Acoustech
OWNER'S MANUAL
Model HT-56
Weather-Resistant Speaker System
SPECIFICATIONS
Design
Enclosure Type
Two-way, indoor/outdoor speakers
Sealed, weather-resistant
Drivers
Grille
One 6
1
/
˝ polypropylene woofer,
Perforated metal, non-removable
2
one 1˝ high efficiency dome tweeter
Bracket
Power Handling
Painted steel with plastic knobs
10 - 150 watts per channel (375 watts peak)
Input Terminals
Sensitivity
Gold-plated binding posts
93dB @ 1 watt, 1 meter
Dimensions
1
1
Frequency Response
12˝ H x 8
/
˝ W x 7
/
˝ D (excluding bracket)
2
2
55Hz - 20kHz (+/- 3dB)
Shipping Weight
Crossover
17 lbs. (7.7 kg.)
2000Hz
Limited Warranty
Impedance
3 years parts and labor (outdoor use)
8 ohms
5 years parts and labor (indoor use)
Advertisement
Related Manuals for Acoustech HT-56
Summary of Contents for Acoustech HT-56
-
Page 1: Specifications
Acoustech OWNER’S MANUAL Model HT-56 Weather-Resistant Speaker System SPECIFICATIONS Design Enclosure Type Two-way, indoor/outdoor speakers Sealed, weather-resistant Drivers Grille One 6 ˝ polypropylene woofer, Perforated metal, non-removable one 1˝ high efficiency dome tweeter Bracket Power Handling Painted steel with plastic knobs... - Page 2 Indoor Speaker Setup(s) ucts offer obvious sonic benefits over lamp The diagram below shows 5.1, 6.1, and cord and light gauge wires. The HT-56 speak- 7.1 speaker placement. ers come equipped with inputs that allow the greatest flexibility and choice of hook-up wire and connectors.
- Page 3 Acoustech indoor/out- Troubleshooting and Service door speaker.) Acoustech speakers do not use external fuse protection or circuit breakers because these Step 4 devices tend to impede sound quality and may Attach the wire from your amplifier to terminals only protect the speaker to a marginal degree.
-
Page 4: Warranty Service
Acoustech Speaker Systems are designed to the highest possible value and performance standards. Our confidence in their quality is such that B . I . C America offers customers this transferable limited warranty: Acoustech System Limited Warranty If the Acoustech speaker system proves to be...
