- Page 1 Sixteen Channel XLR Balanced Patch Bay USER'S GUIDE...
-
Page 2: Important Safety Instructions - Read First
IMPORTANT SAFETY INSTRUCTIONS - READ FIRST This symbol, wherever it appears, This symbol, wherever it appears, alerts you alerts you to the presence of uninsulated to important operating and maintenance dangerous voltages inside the enclosure that instructions in the accompanying literature. may be sufficient to constitute a risk of shock. - Page 3 OVERVIEW The ART P16 Sixteen Channel XLR Balanced Patch Bay is a deceptively simple, yet surprisingly useful addition to any serious collection of audio equipment. A patch bay organizes your cables and provides a convenient, easily accessible central location to make all of your audio connections. It also saves wear and tear on the connectors of your audio equipment because all connections are now made and changed at your patch bay.
- Page 4 The most basic use for the P16 is to extend connections from the back of audio devices that are hard to reach using XLR cables to the back of the patch bay in a rack. From the front, you can then patch these connections to any place you want.
-
Page 5: Warranty Information
This warranty is void if the serial number is altered, defaced, or removed. ART reserves the right to make changes in design or make additions to or improvements upon this product without any obligation to install the same on products previously manufactured. - Page 6 You may want to consult with your dealer for assistance in troubleshooting or testing your particular configuration. 2. If you believe that the ART unit is at fault, go to www.artproaudio.com. You may contact Customer Service for more assistance, or directly request a Return Authorization for service in the “resources”...
-
Page 7: Specifications
SPECIFICATIONS Connectors Balanced XLR (female front, male rear) CMRR > -95 dB (typical) Channel to channel isolation > -95 dB (typical) Enclosure Steel 1U high, 19" rack mount Dimensions (HWD) 1.75” x 19” x 3.5” 44mm x 483mm x 89mm Weight 3.2 lbs. - Page 8 www.artproaudio.com E-mail: cserve@artproaudio.com © 2010 Applied Research & Technology V1.0...
