SIDEWALL (SWf)
cENTRIfUGAL SIDEWALL fANS
VENTILADoRES cENRIfUGoS DE MoNTAjE EN pAREDES
VENTILATEUR DE pARoI cENTRIfUGE EN LIGNE
U L
Models SWf-100, 100X, 150, 150X, 200
C
U
S
R
INSTALLATIoN AND WIRING INSTRUcTIoNS
INSTRUccIoNES DE MoNTAjE
INSTRUCTIONS DE MONTAGE ET DE CÂBLAGE
(English / Español / Français)
READ AND SAVE THESE INSTRUCTIONS
LEER Y GUARDAR ESTAS INSTRUCCIONES
LIRE ET CONSERVER CES INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Soler&Palau SIDEWALL SWF-100
Summary of Contents for Soler&Palau SIDEWALL SWF-100
- Page 1 SIDEWALL (SWf) cENTRIfUGAL SIDEWALL fANS VENTILADoRES cENRIfUGoS DE MoNTAjE EN pAREDES VENTILATEUR DE pARoI cENTRIfUGE EN LIGNE Models SWf-100, 100X, 150, 150X, 200 INSTALLATIoN AND WIRING INSTRUcTIoNS INSTRUccIoNES DE MoNTAjE INSTRUCTIONS DE MONTAGE ET DE CÂBLAGE (English / Español / Français)
-
Page 2: Dimensional Data
Dimensional Data 2 mm Model 13 ¼ 13 ¼ 2 7/16 SWF-100 13 ¼ 13 ¼ 2 7/16 SWF-100x 15 ½ 13 ¼ 10 3/16 2 7/16 SWF-150 15 ½ 16 1/16 3 3/16 2 7/16 SWF-150x 15 ½ 16 1/16... - Page 3 ENGLISH Fan Installation WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY, OBSERVE THE FOLLOWING: Use this unit only in the manner intended by the manufacturer. If you have any questions contact the manufacturer. Before servicing or cleaning the unit, switch the power off at the service panel and lock the service disconnecting means to prevent power from being switched on accidentally.
-
Page 4: Maintenance Instructions
Electrical Connection All SWF series fans operate from a standard 120V 60Hz A.C electrical supply. All wiring must be carried out in accordance with National Electrical Code, and all applicable state and local buildings codes. WIRING INSTRUCTIONS WARNING! Make sure that power supply is disconnected and locked to prevent accidental acti- vation. - Page 5 WIRING DIAGRAMS Motor without speed controller Motor with speed controller...
- Page 6 FIVE (5) YEAR WARRANTY Soler & Palau warrants that the SWF - SIDEWALL series exhaust fan will be free from defective materials and workmanship for the period of (5) years from the date of original purchase. In the event that we and any part defective the product will be repaired or, in the Company’s discretion, replaced without charge provided that the product has been installed in accordance with the enclosed instructions and all applicable EPA Standards and state and local building codes.
