VIDEO DOORPHONE SYSTEM WITH IMAGE MEMORY AND INTERCOM OWNER’S MANUAL INSTALLATION AND OPERATION BEFORE INSTALLING OR, OPERATING THE SYSTEM, PLEASE READ THIS MANUAL VI 450 MODEL:...
Table of Contents Section Page Important Safety Instructions…………………......…..3 Introduction......……………..........4 System Contents......……………..........4 Features............…………......4 Precautions............……………....5 Identifying the Parts........…..……………....….6 Terminal Inputs and Outputs……………………….………….……..7 Installation............……………....8 System Set-up......…....…………….....9 Operation....……...………....…....…..9 Expansion Options......…..……………....10. Identification, Installation & Set-up for MO 451...………..……...11 Identification, Installation & Set-up for CA 456..………..…..13 Installation and Set-up for CA 455..…………………………..14 Door Release Function……………………………………………15 Trouble Shooting Guide....…....……………....16...
Important Safety Instructions WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE OR POWER ADAPTER TO WATER OR MOISTURE Read Instructions – All the safety and operating instructions should be read before operating this equipment. These instructions should be retained for future reference Heed Warnings –...
Introduction Thank you for purchasing the Home Sentinel Video Door phone entry system. This model allows you to identify and communicate with callers at the door, from the security and convenience of any room in your home. Visitors activate the system by pressing a call button on the outdoor camera, which sounds a doorbell chime as well as turning on the inside video monitor.
Precautions • Use only the power adapter supplied with the system. The use of any other power adapter may cause damage to the system which is not covered under warranty • Keep it dry. If water should get on it, wipe it off immediately.
Rotate to adjust sharpness of image AC adapter Fasten Screws: Used to mount the wall plate VI 450 Monitor ( Terminal Inputs and Outputs ) OUT - Connect to the IN - and IN + terminal of the MO 451 Expansion monitor...
Installation Door Release Monitor CA 455 CA 456 CA 456 CA 456 MO451 Please note: Turn off the power to all units being used before connecting or disconnecting cables 1. Choose a suitable location, then fasten the wall mount plate to the monitor unit using the two wall mounting screws provided.
System Set-Up 1. To enter set-up mode for on-screen programming press and hold the left button( Broadcasting and Intercom Button ) for 2 seconds when the handset is “ on the hook “ . You will hear a chime before entering Set-up mode. 2.
Operation 3. Inspect New Memory • Slow flash on the memory status LED indicates memory is captured • Press and hold the middle button for 2 seconds, you will hear a chime before entering the Inspection mode • Press left & right button to scroll pictures •...
Identification, Installation, and Set-up Procedure for an expansion Monitor Station MO 451 4“ B/W Flat CRT Screen AC adapter 1. Pin Socket 6 Pin socket located on the wall mount plate is the connecting terminal for the expansion monitor 2. Wiring Terminals Terminals used to connect to the main monitor unit or other expansion monitors 3.
Page 12
Identification, Installation, and Set-up Procedure for an expansion Monitor Station MO 451 6. On Line W/Door Unit LED Indicates other monitor unit is on line to camera unit 7. Brightness Control Rotate to adjust the picture brightness of image 8. Sharpness Control Rotate to adjust sharpness of image 9.
Identification, Installation, and Set-up Procedure for an expansion Monitor Station MO 451 • When the monitor unit is on-line with the camera unit, you can press the Broadcasting/Intercom button to invite other monitor units for conversation with the camera unit 2.
Identifying the Parts 1. Microphone This highly sensitive microphone will pick up sound within the effective operating range of the camera 2. Linking Wires To hook unit up with main monitor unit 3. CCD Camera Delivers a clear detailed picture to the monitor 4.
- The new CA 455 Door Camera includes selectable door release outputs, either a Normally open dry contact or 12V DC, 300mA - The normally open dry contact output activates the existing door bell unit together with the VI 450 system Jumper Pin Door Release Monitor N.O.
Trouble Shooting Guide Before requesting service, check the troubleshooting guide to solve the problem Problem Solution No Power Make sure that the AC plug is ( no picture on monitor) firmly inserted into the AC outlet Make sure that the DC Power socket is firmly inserted into the mounting monitor unit System is on, but no...
Specifications Monitor Unit Power Source: Full range switching power AC 100V (0.7A) ~ AC 250V (0.35A) DC 18V, 12V, 5V Power Consumption: CRT Screen: 4" B/W Flat type TV system: B/W NTSC Resolution: Over 420 TV Lines Conversation Time: 90 seconds Conversation System: Handset with 2 way full duplex audio intercom...
Home Sentinel will at its option, replace or repair the product free of charge and return the product to you postage prepaid. This warranty does not apply to the product which has been damaged, misused, altered or repaired by anyone other than a Home Sentinel authorized service facility.
