Microlab SOLO7C User Manual page 3

80- SOLO7C -97-0001-01 20071016
Technical Information
Features:
*Designed for Multimedia PC, High Performance to Price Ratio.
*Complete wooden box with elegant wooden finish make pure sounds, avoid sound mixture.
*The system is magnetically shielded which can be put near the monitor or TV, and without
magnetic influence.
*The ultimate aim of Microlab R&D system is to inherit and carry forward the European musical
culture style. To do this, all designs must be music-oriented and sourced from music and art.
Having Microlab, you can enjoy European musical taste.
Specification
*Amplifier specification:
Power output 55Wx2 RMS
Frequency response 5 Hz-70KHz
Sensitivity Input 440mV
≥
Separation 55 dB
S/N 85 dB
*Acoustic specification:
Frequency range 55 Hz-20KHz
Sensitivity 85dB
Driver unit: 6. 5"x2 (magnetically shielded) +1"
*Audio input: (Input 1) RCA jack
(Input 2) RCA jack
(L Speaker) screw terminal
*Audio output: screw terminal
* Product size(DxWxH): 325x220x558mm
SOLO7C(07 )
20.Serving Do not attempt to service this product yourself, as opening or removing covers may expose you to dange
21.Replacement parts When replacement parts are required, be sure the service technician has used replacement
22.Mains fuses For continued protection against fire hazard, use fuses only of the correct type and rating. The corre
23.Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the
24.The only means of completely disconnecting the product from the power supply is by removing the power cord fro
25. The socket-outlet shall be installed near the equipment and shall be easily accessible.
Unpacking:
You should find following items while unpacking:
The apparatus is left unused for a long period of time.
－
voltage or other hazards. Refer all servicing to qualified service personnel.
－
specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions ma
result in fire, electric shock or other hazards.
－
specification for each voltage range is marked on the product.
speaker may be damaged when a peak level section is suddenly played.
wall outlet or the product. Either the wall outlet or the power cord entry to the product must remain freely accessibl
times while the apparatus is in use.
Unpacking the system
*Fold the carton flaps right back and invert the carton and contents.
*Lift the carton clear of the contents.
*Remove the inner packing from the product.
We suggest you retain the packing for future use.
R(main) Speaker 1pc
L(sub) Speaker 1pc
Remote control 1pc
3.5mm-2RCA signal cable 1pc
Speaker cable 1pc
User's manual 1pc
