Page 3 ThinkCentre Hardware Maintenance Manual...
Page 4 © Copyright Lenovo 2008, 2009. All rights reserved. LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.
Page 5: Table Of Contents
Chapter 7. Symptom-to-FRU index . . . 53 (ACPI) BIOS . . 311 Hard disk drive boot error . . 53 Automatic Power-On features . . 311 Diagnostic error codes . . 54 Beep symptoms . . 73 © Copyright Lenovo 2008, 2009...
Page 6 Appendix. Notices ..313 Trademarks . . 314 Television output notice . . 314 Hardware Maintenance Manual...
Page 7: Chapter 1. About This Manual
This manual is intended only for trained ® Service Providers who are familiar with Lenovo computer products. Note: Be sure to read and understand the Chapter 2, “Safety information,” on page 3 before using the information in this manual.
Page 8: Important Information About Replacing Rohs Compliant Frus
FRU part numbers. Lenovo plans to transition to RoHS compliance well before the implementation date and expects its suppliers to be ready to support Lenovo’s requirements and schedule in the EU. Products sold in 2005, will contain some RoHS compliant FRUs.
Page 9: Chapter 2. Safety Information
After service, reinstall all safety shields, guards, labels, and ground wires. Replace any safety device that is worn or defective. v Reinstall all covers correctly before returning the machine to the customer. Electrical safety © Copyright Lenovo 2008, 2009...
Page 10 CAUTION: Electrical current from power, telephone, and communication cables can be hazardous. To avoid personal injury or equipment damage, disconnect the attached power cords, telecommunication systems, networks, and modems before you open the server/workstation covers, unless instructed otherwise in the installation and configuration procedures.
Page 11: Voltage-Selection Switch
v Always look carefully for possible hazards in your work area. Examples of these hazards are moist floors, nongrounded power extension cables, power surges, and missing safety grounds. v Do not touch live electrical circuits with the reflective surface of a plastic dental mirror.
Page 12: Handling Electrostatic Discharge-Sensitive Devices
If any unsafe conditions are present, you must determine how serious the apparent hazard could be and whether you can continue without first correcting the problem. Consider these conditions and the safety hazards they present: v Electrical hazards, especially primary power (primary voltage on the frame can cause serious or fatal electrical shock).
Page 13: Grounding Requirements
v Prevent the part from touching your clothing. Most clothing is insulative and retains a charge even when you are wearing a wrist strap. v Use the black side of a grounded work mat to provide a static-free work surface. The mat is especially useful when handling ESD-sensitive devices.
Page 14 v Connect to properly wired outlets any equipment that will be attached to this product. v When possible, use one hand only to connect or disconnect signal cables. v Never turn on any equipment when there is evidence of fire, water, or structural damage.
Page 15 CAUTION: When replacing the lithium battery, use only Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.
Page 16 CAUTION: The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source.
Page 17 Chapter 2. Safety information...
Page 18 Hardware Maintenance Manual...
Page 19 ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) Chapter 2. Safety information...
Page 20 PERIGO A corrente elétrica proveniente de cabos de alimentação, de telefone e de comunicações é perigosa. Para evitar risco de choque elétrico: v Não conecte nem desconecte nenhum cabo ou execute instalação, manutenção ou reconfiguração deste produto durante uma tempestade com raios. v Conecte todos os cabos de alimentação a tomadas elétricas corretamente instaladas e aterradas.
Page 21 CUIDADO: Ao substituir a bateria de lítio, utilize apenas uma bateria com Número de Peça 33F8354 ou um tipo de bateria equivalente recomendado pelo Se o seu sistema possui um módulo com uma bateria de lítio, substitua-o apenas por um módulo do mesmo tipo e do mesmo fabricante.
Page 22 CUIDADO: O botão de controle de alimentação do dispositivo e o botão para ligar/desligar da fonte de alimentação não desligam a corrente elétrica fornecida ao dispositivo. O dispositivo também pode ter mais de um cabo de alimentação. Para remover toda a corrente elétrica do dispositivo, assegure que todos os cabos de alimentação estejam desconectados da fonte de alimentação.
Page 23 Chapter 2. Safety information...
Page 24 Hardware Maintenance Manual...
Page 25 Chapter 2. Safety information...
Page 26 Hardware Maintenance Manual...
Page 27 DANGER Le courant électrique provenant de l’alimentation, du téléphone et des câbles de transmission peut présenter un danger. Pour éviter tout risque de choc électrique : v Ne manipulez aucun câble et n’effectuez aucune opération d’installation, d’entretien ou de reconfiguration de ce produit au cours d’un orage. v Branchez tous les cordons d’alimentation sur un socle de prise de courant correctement câblé...
Page 28 ATTENTION: Remplacer la pile au lithium usagée par une pile de référence identique exclusivement, (référence 33F8354), ou suivre les instructions du fabricant qui en définit les équivalences. Si votre système est doté d’un module contenant une pile au lithium, vous devez le remplacer uniquement par un module identique, produit par le même fabricant.
Page 29 ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) ATTENTION: Soulevez la machine avec précaution. ATTENTION: L’interrupteur de contrôle d’alimentation de l’unité et l’interrupteur dubloc d’alimentation ne coupent pas le courant électrique alimentantl’unité. En outre, le système peut être équipé de plusieurs cordonsd’alimentation. Pour mettre l’unité...
Page 30 VORSICHT An Netz-, Telefon- und Datenleitungen können gefährliche Spannungen anliegen. Aus Sicherheitsgründen: v Bei Gewitter an diesem Gerät keine Kabel anschließen oder lösen. Ferner keine Installations-, Wartungs- oder Rekonfigurationsarbeiten durchführen. v Gerät nur an eine Schutzkontaktsteckdose mit ordnungsgemäß geerdetem Schutzkontakt anschließen. v Alle angeschlossenen Geräte ebenfalls an Schutzkontaktsteckdosen mit ordnungsgemäß...
Page 31 CAUTION: Eine verbrauchte Lithiumbatterie nur durch eine Batterie mit der Teilenummer 33F8354 oder eine gleichwertige, vom Hersteller empfohlene Batterie ersetzen. Enthält das System ein Modul mit einer Lithiumbatterie, dieses nur durch ein Modul desselben Typs und von demselben Hersteller ersetzen. Die Batterie enthält Lithium und kann bei unsachgemäßer Verwendung, Handhabung oder Entsorgung explodieren.
Page 32 ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) ACHTUNG: Arbeitsschutzrichtlinien beim Anheben der Maschine beachten. ACHTUNG: Mit dem Netzschalter an der Einheit und am Netzteil wird die Stromversorgung für die Einheit nicht unterbrochen. Die Einheit kann auch mit mehreren Netzkabeln ausgestattet sein.
Page 33 Chapter 2. Safety information...
Page 34 Hardware Maintenance Manual...
Page 35 Chapter 2. Safety information...
Page 36 PERICOLO La corrente elettrica proveniente dai cavi di alimentazione, del telefono e di comunicazione può essere pericolosa. Per evitare il rischio di scosse elettriche: v Non collegare o scollegare qualsiasi cavo oppure effettuare l’installazione, la manutenzione o la riconfigurazione del prodotto durante un temporale. v Collegare tutti i fili elettrici a una presa di alimentazione correttamente cablata e dotata di messa a terra.
Page 37 ATTENZIONE: Quando si sostituisce la batteria al litio, utilizzare solo il Numero parte 33F8354 o un tipo di batteria equivalente consigliato dal produttore. Se sul sistema è presente un modulo che contiene una batteria al litio, sostituirlo solo con un tipo di modulo dello stesso tipo della stessa casa di produzione.
Page 38 ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) ATTENZIONE: Prestare attenzione nel sollevare l’apparecchiatura. ATTENZIONE: Il pulsante di controllo dell’alimentazione presente sull’unità e l’interruttore dell’alimentatore non disattivano l’alimentazione corrente fornita all’unità. E’ possibile che l’unità disponga di più cavi di alimentazione. Per disattivare l’alimentazione dall’unità, accertarsi che tutti i cavi di alimentazione siano scollegati dalla fonte di alimentazione.
Page 39 Chapter 2. Safety information...
Page 40 Hardware Maintenance Manual...
Page 41 PELIGRO La corriente eléctrica procedente de cables de alimentación, teléfonos y cables de comunicación puede ser peligrosa. Para evitar el riesgo de descarga eléctrica: v No conecte ni desconecte los cables ni realice ninguna tarea de instalación, mantenimiento o reconfiguración de este producto durante una tormenta eléctrica.
Page 42 PRECAUCIÓN: Cuando sustituya una batería de litio, utilice solamente una batería número de pieza 33F8354 u otra de tipo equivalente recomendada por el fabricante. Si su sistema dispone de un módulo que contiene una batería de litio, reemplácelo sólo con el mismo tipo de módulo, del mismo fabricante. La batería contiene litio y puede explotar si no se utiliza, manipula o desecha correctamente.
Page 43 ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) PRECAUCIÓN: Adopte procedimientos seguros al levantar el equipo. PRECAUCIÓN: El botón de control de alimentación del dispositivo y el interruptor de alimentación de la fuente de alimentación no desconectan la corriente eléctrica suministrada al dispositivo.
Page 44 Hardware Maintenance Manual...
Page 45: Chapter 3. General Information
This chapter provides general information that applies to all machine types supported by this manual. ThinkVantage Productivity Center Note: This section applies only to computer models that have an internal hard disk drive and preinstalled software from Lenovo. ® Use the ThinkVantage Productivity Center program which is preinstalled on most ThinkCentre products for general information about the use, operation, and maintenance of the computer.
Page 46: Specifications
Specifications This section lists the physical specifications for your computer. Dimensions Width: 275 mm (10.83 inches) Height: 80 mm (3.15 inches) Depth: 238 mm (9.37 inches) Weight Note: The weight does not include the power supply or any external cables. Maximum configuration as shipped: 4.18 kg (9.22 lbs) Environment Air temperature:...
Page 47: Chapter 4. General Checkout
If the computer displays a POST error, go to “POST error codes” on page 74. v If the computer hangs and no error is displayed, go to “Checking for power problems” on page 42. © Copyright Lenovo 2008, 2009...
Page 48: Checking For Power Problems
Checking for power problems If the computer does not turn on when the power switch is pressed, use the following procedure to help troubleshoot: 1. Press the power switch to turn on the computer. Check the power indicator LED next to the power switch. v If the LED is illuminated (on), the computer power is OK.
Page 49 v Operating system software – Type and version level Note: To eliminate confusion, identical systems are considered identical only if they: 1. Are the exact machine type and models 2. Have the same BIOS level 3. Have the same adapters/attachments in the same locations 4.
Page 50 Hardware Maintenance Manual...
Page 51: Chapter 5. Diagnostics
Lenovo troubleshooting center, update system drivers, and review system information. To run the Lenovo System Toolbox, click Start → All Programs → Lenovo Services → Lenovo System Toolbox. Follow the instructions on the screen. The Lenovo System Toolbox also has problem determination aids that determine software and usage problems.
Page 52: Pc-Doctor For Windows Pe
Recovery workspace on each Lenovo computer. Use the PC-Doctor for Windows PE if you are unable to start the Windows operating system or if the Lenovo System Toolbox has not been successful in isolating a possible problem. Running diagnostics from the Rescue and Recovery...
Page 53: Navigating Through The Diagnostics Programs
Note: When the program finishes, be sure to remove the disc from the optical drive. 4. Select the diagnostic test you want to run. Press the F1 key for additional help. Navigating through the diagnostics programs Use the cursor movement keys to navigate within the menus. v The Enter key is used to select a menu item.
Page 54: Viewing The Test Log
v Date: Contains the date when the diagnostic test was run. The date is retrieved from CMOS and displayed using the YYYYMMDD format. v ChkDigits: Contains a 2-digit check-digit value to ensure the following: – Diagnostics were run on the specified date. –...
Page 55: Chapter 6. Using The Setup Utility
Power-On Password v Administrator Password v Hard Disk User Password You do not have to set any passwords to use your computer. However, if you decide to set any passwords, read the following sections. © Copyright Lenovo 2008, 2009...
Page 56: Password Considerations
Password considerations A password can be any combination of up to 64 (1 to 64) alphabetic and numeric characters. For security reasons, it is recommended to use a strong password that cannot be easily compromised. A strong password should adhere to the following rules: v Have at least eight characters in length and contain at least one alphabetic character and one numeric character...
Page 57: Enabling Or Disabling A Device
Enabling or disabling a device This section provides information on how to enable or disable user access to the following devices: Serial ATA When this feature is set to Disabled, all devices connected to the SATA connectors (such as hard disk drives or the optical drive) are disabled and will not be displayed in the system configuration.
Page 58: Selecting Or Changing The Startup Device Sequence
Selecting or changing the startup device sequence To view or permanently change the configured startup device sequence, do the following: 1. Start the Setup Utility program. See “Starting the Setup Utility program” on page 49. 2. Select Startup → Startup Sequence. See the information displayed on the right side of the screen.
Page 59: Chapter 7. Symptom-To-Fru Index
The drive must be formatted, do the corrupted. following: 1. Attempt to back-up the data on the failing hard disk drive. 2. Using the operating systems programs, format the hard disk drive. The drive is defective. Replace the hard disk drive. © Copyright Lenovo 2008, 2009...
Page 60: Diagnostic Error Codes
Diagnostic error codes Refer to the following diagnostic error codes when using the diagnostic tests. See “Running tests” on page 47 for the specific type for information about the Diagnostic programs. In the following index, X can represent any number. Diagnostic Error Code FRU/Action 000-000-XXX...
Page 61 Diagnostic Error Code FRU/Action 000-039-XXX 1. Flash the system. See “Updating BIOS DMI data error (flashing) BIOS from a disc” on page 2. System board 000-195-XXX Information only BIOS Test aborted by user Re-start the test, if necessary 000-196-XXX 1. Press F3 to review the log file BIOS test halt, error threshold exceeded 2.
Page 62 Diagnostic Error Code FRU/Action 001-025-XXX 1. Flash the system. See “Updating System Checksum Value error (flashing) BIOS from a disc” on page 2. System board 001-026-XXX 1. Flash the system. See “Updating System FLASH data error (flashing) BIOS from a disc” on page 2.
Page 63 Diagnostic Error Code FRU/Action 001-198-XXX 1. If a component is called out, make sure System test aborted it is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Flash the system and retest. See “Updating (flashing) BIOS from a disc” on page 310 3.
Page 64 Diagnostic Error Code FRU/Action 001-278-XXX 1. Device on IRQ11 System IRQ11 failure 2. System board 001-279-XXX 1. Device on IRQ12 System IRQ12 failure 2. System board 001-280-XXX 1. Device on IRQ13 System IRQ13 failure 2. System board 001-281-XXX 1. Hard disk drive cable System IRQ14 2.
Page 65 Diagnostic Error Code FRU/Action 005-024-XXX 1. Video card, if installed Video Addressing test failure 2. System board 005-025-XXX 1. Video card, if installed Video Checksum Value error 2. System board 005-027-XXX 1. Run Setup Video Configuration/Setup error 2. Video drivers update 3.
Page 66 Diagnostic Error Code FRU/Action 005-199-XXX 1. Go to “Undetermined problems” on page Video test failed, cause unknown 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3. Replace component under function test 005-2XX-XXX 1.
Page 67 Diagnostic Error Code FRU/Action 015-015-XXX 1. Remove USB device(s) and re-test USB port External Loopback failure 2. System board 015-027-XXX 1. Flash the system. See “Updating USB port Configuration/Setup error (flashing) BIOS from a disc” on page 2. System board 015-032-XXX System board USB port Device Controller failure...
Page 68 Diagnostic Error Code FRU/Action 015-199-XXX 1. Go to “Undetermined problems” on page USB port test failed, cause unknown 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3. Replace component under function test 018-000-XXX No action PCI Card Test Passed...
Page 69 Diagnostic Error Code FRU/Action 020-195-XXX Information only PCI Test aborted by user Re-start the test, if necessary 020-196-XXX 1. Press F3 to review the log file PCI test halt, error threshold exceeded 2. Re-start the test to reset the log file 020-197-XXX 1.
Page 70 Diagnostic Error Code FRU/Action 025-02X-XXX 1. IDE signal cable 025-03X-XXX 2. Check AC/DC power adapter 025-04X-XXX 3. Reseat IDE signal cable IDE Interface failure 4. IDE device 5. System board 025-195-XXX Information only IDE interface Test aborted by user Re-start the test, if necessary 025-196-XXX 1.
Page 71 Diagnostic Error Code FRU/Action 030-03X-XXX 1. SCSI signal cable 030-04X-XXX 2. Check AC/DC power adapter SCSI interface error 3. SCSI device 4. SCSI adapter card, if installed 5. System board 030-195-XXX Information only SCSI interface Test aborted by user Re-start the test, if necessary 030-196-XXX 1.
Page 72 Diagnostic Error Code FRU/Action 035-197-XXX 1. Make sure the component that is called RAID interface test warning out is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Re-run test 3. Replace the component that is called out in warning statement 4.
Page 73 Diagnostic Error Code FRU/Action 071-197-XXX 1. Make sure the component that is called Audio port test warning out is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Re-run test 3. Replace the component that is called out in warning statement 4.
Page 74 Diagnostic Error Code FRU/Action 080-198-XXX 1. If a component is called out, make sure Game Port interface test aborted it is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc”...
Page 75 Diagnostic Error Code FRU/Action 086-199-XXX 1. See “Undetermined problems” on page Mouse Port interface test failed, cause unknown 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3. Replace component under function test 089-000-XXX No action Microprocessor Test Passed...
Page 76 Diagnostic Error Code FRU/Action 170-197-XXX 1. Make sure the component that is called Voltage Sensor(s) test warning out is connected and/or enabled. See Chapter 6, “Using the Setup Utility,” on page 49 2. Re-run test 3. Replace the component that is called out in warning statement 4.
Page 77 Diagnostic Error Code FRU/Action 175-198-XXX 1. If a component is called out, make sure Thermal Sensor(s) test aborted it is connected and/or enabled 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 310 3. Go to “Undetermined problems” on page 175-199-XXX 1.
Page 78 Diagnostic Error Code FRU/Action 215-XXX-XXX 1. CD-ROM Drive Cable CD-ROM Drive error 2. Check AC/DC power adapter voltages 3. CD-ROM drive 4. System board 217-000-XXX No action Hard Disk Drive Test Passed 217-25X-XXX 1. Hard Disk Drive Cable 217-26X-XXX 2. Check AC/DC power adapter voltages Hard Disk Drive (IDE) error 3.
Page 79: Beep Symptoms
Diagnostic Error Code FRU/Action 415-XXX-XXX Remove the Modem and re-test the system Modem error Beep symptoms Beep symptoms are tones or a series of tones separated by pauses (intervals without sound) during POST. The following tables describes beep symptoms. Beep Symptom FRU/Action Reseat the memory modules.
Page 80: Post Error Codes
POST error codes Each time you power-on the system, it performs a series of tests that check the operation of the system and some options. This series of tests is called the Power-On Self-Test, or POST. POST does the following operations. v Checks some basic system-board operations v Checks the memory operation v Starts the video operation...
Page 81 POST Error Message Description/Action Press TAB to show POST screen Pressing the TAB key permits the user to toggle between the default POST display screen and a custom POST display screen. Error: Non-System disk or disk error The BIOS was unable to find a suitable boot Replace and press any key when ready device.
Page 82: Miscellaneous Error Messages
Miscellaneous error messages Message/Symptom FRU/Action Changing display colors Display/Monitor Computer will not power-off. See “Checking 1. Power Switch for power problems” on page 42. 2. System Board 3. Riser card, if installed Computer will not PXE from server 1. Ensure that network is in startup sequence as first device or first device after diskette 2.
Page 83: Undetermined Problems
Message/Symptom FRU/Action Non-system disk or disk error-type message 1. Diskette Drive with a known-good diagnostic diskette. 2. System Board 3. Diskette Drive Cable Other display symptoms not listed above 1. Display (including blank or illegible display) 2. System Board Power-on indicator or hard disk drive in-use 1.
Page 84 Hardware Maintenance Manual...
Page 85: Chapter 8. Replacing Frus
Be sure to read and understand the Chapter 2, “Safety information,” on page 3 before replacing any FRU. These precautions and guidelines will help you work safely. FRU replacements are to be done only by trained service technicians. © Copyright Lenovo 2008, 2009...
Page 86: Locations
Locations This section provides illustrations to help you locate the various connectors and components of your computer. Locating connectors on the front of the computer The following illustration shows the location of the connectors on the front of your computer. Note: Not all computer models have the following connectors.
Page 87: Locating Connectors On The Rear Of The Computer
Locating connectors on the rear of the computer The following illustration shows the locations of the connectors on the rear of the computer. Figure 2. Rear connector locations 1 VGA (Video Graphics Array) 8 Cover-release button monitor connector 2 USB connectors (3) 9 Adapter card slot 3 Ethernet connector 10 Audio line-out connector...
Page 88: Locating Components
Locating components The following illustration shows the locations of the various components in the computer. Figure 3. Component locations 1 Optical drive 5 Heat sink 2 Front bezel 6 Battery 3 Hard disk drive 7 Memory slots (2) 4 System fan assembly 8 Internal speaker Hardware Maintenance Manual...
Page 89: Locating Parts On The System Board
Locating parts on the system board The following illustration shows the locations of parts on the system board. Figure 4. System board parts locations 1 Microprocessor 9 PCI slot 2 Clear CMOS/Recovery jumper 10 Front USB connector 2 3 Thermal sensor connector 11 Intrusion switch connector/Cover presence switch connector 4 Battery...
Page 90: Opening The Computer Cover
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to open the computer cover.
Page 91: Replacing The Battery
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the battery. Your computer has a special type of memory that maintains the date, time, and settings for built-in features, such as the parallel-port assignments (configuration).
Page 92: Replacing A Memory Module
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace a memory module.
Page 93 4. Insert the notched end 2 of the new memory module into the socket 1 . Press the memory module firmly, and pivot the memory module until it snaps into place. Make sure that the memory module is firmly fixed in the slot and does not move easily.
Page 94: Replacing The Adapter Card
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the adapter card.
Page 95 6. Rotate the adapter card retainer to the open position and remove the adapter card being replaced by pulling it out of the adapter card slot. Figure 11. Removing the adapter card 7. Remove the new adapter card from its static-protective package. 8.
Page 96: Replacing The Front Audio And Usb Assembly
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the front audio and USB assembly.
Page 97: Replacing The Heat Sink
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the heat sink.
Page 98 To replace the heat sink: 1. Open the computer cover. See “Opening the computer cover” on page 84. 2. Locate the heat sink. See “Locating components” on page 82. 3. Remove the four screws that secure the heat sink to the system board. Note: Carefully remove the four screws from the system board to avoid any possible damage.
Page 99: Replacing The Microprocessor
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the microprocessor. CAUTION: The heat sink and microprocessor might be very hot.
Page 100 6. Lift the microprocessor straight up and out of the socket. Notes: a. Your microprocessor and socket might look different from the one illustrated. b. Note the orientation of the microprocessor in the socket. You can either look for the small triangle 1 on one corner of the microprocessor or note the orientation of the notches 2 on the microprocessor.
Page 101 8. Remove the protective cover 2 that protects the gold contacts on the new microprocessor 1 . 9. Hold the new microprocessor and align the notches on it with the tabs in the microprocessor socket, or align the small triangle on one corner with the corresponding beveled corner of the microprocessor socket.
Page 102: Replacing The System Board
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the system board.
Page 103 7. Remove the adapter card from the failing system board. See “Replacing the adapter card” on page 88. 8. Remove the battery from the failing system board. See “Replacing the battery” on page 85. 9. Remove the microprocessor from the failing system board. See “Replacing the microprocessor”...
Page 104 3. Insert the tabs 1 of the socket cover into the hinged side of the socket, and then press the other side of the socket cover downward until the tabs 2 snap into position. Figure 18. Tabs on the microprocessor socket cover (bottom view) Figure 19.
Page 105: Replacing The System Fan
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the system fan.
Page 106 6. Install the two short rubber mounts in the new system fan as shown. Figure 21. Installing the short rubber mounts 7. Install the two long rubber mounts into the rear of the chassis. Push the mounts through the holes of the chassis. If necessary, pull the mounts through the holes from inside the chassis.
Page 107: Replacing The Hard Disk Drive
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the hard disk drive if your computer has one.
Page 108 7. To install the new hard disk drive into the plastic bracket, flex the bracket and align pin 1 , pin 2 , pin 3 , and pin 4 on the bracket with the holes in the hard disk drive. Do not touch the circuit board 5 on the bottom of the hard disk drive.
Page 109: Replacing The Optical Drive
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the optical drive.
Page 110 5. Remove the retainer bracket from the failing drive and install it on the new optical drive. Figure 27. Retainer bracket for optical drive 6. Slide the new optical drive into the drive bay until it snaps into position. Figure 28. Replacing the optical drive 7.
Page 111: Replacing The Internal Speaker
“Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the internal speaker.
Page 112: Completing The Fru Replacement
Completing the FRU replacement This section provides instructions on how to complete the parts replacement. After completing all parts replacement, you need to close the cover and reconnect cables, such as power cords. Depending on the parts replaced, you might need to confirm the updated information in the Setup Utility program.
Page 113 3. Close the computer cover. Figure 31. Closing the computer cover 4. If a cover lock is installed, lock the cover. 5. Reconnect the external cables and power cords to the computer. See “Locating connectors on the rear of the computer” on page 81. 6.
Page 114 Hardware Maintenance Manual...
Page 115: Chapter 9. Fru Lists
A1L A1D A1Y A1G A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J CTO) Hard disk drive, SATA 250GB 7200RPM/3Gb/8MB (models CTO) 40Y9036 Hard disk drive, SATA 320GB 7200RPM SATA/8MB (models CTO) 87H4891 Hard disk drive, SATA 500GB 7200RPM/3Gb/s/8MB (models CTO) 41X5582 © Copyright Lenovo 2008, 2009...
Page 116 Item # 6136 FRUs FRU # Hard disk drive, SATA 1TB 7200RPM/3Gb/8MB (models) 45C5973 System fan assembly (all models) 43N9655 ™ Microprocessor, Core 2 Duo E4600 Processor 2.40GHz 800MHz FSB 2M L2 M-0 45C5282 Stepping Level, Mainstream/Value FMB (models) Microprocessor, E4700 Conroe 2.60GHz 800MHz FSB 2M (models) 45R5786 Microprocessor, E8600 Wolfdale, 3.33GHZ,1333M FSB 6M E-0 (models CTO) 46R8640...
Page 117 43N9659 IO shielding assembly (all models) 43N9660 MB tray assembly (all models) 43N9661 6136 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models A1U A1L A1G A1M A1A A1Q A1H A1R A1E) 41A5289 Arabic (models A1G)
Page 118 6136 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # French (models A1G) 41A5300 French Canadian (models A1F A1G) 41A5301 French Canadian (models A1F A1G) 41A5302 German (models A1G) 41A5303 Greek (models A1G) 41A5304 Greek/US (models A1G) 41A5305 Hebrew (models A1G)
Page 119 6136 Keyboards (Lenovo Fingerprint Reader USB) FRU # Chinese/US (models) 41R0045 Czech (models) 41R0046 Danish (models) 41R0047 Dutch (models) 41R0048 French (models) 41R0049 French Canadian (models) 41R0050 French Canadian (models) 41R0051 German (models) 41R0052 Greek (models) 41R0053 Greek/US (models) 41R0054...
Page 120 ® 6136 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # Brazilian Portuguese (models) 41A5044 Bulgarian (models) 41A5045 Chinese/US (models) 41A5046 Czech (models) 41A5047 Danish (models) 41A5048 Dutch (models) 41A5049 French (models) 41A5050 French Canadian (models) 41A5051 French Canadian (models)
Page 121 DP to DVI dongle 200 mm (models CTO) 43N9160 IEEE 1394 Firewire adapter (LP) (models CTO) 41D2781 Speakers (2-piece) Lenovo Logo (Primary) (models) 41A5331 Speakers (2-piece) Lenovo Logo (Secondary) (models) 41A5334 Speaker power brick - US, Canada, LA low voltage, ASEAN (models A1U)
Page 122 ® ® 6136 Microsoft Windows XP Home Recovery CDs FRU # US English/UK/Asia Pacific (models) French/Canadian French (models) German (models) Italian (models) Brazilian (models) Spanish/LA (models) Danish (models) Dutch (models) Arabic (models) Swedish (models) Hebrew (models) Finnish (models) Norwegian (models) Polish (models) Portuguese (models) Russian (models)
Page 123 6136 Windows XP Pro Recovery CDs FRU # Polish (models) 53Y7087 Portuguese (models) 53Y7094 Russian (models) 53Y7089 Russian English (models) 63Y8271 Hungarian (models) 53Y7092 Czech (models) 53Y7084 Turkish (models) 53Y7091 Greek (models) 53Y7093 Slovakian (models) 53Y7095 Japanese (models) 53Y7079 Simplified Chinese (models) 53Y7096 Taiwan - Traditional Chinese (models) 53Y7097...
Page 124 ® 6136 Microsoft Windows Vista Home Basic 32 Recovery DVDs FRU # Slovenian (models) 53Y7230 Russian English (models) 53Y7213 Hebrew (models) 53Y7233 Arabic localized (models) 53Y7231 Slovakian (models) 53Y7237 Romanian (models) 53Y7234 Serbian-Latin (models) 53Y7236 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models) 53Y7238 C&L 2 Switzerland (English, French, German, Italian) (models) 53Y7239...
Page 125 6136 Vista Business 32 Recovery DVDs FRU # Slovakian (models A1G) 53Y7179 Arabic localized (models A1G) 53Y7173 Hebrew (models A1G) 53Y7175 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models) 53Y7180 C&L 2 Switzerland (English, French, German, Italian) (models) 53Y7181 C&L 3 Bel Lux (English, French, German, Dutch) (models) 53Y7182 6136 Windows Vista Home Premium 32 Recovery DVDs...
Page 126 6136 Windows Vista Business 64 Recovery DVDs FRU # Russian English (models) 53Y7250 Russian French (models) 53Y7251 German (models) 53Y7252 Spanish (models) Brazilian Portuguese (models) Italian (models) Japanese (models) 53Y7253 Norwegian (models) Swedish (models) Danish (models) Dutch (models) Czech (models) Finnish (models) Polish (models) Russian (models)
Page 127 6136 Windows Vista Ultimate 32 Recovery DVDs FRU # Traditional Chinese (models) Hong Kong (models) 53Y7247 Norwegian (models) Korean (models) Slovenian (models) Greek (models) Russian (models) Portuguese (models) Turkish (models) Czech (models) Polish (models) Russian English (models) Arabic localized (models) 53Y7248 Hebrew (models) Hungarian (models)
Page 128: Machine Type 6139
Machine Type 6139 Item # 6139 FRUs FRU # DVD-ROM 16X Max SATA (models 91G) 41N3325 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models 91G) 43C1042 130W AC/DC Power Adapter WW, Robust, JP (models) 41A9767 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models91G) 40Y9035 Hard disk drive, SATA 250GB 7200RPM/3Gb/8MB (models91G) 40Y9036...
Page 129 Item # 6139 FRUs FRU # Microprocessor, E7200 Wolfdale 2.53GHZ 1066MHZFSB 3MB M-0 (models 91G) 45R8337 Microprocessor, E7300 Wolfdale 2.66GHZ 1066FSB FSB 3MB M-0 (models 91G) 46R1622 Microprocessor, E2160 Conroe-L 1.80GHz 800MHz FSB 1M (models91G) 43C1968 Microprocessor, E2180 Conroe-L 2.00GHz 800MHz FSB 1M (models91G) 45C1773 Microprocessor, E2200 Conroe-L 2.20GHz 800MHz FSB 1M (models91G) 45C5349...
Page 130 MB tray assembly (all models) 43N9661 Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 65W Heatsink kit (all models) 43N9427 6139 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models 91G) 41A5289 Arabic (models 91G) 41A5290...
Page 131 6139 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Greek/US (models 91G) 41A5305 Hebrew (models 91G) 41A5306 Hungarian (models 91G) 41A5307 Iceland (models 91G) 41A5308 Italian (models 91G) 41A5309 Japanese (models 91G) 41A5310 Korean (models 91G) 41A5311 LA Spanish (models 91G)
Page 132 Turkish (models 91G) 41R0075 UK English (models 91G) 41R0076 US Euro (models 91G) 41R0077 Slovenian (models 91G) 41R0078 6139 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91G) 41A5039 Arabic (models 91G) 41A5040 Arabic/French (models 91G) 41A5041...
Page 133 6139 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # Dutch (models 91G) 41A5049 French (models 91G) 41A5050 French Canadian (models 91G) 41A5051 French Canadian (models 91G) 41A5052 German (models 91G) 41A5053 Greek (models 91G) 41A5054 Greek/US (models 91G)
Page 134 6139 adapters and miscellaneous FRUs FRU # Speaker power brick - LA high voltage (non-APU) (models91G) 89P8575 Speaker power brick - Simplified Chinese, Thailand, EMEA (models 91G) 89P8581 Speaker power brick - Japanese (models 91G) 89P8577 Speaker power brick - Brazilian (models 91G) 89P8583 Speaker power brick - Argentina (models 91G) 41A4901...
Page 135 6139 Windows XP Home Recovery CDs FRU # Brazilian (models 91G) Spanish/LA (models 91G) Danish (models 91G) Dutch (models 91G) Arabic (models 91G) Swedish (models 91G) Hebrew (models 91G) Finnish (models 91G) Norwegian (models 91G) Polish (models 91G) Portuguese (models 91G) Russian (models 91G) Russian English (models 91G) Hungarian (models 91G)
Page 136 6139 Windows XP Pro Recovery CDs FRU # Hungarian (models 91G) 53Y7092 Czech (models 91G) 53Y7084 Turkish (models 91G) 53Y7091 Greek (models 91G) 53Y7093 Slovakian (models 91G) 53Y7095 Japanese (models 91G) 53Y7079 Simplified Chinese (models 91G) 53Y7096 Taiwan - Traditional Chinese (models 91G) 53Y7097 Hong Kong - Traditional Chinese (models 91G) 53Y7098...
Page 137 6139 Windows Vista Home Basic 32 Recovery DVDs FRU # Slovakian (models 91G) 53Y7237 Romanian (models 91G) 53Y7234 Serbian-Latin (models 91G) 53Y7236 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91G) 53Y7238 C&L 2 Switzerland (English, French, German, Italian) (models 91G) 53Y7239 C&L 3 Bel Lux (English, French, German, Dutch) (models91G) 53Y7240...
Page 138 6139 Vista Business 32 Recovery DVDs FRU # C&L 2 Switzerland (English, French, German, Italian) (models 91G) 53Y7181 C&L 3 Bel Lux (English, French, German, Dutch) (models91G) 53Y7182 6139 Windows Vista Home Premium 32 Recovery DVDs FRU # English (models 91G) Russian English (models 91G) French/Canadian French (models 91G) German (models 91G)
Page 139 6139 Windows Vista Business 64 Recovery DVDs FRU # Spanish (models 91G) Brazilian Portuguese (models 91G) Italian (models 91G) Japanese (models 91G) 53Y7253 Norwegian (models 91G) Swedish (models 91G) Danish (models 91G) Dutch (models 91G) Czech (models 91G) Finnish (models 91G) Polish (models 91G) Russian (models 91G) Turkish (models 91G)
Page 140 6139 Windows Vista Ultimate 32 Recovery DVDs FRU # Korean (models 91G) Slovenian (models 91G) Greek (models 91G) Russian (models 91G) Portuguese (models 91G) Turkish (models 91G) Czech (models 91G) Polish (models 91G) Russian English (models 91G) Arabic localized (models 91G) 53Y7248 Hebrew (models 91G) Hungarian (models 91G)
Page 141: Machine Type 7187
Machine Type 7187 Item # 7187 FRUs FRU # DVD-ROM 16X Max SATA (models A4J A5J A8J 91P 91G 91M 91A 91Q 91C 91B 41N3325 91H 91V 91K 91R) DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1J 43C1042 A3J A6J A7J ABJ ACJ ADS ADY 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R AFJ AGJ AHJ AJJ AEJ)
Page 142 Item # 7187 FRUs FRU # Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W 45C7735 C-0 (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W 45C7736 C-0 (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Microprocessor, Core 2 Duo E8300 Processor 2.83GHz 1333MHz FSB 6M L2 65W...
Page 143 Item # 7187 FRUs FRU # Microprocessor, E5300 Wolfdale 2.6GHz/800FSB 2MB EIST, EM64T, EDB R-0 53Y9049 (models AEJ) Microprocessor, E1500 Conroe 2.2GHZ/800FSB 512KB EIST, EM64T, EDB M-0 53Y9051 (models) Microprocessor, E5400 Wolfdale 2.7GHz/800FSB 2MB EIST, EM64T, EDB R-0 64Y1075 (models CTO) Memory module, 512 MB PC3-8500 1066MHz DDR3 SoDIMM (models 91P 91G 46R3324 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 144 Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 65W Heatsink kit (all models) 43N9427 7187 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5289...
Page 145 7187 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Thailand (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5324 Turkish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5325 Turkish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 146 41R0077 Slovenian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0078 7187 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 147 IEEE 1394 Firewire adapter (LP) (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 41D2781 91R) Speakers (2-piece) Lenovo Logo (Primary) (models 91P 91G 91M 91A 91Q 91C 91B 91H 41A5331 91V 91K 91R) Speakers (2-piece) Lenovo Logo (Secondary) (models 91P 91G 91M 91A 91Q 91C 91B 91H...
Page 148 7187 adapters and miscellaneous FRUs FRU # Speaker power brick -Taiwan - TC (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 41A4905 91R) Speaker power brick - India, South Africa (models 91P 91G 91M 91A 91Q 91C 91B 91H 89P8585 91V 91K 91R) Modem phone cable (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 149 7187 Windows XP Home Recovery CDs FRU # Danish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Dutch (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Arabic (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Swedish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Hebrew (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Finnish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 150 7187 Windows XP Pro Recovery CDs FRU # Czech (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7084 Turkish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7091 Greek (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7093 Slovakian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7095...
Page 151 7187 Windows Vista Home Basic 32 Recovery DVDs FRU # Hebrew (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7233 Arabic localized (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7231 Slovakian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7237 Romanian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7234...
Page 152 7187 Vista Business 32 Recovery DVDs FRU # Ukrainian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Slovakian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7179 Arabic localized (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7173 Hebrew (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7175...
Page 153 7187 Windows Vista Home Premium 32 Recovery DVDs FRU # Ukrainian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Slovakian (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 7187 Windows Vista Business 64 Recovery DVDs FRU # Russian English (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7250...
Page 154 7187 Windows Vista Ultimate 32 Recovery DVDs FRU # Danish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Swedish (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Finland (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Dutch (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Traditional Chinese (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Hong Kong (models 91P 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 155: Machine Type 7345
Machine Type 7345 Item # 7345 FRUs FRU # DVD-ROM 16X Max SATA (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 41N3325 91B 91H 91V 91K 91R) DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A3J 43C1042 A4J A5J A2J A1J 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 156 Item # 7345 FRUs FRU # Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W 45C7735 C-0 (models A4J A5J 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W 45C7736 C-0 (models A3J A2J A1J 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 157 Item # 7345 FRUs FRU # Microprocessor, E7400 Wolfdale 2.8GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0 53Y6653 (models) Microprocessor, E5300 Wolfdale 2.6GHz/800FSB 2MB EIST, EM64T, EDB R-0 53Y9049 (models) Microprocessor, E1500 Conroe 2.2GHZ/800FSB 512KB EIST, EM64T, EDB M-0 53Y9051 (models) Microprocessor, E5400 Wolfdale 2.7GHz/800FSB 2MB EIST, EM64T, EDB R-0 64Y1075 (models)
Page 158 Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 65W Heatsink kit (all models) 43N9427 7345 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5289...
Page 159 7345 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Russian/Cyrillic (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 41A5318 91R) Serbian/Cyrillic (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K...
Page 160 Slovenian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41R0078 7345 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 161 7345 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # Dutch (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 41A5049 French (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 162 IEEE 1394 Firewire adapter (LP) (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 41D2781 91H 91V 91K 91R) Speakers (2-piece) Lenovo Logo (Primary) (models 91S 91P 91L 91D 91Y 91G 91M 91A 41A5331 91Q 91C 91B 91H 91V 91K 91R)
Page 163 7345 Power Cords (Primary) FRU # Line Cord - Y model - Argentina (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 42T5102 91H 91V 91K 91R) Line Cord - Brazil (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 42T5177 91R) Line Cord - German (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V...
Page 164 7345 Windows XP Home Recovery CDs FRU # Norwegian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Polish (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Portuguese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Russian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Russian English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K...
Page 165 7345 Windows XP Pro Recovery CDs FRU # Greek (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7093 Slovakian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7095 Japanese (models A3J A4J 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 53Y7079...
Page 166 7345 Windows Vista Home Basic 32 Recovery DVDs FRU # Slovenian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7230 Russian English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 53Y7213 91R) Hebrew (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 167 7345 Vista Business 32 Recovery DVDs FRU # Korea (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7171 Slovenian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 53Y7172 Russian English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 53Y7155...
Page 168 7345 Windows Vista Home Premium 32 Recovery DVDs FRU # Simplified Chinese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Traditional Chinese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Hong Kong (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Korean (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 169 7345 Windows Vista Business 64 Recovery DVDs FRU # Korean (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Slovenian (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Portuguese (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Arabic (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Hebrew (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R)
Page 170 7345 Windows Vista Ultimate 32 Recovery DVDs FRU # C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91S 91P 91L 91D 53Y7249 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) 7345 Windows Vista Starter 32 Recovery DVDs FRU # English (models 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91C 91B 91H 91V 91K 91R) Hardware Maintenance Manual...
Page 171: Machine Type 7348
Machine Type 7348 Item # 7348 FRUs FRU # DVD-ROM 16X Max SATA (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41N3325 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1G 43C1042 91G 91M 91A 91Q 91C 91B 91H 91V) 130W AC/DC Power Adapter WW, Robust, JP (models A1G) 41A9767 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models 91G 91M 91A 91Q...
Page 172 Item # 7348 FRUs FRU # Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W 45C7736 C-0 (models 91G 91M 91A 91Q 91C 91B 91H 91V) Microprocessor, Core 2 Duo E8300 Processor 2.83GHz 1333MHz FSB 6M L2 65W 45C7737 C-0 (models 91G 91M 91A 91Q 91C 91B 91H 91V) Microprocessor, Core 2 Duo E8200 Processor 2.66GHz 1333MHz FSB 6M L2 65W...
Page 173 Item # 7348 FRUs FRU # Microprocessor, E5400 Wolfdale 2.7GHz/800FSB 2MB EIST, EM64T, EDB R-0 64Y1075 (models) Memory module, 512 MB PC3-8500 1066MHz DDR3 SoDIMM (models 91G 91M 46R3324 91A 91Q 91C 91B 91H 91V) Memory module, 1GB PC3-8500 1066MHz DDR3 SoDIMM (models 91G 91M 91A 46R3325 91Q 91C 91B 91H 91V) Memory module, 2GB PC3-8500 1066MHz DDR3 SoDIMM (models A1G 91G 91M...
Page 174 7348 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5289 Arabic (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5290 Arabic/French (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 175 7348 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Arabic (New) (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 45J4880 Lithuanian (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 45J4896 7348 Keyboards (Lenovo Fingerprint Reader USB)
Page 176 US Euro (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0077 Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0078 7348 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5039...
Page 177 IEEE 1394 Firewire adapter (LP) (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41D2781 Speakers (2-piece) Lenovo Logo (Primary) (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5331 Speakers (2-piece) Lenovo Logo (Secondary) (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 178 7348 Power Cords (Primary) FRU # Line Cord - Y model - Argentina (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5102 Line Cord - Brazil (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5177 Line Cord - German (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5114 Line Cord - UK (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5120...
Page 179 7348 Windows XP Home Recovery CDs FRU # Hong Kong - Traditional Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) Korean (models 91G 91M 91A 91Q 91C 91B 91H 91V) 7348 Windows XP Pro Recovery CDs FRU # US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7073 French/Canadian French (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 180 7348 Windows Vista Home Basic 32 Recovery DVDs FRU # Brazilian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7217 Italian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y9470 Japanese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7225 Norwegian (models 91G 91M 91A 91Q 91C 91B 91H 91V) Swedish (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 181 7348 Vista Business 32 Recovery DVDs FRU # Swedish (models 91G 91M 91A 91Q 91C 91B 91H 91V) Danish (models 91G 91M 91A 91Q 91C 91B 91H 91V) Dutch (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7174 Czech (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7161 Finnish (models 91G 91M 91A 91Q 91C 91B 91H 91V) Polish (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 182 7348 Windows Vista Home Premium 32 Recovery DVDs FRU # Danish (models 91G 91M 91A 91Q 91C 91B 91H 91V) Dutch (models 91G 91M 91A 91Q 91C 91B 91H 91V) Czech (models 91G 91M 91A 91Q 91C 91B 91H 91V) Finnish (models 91G 91M 91A 91Q 91C 91B 91H 91V) Polish (models 91G 91M 91A 91Q 91C 91B 91H 91V) Russian (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 183 7348 Windows Vista Business 64 Recovery DVDs FRU # Greek (models 91G 91M 91A 91Q 91C 91B 91H 91V) Simplified Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7254 Traditional Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) Hong Kong (models 91G 91M 91A 91Q 91C 91B 91H 91V) Korean (models 91G 91M 91A 91Q 91C 91B 91H 91V) Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 184 7348 Windows Vista Ultimate 32 Recovery DVDs FRU # C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91G 91M 91A 91Q 53Y7249 91C 91B 91H 91V) 7348 Windows Vista Starter 32 Recovery DVDs FRU # English (models 91G 91M 91A 91Q 91C 91B 91H 91V) Hardware Maintenance Manual...
Page 185: Machine Type 7356
Machine Type 7356 Item # 7356 FRUs FRU # DVD-ROM 16X Max SATA (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41N3325 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1G) 43C1042 130W AC/DC Power Adapter WW, Robust, JP (models A1G) 41A9767 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models 91G 91M 91A 91Q 40Y9035...
Page 186 Item # 7356 FRUs FRU # Microprocessor, Core 2 Duo E8300 Processor 2.83GHz 1333MHz FSB 6M L2 65W 45C7737 C-0 (models 91G 91M 91A 91Q 91C 91B 91H 91V) Microprocessor, Core 2 Duo E8200 Processor 2.66GHz 1333MHz FSB 6M L2 65W 45C7738 C-0 (models 91G 91M 91A 91Q 91C 91B 91H 91V) Microprocessor, E8190 Wolfdale 2.66GHz 1333MHz FSB 6M C-0 - NON VT/Vpro...
Page 187 Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 65W Heatsink kit (all models) 43N9427 7356 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5289...
Page 188 7356 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Arabic (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5290 Arabic/French (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5291 Belgian/French (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 189 7356 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Lithuanian (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 45J4896 7356 Keyboards (Lenovo Fingerprint Reader USB) FRU # US English (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 190 US Euro (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0077 Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41R0078 7356 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5039...
Page 191 IEEE 1394 Firewire adapter (LP) (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41D2781 Speakers (2-piece) Lenovo Logo (Primary) (models 91G 91M 91A 91Q 91C 91B 91H 91V) 41A5331 Speakers (2-piece) Lenovo Logo (Secondary) (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 192 7356 Power Cords (Primary) FRU # Line Cord - Y model - Argentina (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5102 Line Cord - Brazil (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5177 Line Cord - German (models 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5114 Line Cord - UK (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 42T5120...
Page 193 7356 Windows XP Home Recovery CDs FRU # Hong Kong - Traditional Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) Korean (models 91G 91M 91A 91Q 91C 91B 91H 91V) 7356 Windows XP Pro Recovery CDs FRU # US English (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7073 French/Canadian French (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 194 7356 Windows Vista Home Basic 32 Recovery DVDs FRU # Brazilian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7217 Italian (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y9470 Japanese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7225 Norwegian (models 91G 91M 91A 91Q 91C 91B 91H 91V) Swedish (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 195 7356 Vista Business 32 Recovery DVDs FRU # Swedish (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) Danish (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) Dutch (models A1G 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7174 Czech (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7161...
Page 196 7356 Windows Vista Home Premium 32 Recovery DVDs FRU # Danish (models 91G 91M 91A 91Q 91C 91B 91H 91V) Dutch (models 91G 91M 91A 91Q 91C 91B 91H 91V) Czech (models 91G 91M 91A 91Q 91C 91B 91H 91V) Finnish (models 91G 91M 91A 91Q 91C 91B 91H 91V) Polish (models 91G 91M 91A 91Q 91C 91B 91H 91V) Russian (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 197 7356 Windows Vista Business 64 Recovery DVDs FRU # Greek (models 91G 91M 91A 91Q 91C 91B 91H 91V) Simplified Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) 53Y7254 Traditional Chinese (models 91G 91M 91A 91Q 91C 91B 91H 91V) Hong Kong (models 91G 91M 91A 91Q 91C 91B 91H 91V) Korean (models 91G 91M 91A 91Q 91C 91B 91H 91V) Slovenian (models 91G 91M 91A 91Q 91C 91B 91H 91V)
Page 198 7356 Windows Vista Ultimate 32 Recovery DVDs FRU # C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91G 91M 91A 91Q 53Y7249 91C 91B 91H 91V) 7356 Windows Vista Starter 32 Recovery DVDs FRU # English (models 91G 91M 91A 91Q 91C 91B 91H 91V) Hardware Maintenance Manual...
Page 199: Machine Type 7359
Machine Type 7359 Item # 7359 FRUs FRU # DVD-ROM 16X Max SATA (models A6U A6F A6M A6A A6Q A6T A6H A6K AKM 41N3325 AKA AKQ AKT AKK ANM ANA ANQ ANT ANK ADU ADF AEU AEF AHV A1G A7S A7P A7Y 91C B1U B1F B3U B3F B5U B5F) DVD recordable SATA/CD-RW Rambo 8 - SATA Vista &...
Page 200 Item # 7359 FRUs FRU # System fan assembly (all models) 43N9655 Microprocessor, Core 2 Duo E4600 Processor 2.40GHz 800MHz FSB 2M L2 M-0 45C5282 Stepping Level, Mainstream/Value FMB (models 91C) Microprocessor, E4700 Conroe 2.60GHz 800MHz FSB 2M (models 91C) 45R5786 Microprocessor, E8600 Wolfdale, 3.33GHZ,1333M FSB 6M E-0 (models 91C) 46R8640...
Page 201 Item # 7359 FRUs FRU # Microprocessor, E7400 Wolfdale 2.8GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0 53Y6653 (models ATM ATA AUM AUA AUQ AUT AUK AWG B1U B1F B2U B2F B6U B6F B6S B6P B6L B6D B6Y B6G B6M B6A B6Q B6T B6C B6B B6H B6V B6K B6R B6E B6J) Microprocessor, E5300 Wolfdale 2.6GHz/800FSB 2MB EIST, EM64T, EDB R-0 53Y9049...
Page 202 Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 65W Heatsink kit (all models) 43N9427 7359 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models A5H A6U A6M A6A A6Q A6H A8M A8A A8Q A9M A9A A9Q AJM 41A5289...
Page 203 7359 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Japanese (models 91C B6J) 41A5310 Korean (models A6K A8K A9K AJK AKK ALK ANK 91C AVK AUK B7K B6K) 41A5311 LA Spanish (models A7S A7Y 91C B6S B6D B6Y)
Page 204 Turkish (models 91C) 41R0075 UK English (models 91C) 41R0076 US Euro (models 91C) 41R0077 Slovenian (models 91C) 41R0078 7359 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91C) 41A5039 Arabic (models 91C) 41A5040 Arabic/French (models 91C) 41A5041...
Page 205 7359 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # Greek (models 91C) 41A5054 Greek/US (models 91C) 41A5080 Hebrew (models 91C) 41A5055 Hungarian (models 91C) 41A5056 Iceland (models 91C) 41A5057 Italian (models 91C) 41A5058 Japanese (models 91C) 41A5059 Korean (models 91C)
Page 206 DP to DVI dongle 200 mm (models CTO 91C) 43N9160 IEEE 1394 Firewire adapter (LP) (models CTO 91C) 41D2781 Speakers (2-piece) Lenovo Logo (Primary) (models 91C) 41A5331 Speakers (2-piece) Lenovo Logo (Secondary) (models 91C) 41A5334 Speaker power brick - US, Canada, LA low voltage, ASEAN (models A6U ABU ADU AEU...
Page 207 7359 Power Cords (Primary) FRU # Line Cord - South Africa (models A6U A6F A6A A6T A8A A8T A9A A9T AJA AJT AKA 42T5141 AKT ALA ALT AMA ANA ANT AQA ABU ABF ADU ADF AEU AEF AFU AFF AGU AGF A7S A7Y ABU ABF 91C AVM AVA ATM ATA AUM AUA ARM ARA B7M B7A AWG B6G B6M B6A) Line Cord - Israel (models ACG A1G A2G A3G A4G 91C AWG B6G)
Page 208 7359 Windows XP Pro Recovery CDs FRU # US English (models AJM AJA AJQ AMM AMA AQM AQA 91C ATM ATA ARM ARA B1U 53Y7073 B2U B3U B4U B5U B8U) French/Canadian French (models 91C B1F B2F B3F B4F B5F B8F) 53Y7074 German (models 91C) 53Y7075...
Page 209 7359 Windows Vista Home Basic 32 Recovery DVDs FRU # Swedish (models 91C) Danish (models 91C) Dutch (models 91C) 53Y7232 Czech (models 91C) 53Y7219 Finnish (models 91C) Polish (models 91C) 53Y7220 Russian (models 91C) 53Y7221 Turkish (models 91C) 53Y7222 Hungarian (models 91C) 53Y7223 Greek (models 91C) 53Y7224...
Page 210 7359 Vista Business 32 Recovery DVDs FRU # Czech (models 91C) 53Y7161 Finnish (models ACG A1G A2G A3G A4G 91C AWG B6G) Polish (models ACG A1G A2G A3G A4G 91C AWG B6G) 53Y7162 Russian (models ACG A1G A2G A3G A4G 91C AWG B6G) 53Y7163 Turkish (models ACG A1G A2G A3G A4G 91C AWG B6G) 53Y7164...
Page 211 7359 Windows Vista Home Premium 32 Recovery DVDs FRU # Russian (models 91C) Turkish (models 91C) Hungarian (models 91C) Greek (models 91C) Simplified Chinese (models 91C) Traditional Chinese (models 91C) Hong Kong (models 91C) Korean (models 91C) Slovenian (models 91C) Hebrew (models 91C) Romanian (models 91C) Bulgarian (models 91C)
Page 212 7359 Windows Vista Business 64 Recovery DVDs FRU # Slovenian (models 91C) Portuguese (models 91C) Arabic (models 91C) Hebrew (models 91C) Slovakian (models 91C) 7359 Windows Vista Ultimate 32 Recovery DVDs FRU # English (models 91C) 53Y7241 Japanese (models 91C) 53Y7246 Simplified Chinese (models 91C) French (models 91C)
Page 213: Machine Type 7479
Machine Type 7479 Item # 7479 FRUs FRU # DVD-ROM 16X Max SATA (models A9U A9F A4U A4F A4S A4P A4Y 91C 91B 41N3325 91H) DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A5M 43C1042 A5A A5Q A5T A5K A7M A7A A7Q A7T A7K AEM AEA AFM AFA AFQ AFT AFK AGM AGA AGQ AGT AGK A8U A8F ABU ABF ACU ACF A3U A3F A3S A3P A3L A3D A3Y ADV A1G A2G AHS AHP AHY A6U A6F 91C 91B 91H AJU AJF AKU AKF)
Page 214 Item # 7479 FRUs FRU # Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W 45C7735 C-0 (models AFM AFA AFQ AFT AFK AGM AGA AGQ AGT AGK A9U A9F ABU ABF ACU ACF A2G CTO 91C 91B 91H AKU AKF) Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W 45C7736 C-0 (models A5M A5A A5Q A5T A5K A7M A7A A7Q A7T A7K AEM AEA A8U...
Page 215 Item # 7479 FRUs FRU # Microprocessor, E5400 Wolfdale 2.7GHz/800FSB 2MB EIST, EM64T, EDB R-0 64Y1075 (models) Memory module, 1GB PC3-8500 1066MHz DDR3 SoDIMM (models A5M A5A 46R3325 A5Q A5T A5K AEM AEA AFM AFA AFQ AFT AFK AGM AGA AGQ AGT AGK A8U A8F A9U A9F ABU ABF ACU ACF A3U A3F A3S A3P A3L A3D A3Y ADV A4U A4F A4S A4P A4Y AHS AHP AHY CTO 91C 91B 91H) Memory module, 2GB PC3-8500 1066MHz DDR3 SoDIMM (models A7M A7A...
Page 216 7479 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models A5M A5A A5Q A7M A7A A7Q AEM AEA AFM AFA AFQ AGM AGA 41A5289 AGQ A8U A9U ABU ACU A3U A3L A1G A2G A4U A6U 91C 91B 91H AJU AKU)
Page 217 7479 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US Euro (models A1G A2G 91C 91B 91H) 41A5328 Slovenian (models A1G A2G 91C 91B 91H) 41A5329 Arabic (New) (models A1G A2G 91C 91B 91H) 45J4880 Lithuanian (models A1G A2G 91C 91B 91H)
Page 218 UK English (models 91C 91B 91H) 41R0076 US Euro (models 91C 91B 91H) 41R0077 Slovenian (models 91C 91B 91H) 41R0078 7479 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91C 91B 91H) 41A5039 Arabic (models 91C 91B 91H) 41A5040...
Page 219 7479 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # Swiss French/German (models 91C 91B 91H) 41A5071 Thailand (models 91C 91B 91H) 41A5072 Turkish (models 91C 91B 91H) 41A5073 Turkish (models 91C 91B 91H) 41A5074 UK English (models 91C 91B 91H)
Page 220 7479 Power Cords (Primary) FRU # Line Cord - US/Canada (models A5A A5T A7A A7T AEA AFA AFT AGA AGT A8U A8F 42T5089 A9U A9F ABU ABF ACU ACF A3U A3F A3S A3L A3Y A4U A4F A4S A4Y AHS AHY A6U A6F 91C 91B 91H AJU AJF AKU AKF) Line Cord - Japan (models 91C 91B 91H) 42T5096...
Page 221 7479 Windows XP Home Recovery CDs FRU # Russian English (models 91C 91B 91H) Hungarian (models 91C 91B 91H) Czech (models 91C 91B 91H) Turkish (models 91C 91B 91H) Greek (models 91C 91B 91H) Japanese (models 91C 91B 91H) Simplified Chinese (models 91C 91B 91H) Taiwan - Traditional Chinese (models 91C 91B 91H) Hong Kong - Traditional Chinese (models 91C 91B 91H) Korean (models 91C 91B 91H)
Page 222 7479 Windows Vista Home Basic 32 Recovery DVDs FRU # US English (models 91C 91B 91H) 53Y7212 French/Canadian French (models 91C 91B 91H) 53Y7214 German (models 91C 91B 91H) 53Y7215 Spanish/LA (models 91C 91B 91H) 53Y7216 Brazilian (models 91C 91B 91H) 53Y7217 Italian (models 91C 91B 91H) 53Y9470...
Page 223 7479 Vista Business 32 Recovery DVDs FRU # Spanish (models A1G A2G 91C 91B 91H) 53Y7158 Brazilian Portuguese (models A3P A4P 91C 91B 91H) 53Y7159 Italian (models A1G A2G 91C 91B 91H) 53Y9468 Japanese (models 91C 91B 91H) 53Y7167 Norwegian (models A1G A2G 91C 91B 91H) Swedish (models A1G A2G 91C 91B 91H) Danish (models A1G A2G 91C 91B 91H) Dutch (models A1G A2G 91C 91B 91H)
Page 224 7479 Windows Vista Home Premium 32 Recovery DVDs FRU # Japanese (models 91C 91B 91H) Norwegian (models 91C 91B 91H) Swedish (models 91C 91B 91H) Danish (models 91C 91B 91H) Dutch (models 91C 91B 91H) Czech (models 91C 91B 91H) Finnish (models 91C 91B 91H) Polish (models 91C 91B 91H) Russian (models 91C 91B 91H)
Page 225 7479 Windows Vista Business 64 Recovery DVDs FRU # Russian (models 91C 91B 91H) Turkish (models 91C 91B 91H) Hungarian (models 91C 91B 91H) Greek (models 91C 91B 91H) Simplified Chinese (models 91C 91B 91H) 53Y7254 Traditional Chinese (models 91C 91B 91H) Hong Kong (models 91C 91B 91H) Korean (models 91C 91B 91H) Slovenian (models 91C 91B 91H)
Page 226 7479 Windows Vista Ultimate 32 Recovery DVDs FRU # Hungarian (models 91C 91B 91H) Slovakian (models 91C 91B 91H) C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91C 91B 91H) 53Y7249 7479 Windows Vista Starter 32 Recovery DVDs FRU # English (models 91C 91B 91H) Hardware Maintenance Manual...
Page 227: Machine Type 7626
Machine Type 7626 Item # 7626 FRUs FRU # DVD-ROM 16X Max SATA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 41N3325 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models 91U 43C1042 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 228 Item # 7626 FRUs FRU # Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W 45C7735 C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W 45C7736 C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 229 Item # 7626 FRUs FRU # Microprocessor, Q9550 Yorkfield 2.83GHz 1333FSB 12MB VT, TXT E-0 (models 91U 46R8646 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Microprocessor, Q8200 Yorkfield 2.33GHZ 1333FSB 4MB R-0 (models 91U 91F 91S 53Y3946 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Microprocessor, E7500 Wolfdale 2.93GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0...
Page 230 Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 65W Heatsink kit (all models) 43N9427 7626 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 41A5289...
Page 231 7626 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Hebrew (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 41A5306 91K 91R 91E 91J) Hungarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 232 7626 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Arabic (New) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 45J4880 91V 91K 91R 91E 91J) Lithuanian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 233 Slovenian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 41R0078 91K 91R 91E 91J) 7626 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 234 7626 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # Belgian/French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 41A5042 91H 91V 91K 91R 91E 91J) Belgian/English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B...
Page 235 IEEE 1394 Firewire adapter (LP) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 41D2781 91T 91C 91B 91H 91V 91K 91R 91E 91J) Speakers (2-piece) Lenovo Logo (Primary) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 41A5331 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 236 7626 adapters and miscellaneous FRUs FRU # Speaker power brick - Simplified Chinese, Thailand, EMEA (models 91U 91F 91S 91P 91L 89P8581 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Speaker power brick - Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 89P8577 91T 91C 91B 91H 91V 91K 91R 91E 91J) Speaker power brick - Brazilian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q...
Page 237 7626 Power Cords (Primary) FRU # Line Cord - Italy (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 42T5132 91H 91V 91K 91R 91E 91J) Line Cord - Australia / New Zealand (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 42T5135 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Line Cord - South Africa (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T...
Page 238 7626 Windows XP Home Recovery CDs FRU # Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Russian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Russian English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 239 7626 Windows XP Pro Recovery CDs FRU # Finnish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 53Y7085 91K 91R 91E 91J) Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 53Y7080 91V 91K 91R 91E 91J) Polish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V...
Page 240 7626 Windows Vista Home Basic 32 Recovery DVDs FRU # Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 53Y9470 91K 91R 91E 91J) Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 53Y7225 91K 91R 91E 91J) Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 241 7626 Windows Vista Home Basic 32 Recovery DVDs FRU # Serbian-Latin (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 53Y7236 91V 91K 91R 91E 91J) C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91U 91F 91S 91P 53Y7238 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) C&L 2 Switzerland (English, French, German, Italian) (models 91U 91F 91S 91P 91L 91D...
Page 242 7626 Vista Business 32 Recovery DVDs FRU # Simplified Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 53Y7168 91H 91V 91K 91R 91E 91J) Traditional Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 53Y7169 91H 91V 91K 91R 91E 91J) Hong Kong (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 243 7626 Windows Vista Home Premium 32 Recovery DVDs FRU # Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Swedish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 244 7626 Windows Vista Home Premium 32 Recovery DVDs FRU # Slovakian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 7626 Windows Vista Business 64 Recovery DVDs FRU # Russian English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 53Y7250 91H 91V 91K 91R 91E 91J)
Page 245 7626 Windows Vista Business 64 Recovery DVDs FRU # Slovenian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Arabic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 246 7626 Windows Vista Ultimate 32 Recovery DVDs FRU # Russian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Turkish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 247: Machine Type 7629
Machine Type 7629 Item # 7629 FRUs FRU # DVD-ROM 16X Max SATA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 41N3325 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models 91U 43C1042 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 248 Item # 7629 FRUs FRU # Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W 45C7735 C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W 45C7736 C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 249 Item # 7629 FRUs FRU # Microprocessor, Q9550 Yorkfield 2.83GHz 1333FSB 12MB VT, TXT E-0 (models 91U 46R8646 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Microprocessor, Q8200 Yorkfield 2.33GHZ 1333FSB 4MB R-0 (models 91U 91F 91S 53Y3946 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Microprocessor, E7500 Wolfdale 2.93GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0...
Page 250 Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 65W Heatsink kit (all models) 43N9427 7629 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 41A5289...
Page 251 7629 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Hebrew (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 41A5306 91K 91R 91E 91J) Hungarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 252 7629 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Arabic (New) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 45J4880 91V 91K 91R 91E 91J) Lithuanian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 253 Slovenian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 41R0078 91K 91R 91E 91J) 7629 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 254 7629 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # Belgian/French (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 41A5042 91H 91V 91K 91R 91E 91J) Belgian/English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B...
Page 255 IEEE 1394 Firewire adapter (LP) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 41D2781 91T 91C 91B 91H 91V 91K 91R 91E 91J) Speakers (2-piece) Lenovo Logo (Primary) (models91U 91F 91S 91P 91L 91D 91Y 91G 91M 41A5331 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 256 7629 adapters and miscellaneous FRUs FRU # Speaker power brick - Simplified Chinese, Thailand, EMEA (models 91U 91F 91S 91P 91L 89P8581 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Speaker power brick - Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 89P8577 91T 91C 91B 91H 91V 91K 91R 91E 91J) Speaker power brick - Brazilian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q...
Page 257 7629 Power Cords (Primary) FRU # Line Cord - Italy (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 42T5132 91H 91V 91K 91R 91E 91J) Line Cord - Australia / New Zealand (models91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 42T5135 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Line Cord - South Africa (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T...
Page 258 7629 Windows XP Home Recovery CDs FRU # Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Russian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Russian English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 259 7629 Windows XP Pro Recovery CDs FRU # Finnish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 53Y7085 91K 91R 91E 91J) Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 53Y7080 91V 91K 91R 91E 91J) Polish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V...
Page 260 7629 Windows Vista Home Basic 32 Recovery DVDs FRU # Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 53Y9470 91K 91R 91E 91J) Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 53Y7225 91K 91R 91E 91J) Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 261 7629 Windows Vista Home Basic 32 Recovery DVDs FRU # Serbian-Latin (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 53Y7236 91V 91K 91R 91E 91J) C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91U 91F 91S 91P 53Y7238 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) C&L 2 Switzerland (English, French, German, Italian) (models 91U 91F 91S 91P 91L 91D...
Page 262 7629 Vista Business 32 Recovery DVDs FRU # Simplified Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 53Y7168 91H 91V 91K 91R 91E 91J) Traditional Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 53Y7169 91H 91V 91K 91R 91E 91J) Hong Kong (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 263 7629 Windows Vista Home Premium 32 Recovery DVDs FRU # Japanese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Swedish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 264 7629 Windows Vista Home Premium 32 Recovery DVDs FRU # Slovakian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) 7629 Windows Vista Business 64 Recovery DVDs FRU # Russian English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 53Y7250 91H 91V 91K 91R 91E 91J)
Page 265 7629 Windows Vista Business 64 Recovery DVDs FRU # Slovenian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Arabic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 266 7629 Windows Vista Ultimate 32 Recovery DVDs FRU # Russian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Turkish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 267: Machine Type 7637
Machine Type 7637 Item # 7637 FRUs FRU # DVD-ROM 16X Max SATA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 41N3325 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1U 43C1042 A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 268 Item # 7637 FRUs FRU # Microprocessor, E8600 Wolfdale, 3.33GHZ,1333M FSB 6M E-0 (models 91U 91F 91S 46R8640 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Microprocessor, Core 2 Duo E8500 Processor 3.16GHz 1333MHz FSB 6M L2 65W 45C7735 C-0 (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 269 Item # 7637 FRUs FRU # Microprocessor, Q9550 Yorkfield 2.83GHz 1333FSB 12MB VT, TXT E-0 (models 91U 46R8646 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Microprocessor, Q8200 Yorkfield 2.33GHZ 1333FSB 4MB R-0 (models 91U 91F 91S 53Y3946 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Microprocessor, E7500 Wolfdale 2.93GHZ/1066FSB 3M ViiV, EIST, EM64T, EDB R-0...
Page 270 Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 65W Heatsink kit (all models) 43N9427 7637 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models A1U A1L A1G A1M A1A A1Q A1H A1R A1E 91U 91F 91S 91P 91L 41A5289...
Page 271 7637 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # German (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 41A5303 91V 91K 91R 91E 91J) Greek (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 272 7637 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # UK English (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 41A5327 91H 91V 91K 91R 91E 91J) US Euro (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H...
Page 273 7637 Keyboards (Lenovo Fingerprint Reader USB) FRU # Hungarian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 41R0056 91V 91K 91R 91E 91J) Iceland (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V...
Page 274 7637 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 41A5039 91V 91K 91R 91E 91J) Arabic (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V...
Page 275 IEEE 1394 Firewire adapter (LP) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 41D2781 91T 91C 91B 91H 91V 91K 91R 91E 91J) Speakers (2-piece) Lenovo Logo (Primary) (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 41A5331 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 276 7637 adapters and miscellaneous FRUs FRU # Speakers (2-piece) Lenovo Logo (Secondary) (models 91U 91F 91S 91P 91L 91D 91Y 91G 41A5334 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Speaker power brick - US, Canada, LA low voltage, ASEAN (models 91U 91F 91S 91P 91L...
Page 277 7637 Power Cords (Primary) FRU # Line Cord - UK (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 42T5120 91H 91V 91K 91R 91E 91J) Line Cord - Denmark (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 42T5126 91C 91B 91H 91V 91K 91R 91E 91J) Line Cord - Switzerland (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q...
Page 278 7637 Windows XP Home Recovery CDs FRU # Finnish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Norwegian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Polish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 279 7637 Windows XP Pro Recovery CDs FRU # Arabic English (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 53Y7088 91V 91K 91R 91E 91J) Swedish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 53Y7081 91K 91R 91E 91J) Hebrew (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V...
Page 280 7637 Windows Vista Home Basic 32 Recovery DVDs FRU # German (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 53Y7215 91K 91R 91E 91J) Spanish/LA (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 53Y7216 91V 91K 91R 91E 91J) Brazilian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V...
Page 281 7637 Windows Vista Home Basic 32 Recovery DVDs FRU # Arabic localized (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 53Y7231 91H 91V 91K 91R 91E 91J) Slovakian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 53Y7237 91K 91R 91E 91J) Romanian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V...
Page 282 7637 Vista Business 32 Recovery DVDs FRU # Hungarian (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 53Y7165 91H 91V 91K 91R 91E 91J) Greek (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 53Y7166 91V 91K 91R 91E 91J) Portuguese (models A1G 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B...
Page 283 7637 Windows Vista Home Premium 32 Recovery DVDs FRU # Spanish (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Brazilian Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Italian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 284 7637 Windows Vista Home Premium 32 Recovery DVDs FRU # Portuguese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Serbian-Latin (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Ukrainian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 285 7637 Windows Vista Business 64 Recovery DVDs FRU # Traditional Chinese (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Hong Kong (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Korean (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 286 7637 Windows Vista Ultimate 32 Recovery DVDs FRU # Korean (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Slovenian (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J) Greek (models 91U 91F 91S 91P 91L 91D 91Y 91G 91M 91A 91Q 91T 91C 91B 91H 91V 91K 91R 91E 91J)
Page 287: Machine Type 8820
Machine Type 8820 Item # 8820 FRUs FRU # DVD-ROM 16X Max SATA (models A3U A3F) 41N3325 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A6G 43C1042 A7G A8U A8F A9U A9F ABG ACG ADU ADF AEU AEF) 130W AC/DC Power Adapter WW, Robust, JP (models A8U A8F A9U A9F ABG 41A9767 ACG ADU ADF AEU AEF)
Page 288 Item # 8820 FRUs FRU # Microprocessor, Core 2 Duo E8200 Processor 2.66GHz 1333MHz FSB 6M L2 65W 45C7738 C-0 (models) Microprocessor, E8190 Wolfdale 2.66GHz 1333MHz FSB 6M C-0 - NON VT/Vpro 45R2568 (models) Microprocessor, E7200 Wolfdale 2.53GHZ 1066MHZFSB 3MB M-0 (models) 45R8337 Microprocessor, E7300 Wolfdale 2.66GHZ 1066FSB FSB 3MB M-0 (models A6G 46R1622...
Page 289 Universal Adapter Bracket 5.25 to 3.5 W/Bezel (all models) 43N9679 65W Heatsink kit (all models) 43N9427 8820 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models A5G A5H A6G A7GA8U A9U ABG ACG ADU AEU) 41A5289...
Page 290 8820 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # French Canadian (models A5G A6G A7GA8F A9F ABG ACG ADF AEF) 41A5301 French Canadian (models A5G A6G A7GA8F A9F ABG ACG ADF AEF) 41A5302 German (models A5G A6G A7GABG ACG)
Page 291 Turkish (models) 41R0074 Turkish (models) 41R0075 UK English (models) 41R0076 US Euro (models) 41R0077 Slovenian (models) 41R0078 8820 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models) 41A5039 Arabic (models) 41A5040 Arabic/French (models) 41A5041 Belgian/French (models) 41A5042...
Page 292 8820 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # Bulgarian (models) 41A5045 Chinese/US (models) 41A5046 Czech (models) 41A5047 Danish (models) 41A5048 Dutch (models) 41A5049 French (models) 41A5050 French Canadian (models) 41A5051 French Canadian (models) 41A5052 German (models) 41A5053...
Page 293 DP to DVI dongle 200 mm (models) 43N9160 IEEE 1394 Firewire adapter (LP) (models) 41D2781 Speakers (2-piece) Lenovo Logo (Primary) (models) 41A5331 Speakers (2-piece) Lenovo Logo (Secondary) (models) 41A5334 Speaker power brick - US, Canada, LA low voltage, ASEAN (models A3U A4U)
Page 294 8820 Windows XP Home Recovery CDs FRU # US English/UK/Asia Pacific (models) French/Canadian French (models) German (models) Italian (models) Brazilian (models) Spanish/LA (models) Danish (models) Dutch (models) Arabic (models) Swedish (models) Hebrew (models) Finnish (models) Norwegian (models) Polish (models) Portuguese (models) Russian (models) Russian English (models) Hungarian (models)
Page 295 8820 Windows XP Pro Recovery CDs FRU # Polish (models A6GACG) 53Y7087 Portuguese (models A6GACG) 53Y7094 Russian (models A6GACG) 53Y7089 Russian English (models A6GACG) 63Y8271 Hungarian (models A6GACG) 53Y7092 Czech (models A6GACG) 53Y7084 Turkish (models A6GACG) 53Y7091 Greek (models A6GACG) 53Y7093 Slovakian (models A6GACG) 53Y7095...
Page 296 8820 Windows Vista Home Basic 32 Recovery DVDs FRU # Slovenian (models) 53Y7230 Russian English (models) 53Y7213 Hebrew (models) 53Y7233 Arabic localized (models) 53Y7231 Slovakian (models) 53Y7237 Romanian (models) 53Y7234 Serbian-Latin (models) 53Y7236 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models) 53Y7238 C&L 2 Switzerland (English, French, German, Italian) (models) 53Y7239...
Page 297 8820 Vista Business 32 Recovery DVDs FRU # Slovakian (modelsABG) 53Y7179 Arabic localized (modelsABG) 53Y7173 Hebrew (modelsABG) 53Y7175 C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models) 53Y7180 C&L 2 Switzerland (English, French, German, Italian) (models) 53Y7181 C&L 3 Bel Lux (English, French, German, Dutch) (models) 53Y7182 8820 Windows Vista Home Premium 32 Recovery DVDs FRU #...
Page 298 8820 Windows Vista Business 64 Recovery DVDs FRU # Russian English (models) 53Y7250 Russian French (models) 53Y7251 German (models) 53Y7252 Spanish (models) Brazilian Portuguese (models) Italian (models) Japanese (models) 53Y7253 Norwegian (models) Swedish (models) Danish (models) Dutch (models) Czech (models) Finnish (models) Polish (models) Russian (models)
Page 299 8820 Windows Vista Ultimate 32 Recovery DVDs FRU # Traditional Chinese (models) Hong Kong (models) 53Y7247 Norwegian (models) Korean (models) Slovenian (models) Greek (models) Russian (models) Portuguese (models) Turkish (models) Czech (models) Polish (models) Russian English (models) Arabic localized (models) 53Y7248 Hebrew (models) Hungarian (models)
Page 300: Machine Type 9961
Machine Type 9961 Item # 9961 FRUs FRU # DVD-ROM 16X Max SATA (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41N3325 DVD recordable SATA/CD-RW Rambo 8 - SATA Vista & non-Vista (models A1U 43C1042 A1F 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V A3U A3F) 130W AC/DC Power Adapter WW, Robust, JP (models A3U A3F) 41A9767 Hard disk drive, SATA 160GB 7200RPM/3Gb/8MB (models A1U A1F 91S 91P 91L...
Page 301 Item # 9961 FRUs FRU # Microprocessor, Core 2 Duo E8400 Processor 3.00GHz 1333MHz FSB 6M L2 65W 45C7736 C-0 (models A1U A1F 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Microprocessor, Core 2 Duo E8300 Processor 2.83GHz 1333MHz FSB 6M L2 65W 45C7737 C-0 (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Microprocessor, Core 2 Duo E8200 Processor 2.66GHz 1333MHz FSB 6M L2 65W...
Page 302 Item # 9961 FRUs FRU # Microprocessor, E5400 Wolfdale 2.7GHz/800FSB 2MB EIST, EM64T, EDB R-0 64Y1075 (models) Memory module, 1GB PC3-8500 1066MHz DDR3 SoDIMM (models A1U A1F 91S 46R3325 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Memory module, 2GB PC3-8500 1066MHz DDR3 SoDIMM (models 91S 91P 91L 46R3326 91D 91Y 91G 91C 91B 91H 91V A3U A3F) System board, GA Intel Q45 (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V...
Page 303 9961 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # US English (models A1U 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V A3U) 41A5289 Arabic (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5290...
Page 304 9961 Keyboards (Lenovo Preferred Pro USB - without hub) FRU # Arabic (New) (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 45J4880 Lithuanian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 45J4896 9961 Keyboards (Lenovo Fingerprint Reader USB)
Page 305 US Euro (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41R0077 Slovenian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41R0078 9961 Keyboards (Lenovo Preferred Pro PS/2 - Full Size) FRU # US English (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41A5039...
Page 306 43N9160 IEEE 1394 Firewire adapter (LP) (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 41D2781 Speakers (2-piece) Lenovo Logo (Primary) (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 41A5331 91V) Speakers (2-piece) Lenovo Logo (Secondary) (models 91S 91P 91L 91D 91Y 91G 91C 91B...
Page 307 9961 Power Cords (Primary) FRU # Line Cord - US/Canada (models A1U A1F A2U A2F 91S 91P 91L 91D 91Y 91G 91C 91B 42T5089 91H 91V A3U A3F) Line Cord - Japan (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 42T5096 Line Cord - Y model - Argentina (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 42T5102...
Page 308 9961 Windows XP Home Recovery CDs FRU # Greek (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Japanese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Simplified Chinese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Taiwan - Traditional Chinese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Hong Kong - Traditional Chinese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Korean (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V)
Page 309 9961 Windows Vista Home Basic 32 Recovery DVDs FRU # US English (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7212 French/Canadian French (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7214 German (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7215 Spanish/LA (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7216...
Page 310 9961 Vista Business 32 Recovery DVDs FRU # Brazilian Portuguese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7159 Italian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y9468 Japanese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) 53Y7167 Norwegian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Swedish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V)
Page 311 9961 Windows Vista Home Premium 32 Recovery DVDs FRU # Italian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Japanese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Norwegian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Swedish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Danish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Dutch (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V)
Page 312 9961 Windows Vista Business 64 Recovery DVDs FRU # Polish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Russian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Turkish (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Hungarian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Greek (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Simplified Chinese (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V)
Page 313 9961 Windows Vista Ultimate 32 Recovery DVDs FRU # Hebrew (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Hungarian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) Slovakian (models 91S 91P 91L 91D 91Y 91G 91C 91B 91H 91V) C&L 1 Nordics (English, Danish, Finnish, Norwegian, Swedish) (models 91S 91P 91L 91D 53Y7249 91Y 91G 91C 91B 91H 91V)
Page 314 Hardware Maintenance Manual...
Page 315: Chapter 10. Additional Service Information
BIOS available for the computer, and where to obtain the latest level of BIOS. v To determine the current level of BIOS: – Start the Setup Utility. – See BIOS Revision Level on the Main setup screen. © Copyright Lenovo 2008, 2009...
Page 316: Updating (Flashing) Bios From A Disc
Sources for obtaining the latest level BIOS available 1. Lenovo support web site: http://www.lenovo.com/support/ 2. Lenovo Customer Support Center 3. Levels 1 and 2 Support To update (flash) the BIOS, see “Updating (flashing) BIOS from a disc.” Updating (flashing) BIOS from a disc This section provides instructions on how to update (flash) BIOS from a disc.
Page 317: Power Management
10. The recovery session will take two to three minutes. During this time you will hear a series of beeps. After the update session is completed, there will be no video, the series of beeps will end, and the system will automatically turn off. Remove the disc from the optical drive before the system completely turns off.
Page 318 Hardware Maintenance Manual...
Page 319 Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk.
Page 320: Television Output Notice
Macrovision Corporation. Reverse engineering or disassembly is prohibited. Trademarks The following terms are trademarks of Lenovo in the United States, other countries, or both: Lenovo PS/2 Rescue and Recovery...
Page 322 Part Number: 53Y6832 Printed in USA (1P) P/N: 53Y6832...

This manual is also suitable for:

Thinkcentre 6139 Thinkcentre 7356 Thinkcentre 7359 Thinkcentre 7479 Thinkcentre 7626 Thinkcentre 7629 ... Show all

Lenovo ThinkCentre 6136 Hardware Maintenance Manual

Chapter 1. About this Manual

Chapter 2. Safety Information

Chapter 3. General Information

Chapter 4. General Checkout

Chapter 5. Diagnostics

Chapter 6. Using the Setup Utility

Chapter 7. Symptom-To-FRU Index

Chapter 8. Replacing Frus

Chapter 9. FRU Lists

Chapter 10. Additional Service Information

Quick Links

Related Manuals for Lenovo ThinkCentre 6136

Summary of Contents for Lenovo ThinkCentre 6136

This manual is also suitable for:

Table of Contents
