Precautions

You cannot operate your oven with the door open due to the safety interlocks
built into the door mechanism. These safety interlocks automatically switch off
any cooking activity when the door is opened; which in the case of a
microwave oven could result in harmful exposure to microwave energy.
It is important not to tamper with the safety interlocks.
Do not place any object between the oven front face and the door or allow
food or cleaner residue to accumulate on sealing surfaces.
Do not operate your oven if it is damaged. It is particularly important that the
oven door closes properly and that there is no damage to the: (1) door(bent),
(2) hinges and latches (broken or loosened), (3) door seals and sealing
surfaces.
Your oven should not be adjusted or repaired by anyone except qualified
service personnel.
Warning
Please ensure cooking times are correctly set as
over cooking may result in the FOOD catching fire
and subsequent damage to your oven.
2
Precautions to avoid possible exposure to excessive microwave energy.
When heating liquids, e.g. soups, sauces and beverages in your microwave
oven, delayed eruptive boiling can occur without evidence of bubbling. This
could result in a sudden boil over of the hot liquid. To prevent this possibility
the following steps should be taken:
1 Avoid using straight sided containers with narrow necks.
2 Do not overheat.
3 Stir the liquid before placing the container in the oven and again halfway
through the heating time.
4 After heating, allow to stand in the oven for a short time, stir or shake
them(especially the contents of feeding bottles and baby food jars) again
carefully and check the temperature of them before consumption to avoid
burns (especially, contents of feeding bottles and baby food jars).
Be careful when handling the container.
Warning
Always allow food to stand after being cooked by
microwaves and check the temperature of them
before consumption. Especially contents of feeding
bottles and baby food jars.

Advertisement

Table of Contents
loading

Summary of Contents for LG Microwave Oven

  • Page 1: Precautions

    To prevent this possibility microwave oven could result in harmful exposure to microwave energy. the following steps should be taken: It is important not to tamper with the safety interlocks.
  • Page 2: Table Of Contents

    Questions & Answers A very safe appliance Plug Wiring Information/Technical Specifications Your microwave oven is one of the safest of all home appliances. When the door is opened, the oven automatically stops producing microwaves. Microwave energy is converted completely to heat when it enters food, leaving no “left over”...
  • Page 3: Unpacking & Installing

    Unpacking & By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your Installing oven make sure you remove all accessories and packing.
  • Page 4 Plug your oven into a standard household socket. Open your oven door by pulling the DOOR Make sure your oven is the only appliance connected HANDLE. Place the ROLLER REST inside the oven to the socket. If your oven does not operate properly, unplug it and place the GLASS TRAY on top.
  • Page 5: Setting The Clock

    Setting the You can set either 12 hour clock or 24 hour clock . Clock In the following example I will show you how to set the time for 14:35 when using the 24 clock. Make sure that you have removed all packaging from your oven. Make sure that you have correctly installed your oven as described earlier in this book.
  • Page 6: Child Lock

    Child Lock Press STOP/CLEAR . Your oven has a safety feature that Press and hold STOP/CLEAR until “L” appears in the display and BEEP prevents accidental running of the oven. sounds. Once the child lock is set, you will be The CHILD LOCK is now set.
  • Page 7: Micro Power Cooking

    Micro Power In the following example I will show you how to cook some food on 80% power for 5 minutes and 30 seconds. Cooking Make sure that you have correctly installed your oven as described earlier in this book. Press STOP/CLEAR.
  • Page 8: Micro Power Level

    Micro Power Your microwave oven is equipped with 5 power levels to give you maximum flexibility and control over cooking. The table below shows the examples of food and their recommended cooking power levels for use with this Level microwave oven.
  • Page 9: Auto Cook 10

    Auto In the following example I will show you how to cook 2 jacket potatoes (0.4 kg). Cook Press STOP/CLEAR. Press JACKET POTATO of AUTO COOK twice to enter 2 jacket potatoes (400g). AUTO COOK allows you to easily cook Auto Cook most of your favorite food by selecting “2”...
  • Page 10 FOOD CATEGORY FOOD TEMP. QUANTITY INSTRUCTIONS Wash, dry and prick potato with a fork several times. Place the JACKET POTATO 1 (200 g) potato on centre of the glass tray. 2 (400 g) Room temp. 3 (600 g) 4 (800 g) FRESH VEGETABLES Place prepared vegetables into a suitable sized container 150 g...
  • Page 11: Auto Defrost 12

    Auto The temperature and density of food varies, I would recommend that the food is checked before cooking commences. Pay particular attention to large joints of meat and chicken, some foods should not be completely thawed before cooking. For example fish cooks so quickly that it is sometimes better to begin cooking while still Defrost slightly frozen.
  • Page 12 AUTO DEFROST SEQUENCE LIST SEQUENCE FOOD MIN./MAX. FOOD 0.1/4.0 kg MEAT Minced beef, Fillet steak, Cubes for stew, Sirloin steak, Pot roast, Rump roast, Beef burger. Beef Chops(2.5 cm thick),Rolled roast. Lamb Pork Chops(1.2 cm thick), Spareribs, Rolled roast, Sausage. Veal Cutlets(450 g, 1.2 cm thick) 0.1/4.0 kg...
  • Page 13: Quick Start

    Quick In the following example I will show you how to set 2 minutes of cooking on high power. Start Press STOP/CLEAR. Press START four times to select 2 minutes on HIGH power. The QUICK START feature allows you to Your oven will start before you have finished the fourth press.
  • Page 14: Timer

    Timer In the following example I will show you how to set the timer for 15 minutes. Press STOP/CLEAR. Press KITCHEN TIMER. Your oven also has a Timer that can be used for noncooking functions. When used as an independent timer, the oven is not running.
  • Page 15: Safety Precautions

    13 Do not cook eggs in their shell. Pressure will build up inside the egg energy, if the oven is accidentally started. which will burst. 3 Do not dry clothes in the microwave oven, which may become carbonized 14 Do not attempt deep fat frying in your oven. or burned if heated too long.
  • Page 16: Microwave Safe Utensils

    You Plastic microwave cookware probably have many items on hand in your kitchen right now that can be used as A variety of shapes and sizes of microwave cookware are available.
  • Page 17: Food Characteristics & Microwave Cooking 18

    Always watch your food while it cooks. Your microwave oven is equipped with a Bone and fat content of food light that turns on automatically when the oven is in operation so that you can see Bones conduct heat and fat cooks more quickly than meat.
  • Page 18: Microwave Cooking

    Food cooks so quickly in a microwave oven, it is necessary to test it frequently. Some foods are left in the microwave until completely cooked, but most foods, including meats and The door and door seals should be kept clean.
  • Page 19: Questions & Answers

    Answers Q What’s wrong when the oven light will not glow? Q Is it possible to pop corn in a microwave oven? A There may be several reasons why the oven light will not glow. A Yes, if using one of the two methods described Light bulb has blown.
  • Page 20: Plug Wiring Information/Technical Specifications

    Plug wiring information/ Technical Specifications Warning Technical Specification This appliance must be earthed MS-194A The wires in this mains lead are colored in accordance with the following codes Power Input 230 V AC / 50 Hz BLUE ~ Neutral Output 800 W (IEC705 rating standard) BROWN ~ Live GREEN &...

This manual is also suitable for:

Ms-194a
