Travis Industries Tempest Portable Torch Owner's Manual
Portable torch
Hide thumbs
Also See for Tempest Portable Torch:
- Owner's manual (20 pages) ,
- Troubleshooting manual (15 pages)
Table of Contents
Advertisement
Quick Links
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- An LP cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and Immediately call your gas supplier
or fire department.
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause injury
or property damage. Read this manual thoroughly before installing or servicing this
equipment. For assistance or additional information consult a qualified installer,
service agency, or the gas supplier.
Installer:
After installation give this manual to the homeowner and explain
operation of this appliance.
© Copyright 2013, T.I.
$10.00
Tempest™ Portable Torch
Natural Gas (sku 94900763) - Propane (sku 94900773)
Tested &
Listed By
ANSI Z21.97-2012/CSA 2.41-2012, CGA 2.17-M91 (R2009)
Outdoor Decorative Gas Appliances - Report # 028-F-83b-5
WARNING: For Outdoor Use Only
Part # 100-01204_000
Owner's Manual
Oregon USA
Portland
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Travis Industries Tempest Portable Torch
Summary of Contents for Travis Industries Tempest Portable Torch
- Page 1 Tempest™ Portable Torch Owner’s Manual Natural Gas (sku 94900763) - Propane (sku 94900773) Tested & Portland Listed By Oregon USA ANSI Z21.97-2012/CSA 2.41-2012, CGA 2.17-M91 (R2009) Outdoor Decorative Gas Appliances - Report # 028-F-83b-5 WARNING: For Outdoor Use Only WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Introduction
This serial number will be needed in case you require service of any type. Mail your warranty card or visit traviswarranty.com to register your Tempest torch. If any service issues may arise, contact your dealer for details. © Travis Industries, Inc. 100-01204_000 4050608... -
Page 3: Table Of Contents
Placement Requirements ........14 Do Not Locate the Torch: ........14 Clearances: ............14 LP and NG Configuration ........15 Fuel Requirements – Natural Gas ....... 15 Fuel Requirements – LP (Propane) ..... 15 © Travis Industries, Inc. 100-01204_000 4050608... -
Page 4: Safety Precautions
Always follow the instructions in this manual. • Travis Industries, Inc. grants no warranty, implied or stated, for the installation or maintenance of your torch, and assumes no responsibility of any consequential damage(s). - Page 5 Installation and repair should be done by a qualified service person. • Do not alter torch in any manner. • Do not use the torch unless it is COMPLETELY assembled and all parts are securely fastened and tightened. © Travis Industries, Inc. 100-01204_000 4050608...
- Page 6 Inspect torch before each use. If a damaged part is detected, do not operate until an original equipment replacement part has been properly installed. • Use only Travis Industries, Inc. factory authorized parts. The use of any part that is not factory authorized can be dangerous. This will also void your warranty. •...
-
Page 7: Features & Specifications
Dimensions: 3" 76mm 8-7/8" 8-7/8" 225mm 225mm Rain Cap 19-1/2" 84" 495mm 2134mm 9-1/2" 9-1/2" 241mm 241mm 3" 76mm 2-1/2" 20" 64mm 508mm NOTE: All Clearances are measured from the glass (and glass frame). © Travis Industries, Inc. 100-01204_000 4050608... -
Page 8: Installation Warnings
3/8” Lock Washer • 1/8” Hex Wrench Torch Head Components (see pages 11-13) • Main Assembly • Burner Top • (4) Support Bars (w screws) • Top Plate • Rain Cap • Glass Kit (4 pieces) © Travis Industries, Inc. 100-01204_000 4050608... -
Page 9: Post And Base Assembly
Attach the weight plate to the base with the included 3/8-16 bolt, lock washer, and nut NOTE: Two holes are provided in the base if you wish to secure the torch to a deck or other surface. © Travis Industries, Inc. 100-01204_000 4050608... - Page 10 (and hole) in the shroud and attached to the gas supply. Slide the post into the base platform and secure with the six pre-installed set-screws in the platform (use the included 1/8” hex wrench). © Travis Industries, Inc. 100-01204_000 4050608...
-
Page 11: Post Mount And Control Cover Installation
(e) Attach the control cover to the torch with the two thumb screws. ! The safety label slides into place between the control cover and the torch body. © Travis Industries, Inc. 100-01204_000 4050608... -
Page 12: Torch Assembly
! Tighten the bolt only enough to hold the glass in place – over- tightening may break the glass. Repeat steps “d” and “e” for the other three pieces of glass. © Travis Industries, Inc. 100-01204_000 4050608... -
Page 13: Optional Rain Cap
Place the rain cap on top of the torch so the four studs insert through the top plate. With one or two pieces of glass removed, secure the rain cap using the included nuts (shipped pre-attached to the rain cap). © Travis Industries, Inc. 100-01204_000... -
Page 14: Placement Requirements
(see the illustration to the right). This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. © Travis Industries, Inc. 100-01204_000 4050608... -
Page 15: Lp And Ng Configuration
Fuel Requirements – LP (Propane) The gas pressure regulator provided with the kit must be used. The regulator is set for an outlet pressure of 11” wc. It must be installed in accordance with all local codes. © Travis Industries, Inc. 100-01204_000 4050608... -
Page 16: Operation
Inspect the torch, burner, and supply lines for any damage prior to operation. The burner must be replaced prior to the appliance being put into operation if it is evident that the burner is damaged. Use only Travis Industries replacement burners. It may be difficult to see the burner operating in direct sunlight. -
Page 17: Lighting The Torch - Wet Weather
Disconnected cylinders must have a threaded valve plug tightly installed and must not be stored in any building, garage, or other enclosed area. Flammable materials must not be stored in the cylinder enclosure. Always store Propane cylinders in a secured upright position, out of the reach of children. © Travis Industries, Inc. 100-01204_000 4050608... -
Page 18: Lp (Propane) Portable Cylinder Installation
Check the LP regulator and cyclinder fittings. Make sure no debris is on the fittings and there is no damage to the connectors. Connect the LP regulator to the cylinder. To disconnect the cylinder, unscrew the regulator and follow the directions above in reverse order. © Travis Industries, Inc. 100-01204_000 4050608... -
Page 19: Maintenance
“OFF”, reconnect the gas connection and re-test. If you continue to see bubbles after several attempts, disconnect gas source and contact your dealer for assistance. If no bubbles appear after one minute turn tank “OFF”, wipe away solution and proceed. © Travis Industries, Inc. 100-01204_000 4050608... -
Page 20: Replacement Parts
250-00409 ORIFICE, BURNER - No. 55 250-00753 ORIFICE, BURNER - No. 50 93006523 PILOT ELECTRODE, S.I.T. PILOT# 93006518 THERMO-COUPLE - S.I.T. # Replacement parts can be obtained from your Tempest torch retailer (see www.tempesttorch.com). © Travis Industries, Inc. 100-01204_000 4050608... -
Page 21: Troubleshooting Table
Vent hole on back of the LP regulator is blocked. Clear any obstructions from the vent Regulator Makes Noise NOTE: The regulator makes a slight hole. (LP ONLY) whisper sound while in use – this is normal. © Travis Industries, Inc. 100-01204_000 4050608... -
Page 22: Warranty
TRAVIS INDUSTRIES, INC. TRAVIS INDUSTRIES, INC., at its option, will repair or replace, free of charge, your TRAVIS appliance if it is found to be defective in material or workmanship within the time frame stated within this 1 year warranty. TRAVIS INDUSTRIES, INC. will return your appliance, freight charges prepaid by TRAVIS INDUSTRIES, INC., to your regional distributor, or dealership. - Page 23 Notes This page is left blank for additional installation, maintenance, or operational notes. © Travis Industries, Inc. 100-01204_000 4050608...
-
Page 24: Index
Post Mount and Control Cover Installation ....11 Replacement Parts ............. 20 Safety Precautions ............. 4 Specifications .............. 7 Torch Assembly ............12 Troubleshooting Table ..........21 Turning the Torch Off ..........17 Warranty ..............22 Winterizing The Torch..........19 © Travis Industries, Inc. 100-01204_000 4050608...
