The Bose@ 601@ Series IV DirectlReflecting@ Speaker System Owner's Guide...
Page 2
Declaration Conformity We, the offerer: Bose® Corporation, The Mountain, Framingham, MA 01701-9168 USA Acknowledge our sole responsibility, that the product: Kind of equipment: Loudspeaker Type designation: 601® Series IV DirectiReflecting® speaker In accordance with EMC Directive 89/336/EEC and Article 10 (1) of the Directive,...
Introduction Your 601 ®DirectiReflecting® speakers re-create a natural balance of reflected and direct sound energy for a lifelike, spacious performance. As with all Bose® products, their design is meant to bring you high-quality concert-like sound. Figure 1 A natural balance of reflected and direct sound energy.
If the length of speaker wire extends more than 20 feet (6 m) from a receiver or amplifier, refer to "Wire recommendations" on page 9 or contact your authorized Bose dealer for more infor- mation.
Preparing the speaker cord Speaker cord consists of two insulated wires. The insulation around one wire is marked (striped, collared, ribbed, or may have writing on it). This marked wire is always positive (+). The plain wire is always negative (-). These wires correspond to the red (+) and black (-) ter- minals on the speaker, receiver, or amplifier.
Checking the connections Check all the connections from the receiver to the left and right speakers. Make sure all the wires are connected in phase and - to -). Correct any wiring problems before you plug in your receiver and turn it on. 601®...
Use the chart below as troubleshooting guidelines. If this does not solve the problem, contact your authorized Bose® dealer to arrange for service. Refer to the address list enclosed in the product packaging for correct phone numbers.
12 (3.3 mm Cuslomer service For additional help in solving problems, contact Bose® customer service. Refer to the address list enclosed in the product packaging for correct phone numbers. C/ea.ing Wipe the 601 ®speaker cabinets using a dry cloth. Do not use solvents or chemicals. Do not allow liquids to spill on, or objects to drop into the speaker grilles.
