SC22 is a digital switch with anatomic design and visible backlit buttons that is able
to switch light devices or sirens.
The SC22 is able to:
-
Switch up to 2 low current devices (Toggle Green/Orange/Yellow wires).
Change Siren tones using a momentary blue wire – GND.
-
Turn ON and OFF the buttons 1, 3 and 4 by pressing the "MASTER" center
-
buttons.
1. Specification
Voltage
11.2–14.7 VDC
www.rontan.com
Current
LED Type
10mA/
SMD High Bright
90mA
PALM SWITCH-S SC22
Snapshot User's Guide
LED Quantity
10
REV3.0
Weight
3.3 ounces
1
Page
Advertisement
Table of Contents
Related Manuals for Rontan PALM SWITCH-S SC22
Summary of Contents for Rontan PALM SWITCH-S SC22
- Page 1 PALM SWITCH-S SC22 Snapshot User’s Guide SC22 is a digital switch with anatomic design and visible backlit buttons that is able to switch light devices or sirens. The SC22 is able to: Switch up to 2 low current devices (Toggle Green/Orange/Yellow wires).
- Page 2 PALM SWITCH-S SC22 Snapshot User’s Guide 2. Dimensions 3. Descriptions FUNCTION COLOR MODE ON/OFF ORANGE continuous SELECT YELLOW momentary FRONT LIGHTS GREEN continuous SIREN BLUE momentary MASTER On/Off 1, 3 & 4 +Vbat BROWN SELECT is only activated if on/off is functioning and the front lights are off.
