JBL PRX715 Specifications

JBL PRX715 Specifications

Prx700 series 15" two-way full-range main system/floor monitor 1500watt high-performance powered speaker system
Hide thumbs Also See for PRX715:

Advertisement

Quick Links

15" TWO-WAY FULL-RANGE
MAIN SYSTEM/FLOOR MONITOR
COMPACT, ULTRA-LIGHTWEIGHT SYSTEMS...
PERFORMANCE YOU CAN TRUST
The PRX715 is the next step in the highly successful PRX Series and introduces
the fi rst use of JBL's patented Differential Drive
Differential Drive technology incorporates lower mass in the ferrite magnet
for reduced weight while maximizing power amp effi ciency for greater heat
dissipation and increased power handling. Powering the PRX715 is a 1500 Watt
high performance, exceptionally low distortion biamplifi cation system engineered
to deliver clean power with maximum headroom to effi ciently deliver smooth
high frequencies and rich, deep bass response even at very high sound power
levels. Compact, ultra-lightweight, the PRX715 uses JBL's tour tested technology
throughout so you can trust it to deliver a lifetime of reliable performance.
KEY FEATURES
HIGH PERFORMANCE DRIVERS
37.5mm (1.5 in) Annular Polymer Diaphragm, Neodymium
Magnet Compression Driver Resulting in Crystal Clear Highs
and Sonic Accuracy. Wide coverage angles are achieved
without compromise and harmonic distortion is minimized for
maximum driver SPL without harshness.
LOW FREQUENCY
JBL's Tour Tested Differential Drive
heat dissipation, lower power compression and higher dynamic
range versus conventional single-coil designs resulting in better
sound quality and higher SPL. In addition, PRX700 woofers use
magnetically saturated pole-pieces and an aluminum shorting ring
which signifi cantly reduces nonlinear distortion.
AMPLIFICATION
Highly effi cient Class-D amplifi cation drives Maximum Sound
Pressure Levels are the best indication of the performance of
a powered speaker and all PRX700 Series excel in this critical
specifi cation. JBL's ability to maximize the speaker and amplifi er
performance guarantees ample power, accurate dynamics and
sonic purity.
ROAD TOUGH CONSTRUCTION
Built from a combination of 25 mm (on the top and bottom for
added rigidity) and 18 mm, strong, light-weight poplar plywood
made structurally sound with tongue and groove joints. JBL's tour
proven DuraFlex™ fi nish, grilles from dent-resistant 16 gauge
steel, and light-weight glass-fi lled nylon handles ensure strength
and durability. All M10 suspension points are constructed from 14
gauge steel and have been tested with a yield-strength of 1000
lbs. each. A seriously rugged package that will withstand the
brutality of constant road use.
Technology with ferrite drivers.
®
technology provides better
1500
WATT
HIGH-PERFORMANCE
POWERED SPEAKER SYSTEM
47.5
21.6
/
LB
KG
FOR EASY PORTABILITY
90
50
°
°
/
H
V
BEST IN CLASS COVERAGE
