Z97E-ITX/ac
Vcore Voltage Additional Offset
Configure the dynamic Vcore voltage added to the Vcore.
CPU Cache Override Voltage
Add voltage to the CPU Cache when the system is under heavy load.
CPU Cache Voltage Offset
Configure the voltage for the CPU Cache. Setting the voltage higher may increase
system stability when overclocking.
System Agent Voltage Offset
Configure the voltage for the System Agent. Setting the voltage higher may increase system
stability when overclocking.
CPU Analog IO Voltage Offset
CPU I/O Analog Voltage.
CPU Digital IO Voltage Offset
CPU I/O Digital Voltage.
CPU Integrated VR Faults
Disable FIVR Faults to raise the threshold to trigger CPU over current protection
and over voltage protection for better overclocking capabilities.
CPU Integrated VR Efficiency Mode
Enable FIVR Efficiency Management for power saving. Disable for better
performance and overclocking capabilities.

Voltage Configuration

CPU Input Voltage
Configure the voltage for the CPU.
CPU Load-Line Calibration
CPU Load-Line Calibration helps prevent CPU voltage droop when the system is
under heavy load.
CPU Input Offset
The fixed external voltage input to the CPU.
DRAM Voltage
