Audio Note M5 Phono Signature Owner's Information page 13

TECHNICAL SPECIFICATIONS
INPUT IMPEDANCE
INPUT SENSITIVITY
GAIN @ 1KHz
OUTPUT IMPEDANCE
OUTPUT NOISE (RMS)
TUBE COMPLIMENT
FUSE RATINGS
MAX. POWER CONSUMPTION
UNIT WEIGHT
SHIPPING WEIGHT
(ORIGINAL PACKAGING)
UNIT DIMENSIONS
SHIPPING DIMENSIONS
(ORIGINAL PACKAGING)
NOTE
100 KOhm Line Level
47KOhm, phono
126mV for 1V Output, Line Level
15dB Line Level
63dB
<10 Ohms
<0.1mV unweighted, Line Level
<15mV unweighted,
1 x ECC82
1 x 5687
2 x 6X5
2 x ECL82
2 x OB2
3 x 6072a
1.6A anti-surge (110 / 120V supply)
800mA anti-surge (220 / 240V supply)
81 Watts
16 KG
19 KG
135mm (h) x 440mm (w) x 410mm (d)
235mm (h) x 540mm (w) x 510mm (d)
Due to Audio Note (UK)'s ongoing research
and development program, specifications
are subject to change without notice.
Phono
Phono
