- Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL ENERGY RECOVERY VENTILATOR TRC800 TRC800V MODEL: TRC800V MODEL: TRC800 WWW.SOLERPALAU-USA.COM...
- Page 2 TRC800 & TRC800V TRC800 & TRC800V INFO TABLE OF CONTENTS TRC800/V info ..... 2-5 Installation ......6-12 Start-up ......13-15 Maintenance .....17-19 ABOUT S&P S&P USA operations are based in Jacksonville, Florida. This geographically strategic location allows the shipment of products throughout the US and Canada. The Jacksonville manufacturing facility has more than 150,000 square feet of warehouse space for the stocking of a comprehensive range of products.
-
Page 3: Installation
TRC800 & TRC800V TRC800 & TRC800V INFO SPECIFICATIONS NOTE: Specifications may TRC800 TRC800V be subj ec t t o ch ange Ventilation Type: Ventilation Type: without notice. Static plate, heat and humidity transfer Static plate, heat and humidity transfer Unless otherwise specified,... - Page 4 TRC800 & TRC800V TRC800 INFO WWW.SOLERPALAU-USA.COM 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL...
- Page 5 TRC800 & TRC800V TRC800V INFO 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM...
- Page 6 TRC800 & TRC800V INSTALLATION PLACEMENT OF THE TRC800 & TRC800V TheTRC800/TRC800V is designed for installation indoors. Select a location that is central to the inside duct runs, PLANNING and close to both the exhaust duct (to the outside) and the fresh air duct (from the outside). The unit YOUR INSTALLATION can be installed in any orientation but the contractor is responsible for safe installation of the unit.
- Page 7 TRC800 & TRC800V INSTALLATION APPLICATIONS PLANNING YOUR INSTALLATION See figures for examples of some common installation approaches. (TRC800 shown) www.renewaire.com (800) 627- 4499 support@renewaire.com www.renewaire.com (800) 627- 4499 support@renewaire.com 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM www.renewaire.com (800) 627- 4499...
- Page 8 Take these simple steps to attenuate noise from the unit. OUTSIDE THE BUILDING RADIATED NOISE Exhaust velocity noise is the primary cause of The TRC800/TRC800V is insulated with high-den- unit-related noise outside the building. Size the sity exhaust duct and grille for less than 1000 FPM fiberglass.
-
Page 9: Installation
électronique. CAUTION WARNING The TRC800 weighs 210 lbs. and the TRC800V Secure the TRC800 or TRC800V with straps or weighs 207 lbs. It is the installer’s responsibility to clamps so that it cannot fall or tip in the event of make sure that the screws or bolts used for securing accident, structural failure or earthquake. - Page 10 TRC800 & TRC800V INSTALLATION TRC800 & TRC800V SINGLE PHASE NOTE: Schematics shown are representative of standard units. See Unit Schematic label for detailed information. WWW.SOLERPALAU-USA.COM 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL...
- Page 11 A built-in circuit-breaker prevents damage to the supply system that operates the unit’s contactor(s) transformer and other low-voltage components in for TRC800 & TRC800V. The ERV’s 24VAC Power the event of a short-circuit or overload. In extreme Supply can also be used to power the external- cases, the transformer itself is designed to fail safely.
- Page 12 TRC800 & TRC800V INSTALLATION CONTROL WIRING SCHEMATICS NOTE: The simplified schematics below show CAUTION only the relevant portions of the low-voltage Be careful if the external control system provides control circuit in the ERV unit and representational 24VAC power at its control output: make sure external control approaches.
-
Page 13: Start-Up
TRC800 & TRC800V START-UP EQUIPMENT REQUIRED NOTE: Be sure to remove cap from pressure port MEASURING AIR FLOW A magnehelic gauge or other device capable of before inserting tubing. Insure tubing is well seated • measuring 0 to 1.5 in. water of differential pressure. -
Page 14: Start-Up
TRC800 & TRC800V Pleated_Filter_PD_APR16 20x20x2 MERV 8 (IOM) START UP MEASURING AIR FLOW FILTER SPECIFICATIONS • (2) 20” x 20” x 2”(nominal) pleated filters. Actual size: 19.5” x 19.5” x 1.75” • Unit shipped with MERV-8 Filters. Minimum recommended effectiveness: MERV-6... - Page 15 TRC800 & TRC800V NOTES 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM...
-
Page 16: Maintenance
TRC800 & TRC800V NOTES WWW.SOLERPALAU-USA.COM 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL... - Page 17 TRC800 & TRC800V MAINTENANCE TRC800 Horizontal Unit SERVICE PARTS 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM...
- Page 18 TRC800 & TRC800V MAINTENANCE TRC800V Vertical Unit SERVICE PARTS WWW.SOLERPALAU-USA.COM 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL...
- Page 19 WARNING Inspect and/or replace filters every two or three months when the TRC800/V is in regular use, or as needed. Filters must be used or the energy exchange core will become blocked by dust and the unit will not do Don’t allow the filter access door...
- Page 20 (800) 961-7370 FAX: (800) 961-7379 6393 POWERS AVE JACKSONVILLE, FLORIDA 32217 USA WWW.SOLERPALAU-USA.COM CANADA (416) 744-1217 FAX: (416) 744-0887 5600 AMBLER DRIVE MISSISSAUGA, ON L4W 2K9 - CANADA WWW.SOLERPALAUCANADA.COM 132103_003 (10/18)
