Outdoor GreatRoom Company Crystal Fire Owner's Manual

Decorative gas appliance
Hide thumbs Also See for Crystal Fire:

Advertisement

Model:
Crystal Fire
Decorative Gas Appliance
• Important operating
and maintenance
instructions included.
WARNING
If the information in these instruc-
tions is not followed exactly, a fire
or explosion may result causing
property damage, personal injury,
or loss of life.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do
not use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier,
call the fire department.
• Installation and service must be per-
formed by a qualified installer, service
agency, or the gas supplier.
WARNING
Improper installation, adjustment, alteration service
or maintenance can cause injury or property damage.
Read the installation and maintenance instructions
thoroughly before installing or servicing this equipment.
The Outdoor Greatroom Company
CAUTION
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
The Outdoor Greatroom Company • Crystal Fire • Rev1
- 1 -
Owner's Manual
• Leave this manual
with party responsible
for use and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
• Keep children away.
• CAREFULLY SUPERVISE children near or
around this appliance.
• Alert children and adults to hazards of high tem-
peratures.
• Keep clothing, furniture, draperies and other com-
bustibles away.
WARNING
For outdoor use only.
WARNING
Its imperative the burner be kept clean.
Installation and service of this appliance should be
performed by qualified personnel. Fire Stone Home
Products suggests NFI certified or factory-trained
professionals, or technicians
supervised by an NFI certified
professional.
Installation and Operation
GAS-FIRED
LISTED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Crystal Fire and is the answer not in the manual?

Questions and answers

Rickie Diehl
May 26, 2025

Need to know what valve the black key shuts off

Wassil
May 8, 2025

What size is the natural gas orfice

Subscribe to Our Youtube Channel

Summary of Contents for Outdoor GreatRoom Company Crystal Fire

  • Page 1 Read the installation and maintenance instructions supervised by an NFI certified thoroughly before installing or servicing this equipment. professional. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 1 -...
  • Page 2 Your new Crystal Fire will give you years of durable use and As the owner of a Crystal Fire, you’ll want to read and care- trouble-free enjoyment. fully follow all of the instructions contained in this owner’s manual.
  • Page 3: Table Of Contents

    C. Gas Connection ..........9 D. High Altitude Installations ......... 10 B. Limited One Year Warranty ......20 E. LP Gas Supply ..........10 C. Contact Information .......... 21 The Outdoor Greatroom Company • Crystal Fire • Rev1 - 3 -...
  • Page 4: Listing And Code Approvals

    Input rate The Crystal Fire has been tested in accordance with IAS should be reduced by 4% for each 1000 ft above a 2000 US requirements for Outdoor Gas Fireplaces, Draft 4-96 ft elevation in the U.S.A., or 10% for elevations between...
  • Page 5: Getting Started

    CAUTION DOOR USE ONLY and MUST NOT be used for cooking. Place the Crystal Fire on a flat and stable surface in an out- Check building codes prior to installation. door location such as a patio or deck. This location must be •...
  • Page 6: Step By Step Lighting Instructions

    Step 1. Remove top from tank cover. Step 4. Make sure electrode is sparking. Step 2. Turn gas on at tank. Step 5. Turn shut-off valve to “ON” position. Step 3. Begin pressing sparker. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 6 -...
  • Page 7: Framing And Clearances

    72 inches to overhang from top of metal bowl. SIDE WALL SIDE WALL 72” 24” 24” METAL BOWL Figure 3.1 Clearances to Combustibles The Outdoor Greatroom Company • Crystal Fire • Rev1 - 7 -...
  • Page 8: Framing Enclosure For Lp Gas Supply System

    180 degrees (3.14 rad) and unobstructed. Every opening must have minimum dimensions to permit the entrance of a 1/8 inch (3.2 mm) diameter rod. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 8 -...
  • Page 9: Gas Information

    (In Fittings and connections may have loosened during the Commonwealth of Massachusetts installation must shipping and handling. be performed by a licensed plumber or gas fitter.) The Outdoor Greatroom Company • Crystal Fire • Rev1 - 9 -...
  • Page 10: High Altitude Installations

    • When an LP model is not in use, the LP gas must be turned off at the supply cylinder. • The specific size and capacity of the cylinder(s) to be used: 20 lb. or hard plumbed to propane tank. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 10 -...
  • Page 11: Appliance Setup

    • Position the hose out of pathways where people might trip over it or in areas where the hose might be subject to accidental damage. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 11 -...
  • Page 12: Operating Instructions

    For assistance or additional information consult that control compartment, burners and circulating a qualified installer, service agency or the gas supplier. air passageways of the appliance be kept clean. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 12 -...
  • Page 13: Lighting The Appliance

    “OFF” position when the appliance is not in use. • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 13 -...
  • Page 14: After The Appliance Is Lit

    Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the sound produced by a furnace or heating duct. Metallic noise This noise does not affect the operation or longevity of the appliance. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 14 -...
  • Page 15: Finishing

    • Using non-listed accessories may result in a safety hazard. • Only Fire Stone Home Products approved accessories may be used safely. Figure 7.2 Chat Fire Granite Top Surround The Outdoor Greatroom Company • Crystal Fire • Rev1 - 15 -...
  • Page 16: Converting To Natural Gas

    Converting to Natural Gas Crystal Fire Natural Gas Conversion Kit (Part # 2006-330) Step 4. Remove brass orifice from flex line. Step 1. Shut off gas supply at tank or source. Step 2. Shut off gas valve at appliance. Step 5. Follow the above steps 3 and 4 in reverse order with new natural gas orifice.
  • Page 17: Troubleshooting

    Troubleshooting With proper installation, operation and maintenance your Crystal Fire will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualified service person in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualified service technician.
  • Page 18: Maintaining And Servicing The Appliance

    Verify manifold and inlet pressures. Adjust regulator as required. Gas Hose The gas hose with regulator supplied with the appliance must be used. The replace- with Regulator ment must be those specified by the appliance manufacturer. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 18 -...
  • Page 19: Reference Materials

    Ball Valve (LP) SRV-BV-CF On/Off Valve (NG) SRV-OO-CF Electronic Piezo CF-Sparker Gas Hose with Regulator SRV-Hose-CF Ignition Electrode CF-Electrode Replacement Glass for Crystal Fire CF20-Glass CF20 Log Set CF20-Logs The Outdoor Greatroom Company • Crystal Fire • Rev1 - 19 -...
  • Page 20: Limited One Year Warranty

    The maximum amount recoverable under this warranty is limited to the pur- chase price of the Product and, if The Outdoor Greatroom Company is unable to provide replacement or repair in an expedient and cost-effective manner, The Outdoor Greatroom Company may discharge all obligations under this warranty by refunding the purchase price of the Product.
  • Page 21: Contact Information

    Important operating and maintenance instructions included. • Read, understand and follow these instruc- tions for safe installation and operation. • Leave this manual with party responsible for use and operation. The Outdoor Greatroom Company • Crystal Fire • Rev1 - 21 -...
