SC23 is a digital switch with anatomic design and visible backlit buttons that is able
to switch light devices or sirens. Exclusively for motorcycles.
The SC23 is able to:
-
Switch up to 3 low current devices (Toggle Green/Orange/Yellow wires).
Change Siren tones using a momentary blue wire – GND.
-
Turn ON and OFF the buttons 1, 3 and 4 by pressing the "MASTER" center
-
buttons.
1. Specification
Voltage
11.2–14.7 VDC
www.rontan.com
Current
LED Type
10mA /
SMD High Bright
90mA
PALM SWITCH-S SC23
Snapshot User's Guide
LED Quantity
10
REV3.0
Weight
3.3 ounces
Page 1
Advertisement
Table of Contents
Related Manuals for Rontan SC23
Summary of Contents for Rontan SC23
- Page 1 PALM SWITCH-S SC23 Snapshot User’s Guide SC23 is a digital switch with anatomic design and visible backlit buttons that is able to switch light devices or sirens. Exclusively for motorcycles. The SC23 is able to: Switch up to 3 low current devices (Toggle Green/Orange/Yellow wires).
- Page 2 PALM SWITCH-S SC23 Snapshot User’s Guide 2. Dimensions 3. Descriptions FUNCTION COLOR MODE ACTIVATES THE FRONT ORANGE continuous MOTORCYCLE LIGHTS MANUAL SIREN YELLOW momentary ACTIVATES THE REAR MOTORCYCLE GREEN continuous LIGHTS SIREN-ON/OFF / CHANGE SIREN BLUE momentary TONE MASTER On/Off 1, 3 & 4...
