LG MS-1983ALB Service Manual

Microwave oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

MICROWAVE OVEN

SERVICE MANUAL
MODEL: MS-1983ALB
CAUTION
BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : 3828W5S3803
Website: http://biz.lgservice.com
Printed in Korea
May, 2004

Advertisement

Table of Contents
loading

Related Manuals for LG MS-1983ALB

Summary of Contents for LG MS-1983ALB

  • Page 1: Microwave Oven

    Website: http://biz.lgservice.com MICROWAVE OVEN SERVICE MANUAL MODEL: MS-1983ALB CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. May, 2004 Printed in Korea P/NO : 3828W5S3803...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS This device is to be serviced only by properly qualified service personnel. Consult the service manual for proper service procedures to assure continued safety operation and for precautions to be taken to avoid possible exposure to excessive microwave energy. PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY...

  • Page 3: Table Of Contents

    CONTENTS (Page) SAFETY PRECAUTIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Inside front cover SPECIFICATIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1 CAUTIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1 INSTALLATIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-1...

  • Page 4: Specifications

    SPECIFICATIONS ITEM DESCRIPTION MODEL MS-1983ALB Power Requirement 230/240 Volts AC 50 Hz 1,200 Watts Single phase, 3 wire grounded Power Output 800 Watts full microwave power (IEC60705) Microwave Frequency 2,450 MHz Magnetron 2M214 - 240GP Timer 10 sec. ~ 99 min.

  • Page 5: Cautions

    CAUTIONS Unlike other appliances, the microwave oven is MICROWAVE RADIATION high-voltage and high-current equipment. Personnel should not be exposed to the Though it is free from danger in ordinary use, microwave energy which may radiate from the extreme care should be taken during repair. magnetron or other microwave generating device if it is improperly used or connection.

  • Page 6: Installations

    INSTALLATIONS BEFORE YOU BEGIN, READ THE FOLLOWING INSTRUCTIONS COMPLETELY AND CAREFULLY. INSTALLING EARTHING INSTRUCTIONS 1. Empty the microwave oven and clean inside it with This microwave oven is designed to be used in a fully a soft, damp cloth. Check for damage such as earthed condition.

  • Page 7: Operating Instructions

    OPERATING INSTRUCTIONS FEATURES Oven Front Plate Window Door Screen Door Seal Control Panel Safety Door Lock System Turntable Roller Rest CONTROL PANEL 1. POWER: Used to select the desired power level for cooking. 2. AUTO DEFROST(LESS): Used to select the auto defrost and decrease the cooking time.

  • Page 8: Operating Sequence

    OPERATING SEQUENCE The following is a description of component functions during oven operation. 7. CHILD LOCK 1. SETTING THE CLOCK This oven has a CHILD LOCK feature. STOP/CLEAR CLOCK TIME (hour) CLOCK TO SET CHILD LOCK • Touch the STOP/CLEAR pad •...

  • Page 9: Schematic Diagram

    SCHEMATIC DIAGRAM...

  • Page 10: Circuit Description

    CIRCUIT DESCRIPTION • A high voltage of approximately 2100 volts AC is GENERAL DETAILS generated in the secondary of the high voltage • The low voltage transformer supplies the necessary transformer which is increased by the action of the high voltage to the micom controller when power cord is voltage diode and charging of the high voltage plugged in.

  • Page 11: Service Information

    SERVICE INFORMATION TOOLS AND MEASURING INSTRUMENTS NECESSARY TOOLS NECESSARY MEASURING INSTRUMENTS Tools normally used for TV servicing are sufficient. • TESTER(VOLTS-DC, AC., Ohmmeter) Standard tools are listed below. • Microwave survey meter • Diagonal pliers - Holaday HI-1500 • Long nose pliers HI-1501 •...
  • Page 12 MEASUREMENT WITH OUTER CASE NOTES WHEN MEASURING REMOVED • Do not exceed meter full scale deflection. • The test probe must be removed no faster than • When you replace the magnetron, measure for 1 inch/sec (2.5 cm/sec) along the shaded area, microwave energy leakage before the outer case is otherwise a false reading may result.

  • Page 13: Measurement Of Microwave Power Output

    MEASUREMENT OF MICROWAVE POWER OUTPUT • Microwave power output measurement is made with • The microwave power output P in watts is calculated the microwave oven supplied at its rated voltage and from the following formula: operated at its maximum microwave power setting with 4187 x (∆T) a load of (1000 ±...

  • Page 14: Diode Removal

    D. DOOR GROSS ASSEMBLY REMOVAL E. HIGH VOLTAGE TRANSFORMER REMOVAL 1) Open the door. 2) Pull out the door protector very carefully with a flat- 1) Discharge the high voltage capacitor. blade screwdriver. 2) Disconnect the leadwire from magnetron, high voltage CAUTION : Be careful not to damage door seal plate transformer, and capacitor.
  • Page 15 H. AIR DUCT ASSEMBLY REMOVAL J. REMOVING THE TURNTABLE MOTOR 1) Disconnect the leadwire from the lamp. 1) Remove the turntable. 2) Remove the mounting screw to the latch board. 2) Remove the turntable shaft VERY CAREFULLY. 3) Lay the unit down on its back. 4) Remove the turntable motor cover.
  • Page 16 K. PCB ASSEMBLY REMOVAL L. INTERLOCK SYSTEM 1) Remove the control panel assembly from the 1) INTERLOCK MECHANISM cavity. (Refer to control panel assembly removal The door lock mechanism is a device which has on previous page.) been specially designed to eliminate completely 2) Remove screws which hold the PCB SUB ASS’Y to microwave activity when the door is opened during the control panel.

  • Page 17: Interlock Continuity Test

    INTERLOCK CONTINUITY TEST WARNING : FOR CONTINUED PROTECTION AGAINST EXCESSIVE RADIATION EMISSION, REPLACE ONLY WITH IDENTICAL REPLACEMENT PARTS. TYPE NO. SZM-V 16-FA-63 OR VP-533A-OF FOR PRIMARY SWITCH TYPE NO. SZM-V 16-FA-62 OR VP-532A-OF FOR MONITOR SWITCH TYPE NO. SZM-V 16-FA-63 OR VP-533A-OF FOR SECONDARY SWITCH B.

  • Page 18: Component Test Procedure

    COMPONENT TEST PROCEDURE CAUTIONS 1. DISCONNECT THE POWER SUPPLY CORD FROM THE OUTLET WHENEVER REMOVING THE OUTER CASE FROM THE UNIT. PROCEED WITH THE TEST ONLY AFTER DISCHARGING THE HIGH VOLTAGE CAPACITOR AND REMOVING THE WIRE LEADS FROM THE PRIMARY WINDING OF THE HIGH VOLTAGE TRANSFORMER.

  • Page 19: Test Procedure

    COMPONENTS TEST PROCEDURE RESULTS Antenna Gasket Chassis Filament Terminals NOTE: When testing the magnetron, be sure to install the magnetron gasket in the correct position and be sure that the gasket is in good condition. HIGH VOLTAGE Measure the resistance. Normal: Momentarily indicates CAPACITOR (Ohm-meter scale: Rx1000)
  • Page 20 COMPONENTS TEST PROCEDURE RESULTS FUSE Check for continuity of the fuse with an Normal Abnormal multi-meter. NOTE: If the fuse is blown, check the primary, the secondary, and the monitor switches, H.V.D. and H.V.C. before replacing the fuse. If the fuse is blown by improper switch operation replace the defective switch and the fuse at the same time.
  • Page 21 COMPONENTS TEST PROCEDURE RESULTS FAN MOTOR Measure the resistance. Normal: (Wire leads removed) (Ohm-meter scale: R x 100) A ~ B A ~ C 40 ~ 60Ω 300~500Ω Abnormal: ∞ or several Ω Normal: Approx. 100~200 Ω Measure the resistance. TURNTABLE Abnormal: ∞...

  • Page 22: Troubleshooting

    TROUBLESHOOTING WHEN YOU GET A COMPLAINT FROM YOUR CUSTOMER, EVALUATE THE COMPLAINT CAREFULLY. IF THE FOLLOWING SYMPTOMS APPLY, PLEASE INSTRUCT THE CUSTOMER IN THE PROPER USE OF THE MICROWAVE OVEN. THIS CAN ELIMINATE AN UNNECESSARY SERVICE CALL. CAUTIONS 1. Check grounding before checking for trouble. 2.
  • Page 23 (TROUBLE 1) The following visual conditions indicate a probable defective control circuit. 1. Incomplete segments. • Segment missing. • Partial segment missing. • Digit flickering (NOTE: Slight flickering is normal.) 2. Colon does not turn on or blink. 3. A distinct change in the brightness of one or more numbers in display. 4.
  • Page 24 (TROUBLE 2) Oven does not operate at all; Display window does not display any figures, and no input is accepted. CONDITION CHECK RESULT CAUSE REMEDY Malfunction of the Check continuity Replace fuse, 1. Fuse blows. Continuity. monitor switch. of monitor primary, monitor switch (with switches, and...
  • Page 25 (TROUBLE 3) Display shows all figures set, but oven does not start cooking while desired program times are set and START pad is touched. CONDITION CHECK RESULT CAUSE REMEDY Defective Replace Check continuity 1.Setting time No continuity. secondary switch. secondary switch. of secondary does not count switch (with...
  • Page 26 (TROUBLE 5) No microwave oscillation even though oven lamp and fan motor run (Display operates properly) CONDITION CHECK RESULT CAUSE REMEDY Defective PCB No microwave Replace PCB Disconnect the No continuity. assembly. oscillation. assembly. wire leads from relay 2 and check continuity Continuity.
  • Page 27 (TROUBLE 6) No microwave oscillation even though oven lamp and fan motor run. (Display operates properly) CONDITION CHECK RESULT CAUSE REMEDY Defective PCB Replace PCB Output is full power Disconnect the Abnormal. assembly. assembly. when you set lower wire leads from power level.

  • Page 28: Exploded View

    EXPLODED VIEW INTRODUCTION OVEN CAVITY PARTS INTERIOR PARTS BASE PLATE PARTS DOOR PARTS LATCH BOARD PARTS CONTROL PANEL PARTS...

  • Page 29: Door Parts

    DOOR PARTS 13581A 13536A 13552A 13213A 14890A 13551A 14026A 14970A WTT028 13650A...

  • Page 30: Control Panel Parts

    CONTROL PANEL PARTS 23790D 24781M 268711 23551A 250201 WTP004 249401...

  • Page 31: Oven Cavity Parts

    OVEN CAVITY PARTS 33112U WTT021 WTT020 33390G 33052A 35889A 36549S WTP013...
  • Page 32 LATCH BOARD PARTS 43500A WSZ085 466001 466003 466001 44510A...
  • Page 33 INTERIOR PARTS WSZ062 56411A WSZ002 56930V 56324A WSZ002 50FZZA 56201A WTT028 WTT037 56549F 55900A 54974S WSZ002 WSZ002 50CZZH 56851D 56912B 54810C 56901A WTT028 948501 568771 55262A...
  • Page 34 BASE PLATE PARTS 56170D 63302A 63303A 948502 65006B WSZ002 WTT021...
