UNICOM FEP-5300TF-C User Manual

Velocity series 10/100base-tx/100base-fx fast ethernet converter
Hide thumbs Also See for FEP-5300TF-C:

Advertisement

Quick Links

For full coverage of your warranty, be sure
to register your product using the enclosed
registration card.
908 Canada Court
City of Industry, CA 91748 U.S.A.
Phone: 626.964.7873 or 800.346.6668 Fax: 626.964.7880
www.unicomlink.com
e-mail: info@unicomlink.com
©UNICOM 2003. UNICOM and "A Network Systems Solution" are trademarks of UNICOM Electric, Inc.
All rights reserved. Specifications subject to change without notice.
Rev: 05.03
10/100Base-TX/FX
Fast Ethernet Converter
FEP-5300TF-C
( SC/MM/2km )
FEP-5300TF-T
( ST/MM/2km )
FEP-5400TF-C
( SC/SM/15km )
FEP-5401TF-C
( SC/SM/30km )
FEP-5402TF-C
( SC/SM/60km )
U
M
SER'S
ANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FEP-5300TF-C and is the answer not in the manual?

Questions and answers

Summary of Contents for UNICOM FEP-5300TF-C

  • Page 1 City of Industry, CA 91748 U.S.A. Phone: 626.964.7873 or 800.346.6668 Fax: 626.964.7880 www.unicomlink.com e-mail: info@unicomlink.com SER’S ANUAL ©UNICOM 2003. UNICOM and “A Network Systems Solution” are trademarks of UNICOM Electric, Inc. All rights reserved. Specifications subject to change without notice. Rev: 05.03...
  • Page 2: Package Contents

    Package Contents Package contents include the following: 10/100Base-TX to 100Base-FX Converter (Multi-Mode, Single Mode) DC Power Adapter User’s Manual Rack Mount Brackets Warranty card (not shown) 10/100Base-TX/FX User’s Manual Power Adapter Rack Mount Converter Brackets (Multi-Mode, Single Mode) Figure 1. Contents of package. IMPORTANT: If any piece is missing or damaged, please contact your local dealer or reseller for service.
  • Page 3: Product Specifications

    30 km Max., FEP-5401TF-C switches to set the operation mode for the UTP, Fiber ports and Link 60 km Max., FEP-5402TF-C Loss Forwarding function. These converters can be used in Unicom’s 10 bay media chassis or as stand-alone components. DIP Switch:...
  • Page 4: Hardware Description

    Switch or workstation without changing to a crossover cable. FEP-5402TF-C 29 dBm 60 Km 9/125, 8/125 • Fiber Port: This port is for the 100 Base-FX connection. Unicom provides three different styles of fiber connectors (SC/ST, Multi- Mode or SC, Single-mode).
  • Page 5: Led Indicators

    C. Use a screwdriver to attach the rack mount ears to both sides of LED Indicators the modular converter. There are six diagnostic LEDs located on the Front panel of these D. Install the modular converter by inserting it into the chassis Converters.
  • Page 6: Dip Switch

    DIP Switch Network Connection The DIP-switches are used to configure operation mode for LLF ( Link A. Select the appropriate length Category 5e or 6 twisted pair cable. Loss Forwarding ) and operation modes for the UTP/Fiber ports. Connect one end of the twisted pair cable to the RJ-45 connector DIP-switch setup is as follows: on the converter and the other end of twisted pair cable to the RJ- 45 connector on any 10/100 Base-TX device.
