- Page 1 RC650 MP4 PLAYER User Manual...
-
Page 2: Important Safety Instruction
USB 2.0 High Speed interface make data transfer from/to the computer easy and fast. The RICATECH RC650 MP4 Player has built-in a Lithium battery rechargeable by your computer or the optional adapter model : Ricatech RCCH03 By the built-in microphone, it is possible to record your voice messages and play them directly with the device or from your computer. -
Page 3: Package Contents
5. User manual 3. Minimum system requirements To use your RC650 MP4 Player it is necessary to have a computer with the following hardware configuration: 1. PC IBM® or 100% compatible with an Intel® Pentium® II CPU at 233 MHz or more. - Page 4 Description Here below you will find a product description 1. On / Off 2. Record 3. VOL – (Decrease the Volume) 4. Previous [] / Backward [] 5. Menu 6. VOL +(Increase the Volume) 7. Next [] / Forward [] 8.
-
Page 5: Power On/Off
5. Use 5.1 Power ON/OFF The MP4 player has built-in a rechargeable battery. At the first use we suggest to recharge the battery for a long period (around 8 hours). To recharge the battery please connect the MP4 player to USB computer port. Powering On:. -
Page 6: Main Menu
Main Menu After powering on the MP4 player, you can see the main menu with 9 submenus (optional), which allow you to select different functions and options. By using the [] or [] buttons, you can select the desire option, and then press Play button to confirm the selection. -
Page 7: Music Mode
5.2 Music Mode The music player option allows playing songs. To activate this option please follow here below instruction: 1. Power ON the MP4 Player, the screen will display the main menu 2. By using [] or [] buttons, select MUSIC PLAY option then press [PLAY] button. -
Page 8: A-B Repeat Function
Equalizer With preset 7 equalizers including Natural, Rock, Pop, Classic, Soft, Jazz and DBB Tempo Rate: You can alter the Tempo Rate of the Song. 5.2.3 A-B Repeat Function The player can loop-playing a specified music interval of a song. While Playing Music, Press RECORD [REC] button to set repeat start point A, and then press RECORD [REC] again to set repeat end point B. - Page 9 5.3.2 AMV Submenu By short pressing the MENU [M] button, you can find the following AMV submenus. Press [] or []to choose, and then press PLAY [] key to confirm each submenus. Use the same technique to navigate inside each of the submenus. Status Submenu Options Local Folder...
- Page 10 After installation finished, select and run MP3 PLAYER UTILITIES -> AMV Converter Choose the video file you want to be converted in “INPUT FILE”. Choose the output destination folder in the “OUTPUT FILE”. You can set the size, quality and rotation for the conversion.
-
Page 11: Voice Submenu
During recording, Press the PLAY [] / RECORD [REC] to start recording. Press the play button again to pause recording. Hold the PLAY [] / RECORD [REC] button for longer time will eventually stop recording. By short pressing the MENU [M] button, you can find the LOCAL FOLDER and REC TYPE. Press [] or [] to choose, and then press PLAY [] key to confirm each submenus. - Page 12 Status Submenu Options Status Submenu Options Local Folder While music is on Repeat Delete File Tempo Rate While Music is paused Delete All Replay Local Folder: Under this directory, you can choose to go up a folder level by pressing PLAY [] to confirm. And then you can choose the folder you want to play ...
-
Page 13: Automatic Search
Here below you will find the FM radio option list. AUTO SERACH: Select this option to start auto-searching for radio channels. SAVE: Select this option to save radio channels DELETE: Select this option to delete radio channels. DELETE ALL: Select this option to delete all radio channels. NORMAL BAND: Select this option to activate normal FM band. - Page 14 5.7 E-Book The Ebook option allows reading text file. To activate this option please follow here below instruction: 1. Power ON the MP4 Player, the screen will display the main menu. 2. By using the [] or [] buttons select E-book, and then press PLAY [] button to confirm 3.
- Page 15 5.8.1 ALBUM Submenu By short pressing the MENU [M] button, you can find the following music submenus. Press [] or [] to choose, and then press PLAY [] key to confirm each submenus. Use the same technique to navigate inside each of the submenus. Status Submenu Options Local Folder...
-
Page 16: System Time Set
The parameters available in the setup system are: System Time: This option allows setting of the system date and time. LCD set: This option allows setting the brightness, darkly and black screen of the LCD panel. Language: This option allows setting the Language of the User Interface. Power Off: This option allows setting the off time and sleep time. -
Page 17: Computer Installation
6. Computer installation This chapter describes how to install the MP4 player in your computer system in order to transfer songs file in the memory device. The following instructions are intended a PC where at the CD-ROM drive is assigned “D:”... -
Page 18: Windows® Me, Windows® 2000 And Windows® Xp
6.1.1 Windows® 98 Second Edition – Safety Remove Hardware The Windows® 98 SE driver install the Safety Remove utility in the systray Before to disconnect the MP4 Player to USB port please follow here below instruction: 1. Double click the utility available in the systray. Windows®... -
Page 19: File Transfer
6.3 File transfer When the MP4 Player is connected to the computer, “My Computer” has a new “Removable Disc”. This removable disc is the MP4 player. The operating system assigns automatically a drive letter to removable device (the picture below shows an MP4 Player where the operating system has assigned the H: letter). Windows®... -
Page 20: Firmware Upgrade
7. Firmware upgrade To upgrade the firmware please follow here below instruction: 1. From the provide CD-Rom, find RICATECH RC650 Driver and Video Converter/ setup.exe, double click it to start installing MP3 PLAYER UTILITIES 2. Follow instruction install programme, . - Page 21 21 -...
