Leviton LevNet rF Wireless Product Data

product data
LevNet rF Wireless
Self-powered Solutions
plug-In receivers
Wireless self-powered technology means no new
wiring is required. Leviton LevNet RF Wireless
Self-Powered Solutions are easy to install and
maintenance-free, saving ongoing labor and
material costs while saving energy.
EnOcean technology allows energy harvesting LevNet
®
RF Transmitters to operate indefinitely without the
use of batteries. The motion of a switch actuation,
light on a solar cell, or temperature differentials
in the environment provide power to LevNet RF
Transmitters, allowing zero-maintenance wireless
devices. The LevNet RF line includes multiple products
that operate in the uncrowded 315MHz band offering
greater transmission range (50-150 feet) than other
wireless technologies and minimal competitive traffic.
Levnet Rf Plug-In Receivers receive signals from
LevNet RF Sensors, Switches, and Transmitters to
control lighting, thermostats, and other devices or
loads. Wireless, self-powered technologies make them
the ideal solution for retrofits and new construction;
installation is quick and easy with no additional wiring
required. It takes only minutes to install and configure.
Leviton Mfg. co., Inc. Lighting Management Systems
20497 SW Teton Avenue, Tualatin, OR 97062 1-800-736-6682 Tech Line: 1-800-959-6004 Fax: 503-404-5594 www.leviton.com/lms
© 2009 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice.

appLIcatIoNS

• Retrofits
• New construction
• Conference rooms
• Classrooms
• Lounges/Lobbies
• Private offices
• Executive offices
• Restrooms
• Daycare facilities
• Multimedia areas

PLug-IN DImmeR/ReLay ReceIveR (WSg0S-D1T)

The Plug-in Dimmer Receiver provides dimming
control of lamps and other devices. Simply plug a
lamp into the Dimming Receiver, and then plug the
Dimming Receiver into a standard electrical outlet.
The lamp may then be controlled using Wireless
Self-Powered Switches or Sensors.

PLug-IN ON/OFF ReLay ReceIveR (WSg0S-S1T)

The LevNet RF Plug-In ON/OFF Relay Receiver
responds to compatible LevNet RF Switches and
Transmitters to provide ON/OFF control of lights,
TVs, and other plug-in devices. The Plug-In ON/OFF
Receiver may optionally be used to control electrical
loads using signals from Sensors.

FEaturES

• easy-to-use: fast installation – plugs into any 120V
outlet; run zero switch-leg wires; DIM (WSG0S-D1T
only) or ON/OFF (WSG0S-S1T only) control of lights
• ultra smooth wireless light dimming: dimming
for architectural lighting, daylighting, load shedding,
and manual-ON/OFF and auto-OFF controls
(WSG0S-D1T only)
• Reliable range: compatible with all LevNet RF
Switches; error checking ensures response only to
appropriate Switches; a single Transmitter can
control unlimited Dimmers (WSG0S-D1T only) or
ON/OFF Relay Receivers (WSG0S-S1T) within range
• Simple wireless control systems: architectural
lighting, daylighting, load shedding, and manual-
ON/OFF and auto-OFF control of lights, TVs, and
other plug-in devices
• control the way you want it: control the LevNet
RF Relay Receiver with a variety of devices –
Wireless Self-Powered Switches, Sensors, and more
