1997-99 CR-V – ALL
Applies To:
Noisy Rear Differential
SYMPTOM
A squealing or moaning noise is heard from the rear of
the vehicle when the front tires are slipping during
acceleration or when the vehicle is turning.
PROBABLE CAUSE
Water entered the differential through the breather tube
and contaminated the differential fluid.
CORRECTIVE ACTION
Flush the differential with new fluid and/or replace the
differential clutch set.
PARTS INFORMATION
Breather Tube Assembly: P/N 41130-P6R-020
Differential Clutch Set: P/N 48010-P6R-305
Rear Differential Mounting Bracket:
P/N 50710-S10-A01
Honda Dual Pump Fluid: P/N 08200-9002
WARRANTY CLAIM INFORMATION
In warranty: The normal warranty applies.
Description
Flush the differential
Flush the differential; replace the differential
clutch set, the mounting bracket, and the
breather tube
Flush the differential; replace the clutch set
and the breather tube
Flush the differential, and replace the clutch
set
Failed Part: A/T, P/N 41011-P6R-315
M/T, P/N 41011-P6R-316
DIAGNOSIS
1. Test-drive the vehicle on a dirt or gravel road. From
a stop, accelerate hard to make the front tires slip.
• If the rear differential makes noise, go to the
REPAIR PROCEDURE.
• If the rear differential does not make noise, go to
step 2.
 2000 American Honda Motor Co., Inc. – All Rights Reserved
Export Service Bulletin
2. Test-drive the vehicle in a circle on a paved, open
REPAIR PROCEDURE
1. Start the engine. Hold the engine at 3,000 rpm with
2. Raise the vehicle on a hoist.
3. Circulate the Dual Pump Fluid through the clutch
4. Engage both differential pumps:
FRT
0.6
3.7
5. Turn the ignition switch OFF, and put the vehicle in
3.0
6. Drain the rear differential.
2.8
7. Test-drive the vehicle as you did for DIAGNOSIS.
8. Remove and disassemble the rear differential.
9. Remove and discard the original differential clutch
XTB 22224 (0011)
parking lot at about 10 mph while holding the
steering wheel in a full-lock position.
• If the rear differential makes noise, go to the
REPAIR PROCEDURE.
• If the rear differential does not make noise,
disregard this bulletin and troubleshoot other
causes.
no load (in Park or Neutral) until the radiator fan
comes on.
assembly:
• On A/T models: Apply the parking brake, put the
transmission into D
, and let the vehicle idle for 5
4
minutes.
• On M/T models: Put the transmission into 1st
gear and engage the clutch. Slowly apply the
parking brake until just before the engine stalls.
Let the engine run like this for 5 minutes.
• On A/T models: Release the parking brake, and
let the vehicle idle in D
• On M/T models: Release the parking brake, and
let the vehicle idle in 3rd or 4th gear for 5
minutes.
Park or Neutral.
• If the fluid looks and smells burnt, go to step 8.
• If the fluid looks normal and does not smell, refill
the differential, repeat steps 3 thru 6 two more
times, then go to step 7.
• If the differential is still noisy, go to step 8.
• If the noise is gone, return the vehicle to the
customer.
Refer to section 15 of the 1997 CR-V Shop Manual.
assembly and the shim.
00-901
November 2000
for 5 minutes.
4
1 of 2
