TECHNICAL SPECIFICATIONS
INPUT IMPEDANCE
INPUT SENSITIVITY
GAIN
OUTPUT IMPEDANCE
OUTPUT NOISE
TUBE COMPLIMENT
FUSE RATINGS
MAX. POWER CONSUMPTION
UNIT WEIGHT
SHIPPING WEIGHT
(ORIGINAL PACKAGING)
UNIT DIMENSIONS
SHIPPING DIMENSIONS
(ORIGINAL PACKAGING)
NOTE
100 KOhms
126mV for 1V Output
18dB at 1KHz
<10 Ohms
<0.08mV unweighted (RMS)
1 x ECC82
1 x 5687WB
1 x 6X5
1 x ECL82
1 x OB2
1A anti-surge (110 / 120V supply)
500mA anti-surge (220 / 240V supply)
81 Watts
16 KG
19 KG
135mm (h) x 440mm (w) x 410mm (d)
235mm (h) x 540mm (w) x 510mm (d)
Due to Audio Note (UK)'s ongoing
research and development program,
specifications are subject to change
without notice.
