3 LVDS M/I FOR DN-52SZ82D
CHASSIS ASSEMBLY,SUB MB042K HD3 DMD BOARD FOR DN-52SZ82D
PCB ASSEMBLY,SUB AUDIO MB042A DN-44SZ80L
CHASSIS ASSEMBLY,SUB MB042K HD3 SUB ENGINE ASSY FOR NEW CONDENSING LENS
SUPPORTER,SMPS EGI RU-44SZ63D
SUPPORTER,ENGINE SECC(EGI) BASE,DU-62SY20D
COVER,DU-62SX40D HIPS 40AF LENS COVER HD3
LAMP,HIGH PRESSURE MECURY UHP 120W 1.0 PH E22 PHILIPS 70V 1.6A 130MM/160MM XHD3
SHIELD ASSY,RU-44SZ63D NB03KB SECC(EGI) 4980V00B43B+4814V00530B
CASE,DU-62SY20D NON E-22 LAMP CASE
FAN,DC F6025S06B2-RH DONGYANG 60*60*25 6 2000RPM . 650MM
FAN,DC G9232S06B2-AA DONGYANG 92*92*32 6V 1700RPM DC5-8V 0.34CFM 750MM
SUPPORTER,EGI DMD FAN SUPPORTER(PRESS MOLD)
PCB ASSEMBLY,SUB NB05CA PRE-AMP DN-52SX40D
BALLAST,EUC-120P/11 PHILIPS REV 0.2 120W DLP PJT
HOLDER,BRACKET BALLAST PS .
PCB ASSEMBLY,SUB CONT NB05CA COTROL DN-52SX40D
PCB ASSEMBLY,SUB LED NB05EB DU-62SX40D LED M/I
PCB ASSEMBLY,SUB NB05CB SX40D EPF M/I
CHASSIS ASSEMBLY,SUB NB05CB DU-52SX40D EPF ASSY
PCB ASSEMBLY,SUB NB05CB SIDE A/V FOR DN-62SX40D
BOARD ASSY,DU-62SY20D NB05EA .
PCB ASSEMBLY,SUB NB05CA CASE DET S/W, SX40D
PCB ASSEMBLY,SUB INTER MB042A DN-44SZ80L
PCB ASSEMBLY,POWER SMPS NB05EB DU-62SX40D M/I ASSY
PCB ASSEMBLY,SUB SENSOR MB03CC HD3 DLP SENSOR
PLATE,LOCK AL . RT-52SZ60D HD3 PLATE UNAXIS C/W
SUPPORTER,AL COLOR WHEEL HOLDER(WITH HEAT SINK)
Description
- 25 -
