SERVICE MANUAL
Ver 1.1 2001. 12
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance of
about 200 mm from the objective lens surface on
the optical pick-up block with 7 mm aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm) (CLV)
Number of channels
2
Frequency response
20 - 20 000 Hz +1/–2 dB
Wow and flutter
Below measurable limit
Sony Corporation
9-929-256-32
2001L1600-1
Home Audio Company
© 2001.12
Published by Sony Engineering Corporation
PHC-Z10
Model Name Using Similar Mechanism NEW
CD
CD Mechanism Type
Section
Optical Pick-up Name
Model Name Using Similar Mechanism NEW
TC
Section Tape Transport Mechanism Type
SPECIFICATIONS
Radio section
Frequency range
FM: 87.5 - 108 MHz
AM: 531 - 1 602 kHz
IF
FM: 10.7 MHz
AM: 450 kHz
Aerial
FM: Lead aerial
AM: Loop aerial
Cassette-corder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 100 s (sec.) with Sony cassette C-60
Frequency response
TYPE I (normal): 100 - 10 000 Hz
PERSONAL COMPONENT SYSTEM
AEP Model
UK Model
KSM-213CCM
KSS-213C
MF-PHCZ10T
— Continued on next page —
