Clarity S-750 Quick Manual

(540) 427-3505

INTRODUCTION

The S-570 is a co-axial speaker/transformer/baffle
assembly for use with any Clarity Mixer-Amplifier.
This 8" ceiling speaker assembly is for use in interior
areas only.
These instructions contain the specifications and
information necessary to install, operate, and maintain
the co-axial ceiling speaker.

SPECIFICATIONS

Applications
- Clarity Paging Systems
- Clarity Background Music Systems
- Existing 25 or 70V Paging Systems
Features
- Combination 25/70V Transformer
- White epoxy paint ceiling grille
Transformer Tap Color Code
25 Volt Line
Color Designation
BLK Common
BRN 8W
RED 4.0W
ORN 2.0W
YEL 1.0W
GRN 0.5W
BLU 0.25W
Dimensions
13" Dia. x 3" D (33.02 cm X 7.62 cm)*
*All dimensions are approximate.
8 Watt Co-Axial Ceiling Speaker
70.7 Volt Line
Color Designation
BLK Common
YEL 8.0W
GRN 4.0W
BLU 2.0W
VIO 1.0W
GRY 0.5W
WHT 0.25W
S-750

Technical Specifications

Frequency Response
Max. Power Capability
SPL @ 4 ft. w/ 1 watt input 98 dB
Transformer Taps (Watts)
Line Voltage
Magnet Woofer
Magnet Tweeter
Environment
Temperature
Humidity
Coverage
The area covered by a ceiling speaker is determined by
the height of the ceiling. If the ceiling height is 8', the
speaker will cover 250 sq. ft. With a ceiling height of 9
to 15 feet, the speaker will cover 400 sq. ft. If the
ceiling is 16 to 35 feet high, the speaker will cover 850
sq. ft.
1
CSP S-750
Issue 1
60 to 17K
8 Watts
5/16, 5/8, 1-1/4,
2-1/2 and 5
25 or 70V
10 oz
3.0 oz
0 to 50 Degrees C
0 to 85% non-precipitating
947444
