Smart S-3 & Genius G-2.5 & G-3 Series Spa Owner’s Manual “Trend Setting Innovations Since 1973” This Manual Contains IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS “SAVE THESE INSTRUCTIONS”... -
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY G-2.5 & G-3 GENIUS SERIES EQUIPMENT IMPORTANT SPA SAFETY INSTRUCTIONS ....1, 2, 3 All Electrical Wiring Must be Installed By A Certified Licensed Important Safety Precautions ..........3 Electrician Ground Fault Circuit Interrupter ..........5 G-2.5 and G-3 Dip Switch Configuration ....... -
Page 3: Important Spa Safety Instructions
THIS SPA IS FOR RESIDENTIAL USE ONLY! IMPORTANT SAFETY INSTRUCTIONS When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: 1. READ AND FOLLOW ALL INSTRUCTIONS 7. Danger Risk of Injury. The suction fittings in this spa are sized to match the specific 2. -
Page 4: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS Your spa can be a source of great pleasure. It offers healthful stimulating recreation and is a delightful fun center for you, your family and friends. However, it contains large quantities of water and is deep enough to present inherent dangers to life and health unless the following safety rules are strictly observed. -
Page 5: Site Selection
Selecting A Good Location Site Selection... Your new spa will provide you and yours with hour upon hour of healthy, relaxing enjoyment. The following suggestions and recommendations will help you select a safe and compatible site for your spa, maximizing your enjoyment. READ ALL SAFETY INSTRUCTIONS! See pages 1 and 2 for other safety requirements and instructions 1. -
Page 6: Filling Your Spa
WARNING: DO NOT SUPPLY POWER TO AN EMPTY SPA! FILLING YOUR SPA WINTERIZING YOUR SPA Filling your spa is the first step in maintaining water quality Warning: Allowing the spa water to freeze will cause severe and chemical balance. Use only clear, uncontaminated damage to the spa shell, equipment, and plumbing. -
Page 7: Nema 5-20 Amp Receptacle
ELECTRICAL DATA FOR THE USE OF CERTIFIED LICENSED ELECTRICIAN WARNING: Shock Hazard! Under No Circumstances Should This Spa Be Installed By Anyone Other Than A Certified Licensed Electrician! All wiring MUST be in accordance with the National Electrical Code and all local codes. S-3 SERIES CONVERTIBLE EQUIPMENT PACKAGE The S-3 is a convertible equipment pack designed to accept either 120 or 240 volt power input. -
Page 8: Ground Fault Circuit Interrupter Plug
GROUND FAULT CIRCUIT INTERRUPTER Your Leisure Bay Spa has a factory mounted power cord which is equipped with a Ground Fault Circuit Interrupter “G.F.C.I.” built within the plug housing. The G.F.C.I. has two mode buttons. The first is labeled “Test.” This button has a dual function. -
Page 9: Electrical Data
ELECTRICAL DATA FOR THE USE OF CERTIFIED LICENSED ELECTRICIAN WARNING: Shock Hazard! Under No Circumstances Should This Spa Be Installed By Anyone Other Than A Certified Licensed Electrician! All wiring MUST be in accordance with the National Electrical Code and all local codes. S-3 SERIES 120-240 VOLT HARD WIRE CONVERSION Conversion of the S-3 Series Equipment The conversion of an S-3 equipment package from a factory installed 120 volt system to a hardwired 240 volt system must be completed by a certified... - Page 10 ELECTRICAL DATA FOR THE USE OF CERTIFIED LICENSED ELECTRICIAN WARNING: Shock Hazard! Under No Circumstances Should This Spa Be Installed By Anyone Other Than A Certified Licensed Electrician! All wiring MUST be in accordance with the National Electrical Code and all local codes. G-2.5 &...
-
Page 11: Wiring Schematic
SUGGESTED WIRING FOR 240 VOLT INSTALLATION Wiring Schematic RED (HOT) BLK (HOT) Bottom View of G.F.C.I. (Square D) Front View of G.F.C.I. (Square D) RED (HOT) BLK (HOT) Elite System In-Spa System Box WHITE (NEUTRAL) BLK (HOT) RED (HOT) GREEN (GROUND) - Page 12 ELECTRICAL DATA FOR THE USE OF CERTIFIED LICENSED ELECTRICIAN WARNING: Shock Hazard! Under No Circumstances Should This Spa Be Installed By Anyone Other Than A Certified Licensed Electrician! All wiring MUST be in accordance with the National Electrical Code and all local codes. CONVERSION S-3 SERIES 120V...
- Page 13 ELECTRICAL DATA FOR THE USE OF CERTIFIED LICENSED ELECTRICIAN WARNING: Shock Hazard! Under No Circumstances Should This Spa Be Installed By Anyone Other Than A Certified Licensed Electrician! All wiring MUST be in accordance with the National Electrical Code and all local codes. G-2.5 &...
-
Page 14: Control Console
Personal Comfort Control Console The Leisure Bay Personal Comfort Control Console is your direct link to the most sophisticated solid state spa control center available. With a simple touch of the finger you can select any spa’s functions from turning on the lights to powering up the jets. This state of the art control console allows you to program the spa’s various operating functions to suit your individual needs by following the user friendly directions which follow. -
Page 15: Control Console
Personal Comfort Control Console The Leisure Bay Personal Comfort Control Console is your direct link to the most sophisticated solid state spa control center available. With a simple touch of the finger you can select any spa’s functions from turning on the lights to powering up the jets. This state of the art control console allows you to program the spa’s various operating functions to suit your individual needs by following the user friendly directions which follow. -
Page 16: G-3 Series Control
Personal Comfort Control Console The Leisure Bay Personal Comfort Control Console is your direct link to the most sophisticated solid state spa control center available. With a simple touch of the finger you can select any spa’s functions from turning on the lights to powering up the jets. This state of the art control console allows you to program the spa’s various operating functions to suit your individual needs by following the user friendly directions which follow. -
Page 17: Additional Features
Additional Features for S-3, G-2.5 and G-3 Spa Heating Modes The Heating Mode offers the ability to control your heater in special circumstances. Your spa is preset at the factory to Standard Mode. However, the Heating Mode can be changed to Economy or Sleep by pressing the button at any time. - Page 18 S-3, G-2.5 and G-3 Display Messages MESSAGE MEANING ACTION REQUIRED No message on display. The control panel will be disabled until power returns. Spa settings Power has been cut off to the spa. will be preserved until next power up. Temperature unknown.
-
