INV5100

USER MANUAL

Optimum Standalone NVR
Version 1.0.5
About this user manual
Before installing and using this NVR unit, please read this user manual carefully.
.
Be sure to keep it handy for later reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INV5100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IPUX INV5100

Summary of Contents for IPUX INV5100

  • Page 1: User Manual

    INV5100 USER MANUAL Optimum Standalone NVR Version 1.0.5 About this user manual Before installing and using this NVR unit, please read this user manual carefully. Be sure to keep it handy for later reference...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 Introduction ..........................2 Overview ............................ 2 Product Components ........................4 Front Panel ..........................5 Rear Panel ..........................6 Chapter 2 Installation ..........................7 HDD Installation ........................7 Hardware connection ......................... 7 Setup NVR via Wizard ......................8 Chapter 3 Getting Start ..........................

  • Page 3: Chapter 1 Introduction

    (ARM 11MP with MMU) platform for superior performance and stability. This NVR systems can support iPUX IP camera series for 6CH A/V recording and let you access your recordings quickly and reliably. With this NVR system, customers can rapid deploy their IP surveillance application with optimum surveillance and operating efficiency and delivers a better security and stability than the counter-part Windows®...
  • Page 4  Windows® remote client and WEB remote client support  CMS and 3G mobile surveillance support Hardware Specification Model INV5100 Type Default/Max. CH Processor Dual-core 750MHz (ARM 11MP with MMU ) Memory 128MB DDR2 SDRAM 256MB NAND Flash HDD Tray(Shipping w/o HDD)

  • Page 5: Product Components

    Recording Backup recording video of previous day to ftp server Recording Speed: Max. 6CH, 180FPS@1080P Copy button to copy recording video to USB device System recording Recording Mode: Continuous/motion/alarm Support network firmware upgrade recording, multiple continuous/motion/alarm Support remote system shutdown and reboot Security recording schedules Recording Buffer: Adjustable for pre-event recording...

  • Page 6: Front Panel

    1.3 Front Panel Description Power button (blue when turned on) Blue = System ready Flashing blue = System is starting up or shutting down Flashing green = Data access Red = System firmware is upgrading Orange = USB drive connected (front port only) Flashing orange = video clips copy from NVR to USB drive(front port only) USB copy button (press to copy video clips from NVR to USB drive on the Copy...

  • Page 7: Rear Panel

    1.4 Rear Panel Label Description USB 2.0 host port Gigabit Ethernet port DC +12V Power receptacle Reset System reset button Security lock slot Note: To reset the configurations (e.g. admin password, DHCP settings, preferences, etc.), make sure the power is ON and the system is running. Press and hold the Reset button for 5 seconds and then release it.

  • Page 8: Chapter 2 Installation

    Chapter 2 Installation 2.1 HDD Installation 1. Remove the screw at the bottom of the case and lift the front panel upward and away from the housing to remove it. 2. Install the hard drives as illustrated below with the top of the drives, where the label is located, facing each other.

  • Page 9: Setup Nvr Via Wizard

    existed ) 2. Connect the other end of the network cable to your Ethernet hub or switch. 3. Connect the power supply to your device first and only then plug it into the wall outlet. The system starts up automatically as soon as you plug in the power supply. It takes about 1-2 minutes for the device to go online but the blue system LED will indicate when the system is ready.
  • Page 10 5. Choose your preferred language and then click the Next button 6. Click Search button, the NVR Setup Wizard will start searching for all the available NVRs on the LAN currently. Choose one of them, and then click the Next button.
  • Page 11 7. Type in the admin password (default is “1234”), click the OK button and then click the Next button. 8. Type in the NVR hostname, http port (default is 80) and eth0/eth1 network setting, and then click the Next button. ...
  • Page 12 Secondary DNS Server manually. 9. Add cameras for this server. Click Search to automatically find all IP cameras on the LAN currently. (adjust the Timeout parameter of the left bottom if can’t find any connected IP camera, the default value is 60 seconds) Select the check box next to the desired IP camera or All for all IP cameras, and then click Next button.
  • Page 13 11. Click Start up NVR remote client or Start up NVR Web client to bring up the NVR remote client or Web client. 12. Click the Exit button to finish the settings procedure and activate the NVR unit.

  • Page 14: Chapter 3 Getting Start

    Chapter 3 Getting Start After the installation is done, you can begin to operate the NVR unit to monitor, playback the connected IP cameras and manage the functions of the NVR unit via Windows® remote client. 3.1 Login Click the Start button -> NVR Client -> NVR Remote Client at your Windows® desktop. When the client is up, you will see the following login window.

  • Page 15: Live Display Screen

    The entered NVR would be listed in the drop-down menu at the NVR Name field. You can select available NVR units from the drop-down menu during next time you log in and the system will fill in the related fields automatically and you only need to reenter the Password field to login your NVR unit.
  • Page 16 System bar In the system bar, you may see system information including the login user name, the address of the NVR unit you connect to and the following buttons: Icon Description Press to minimize Windows® remote client. Press to close Windows® remote client. Press to enter emap screen.
  • Page 17 Camera is being recorded/not being recorded. Camera detects motion. The camera title box and bounding box of camera view window will be shown in white color. It will change to orange color when it becomes as the focus window. Double-click left mouse button on a given grid will enlarge its size and double-click right mouse button on a given gird will reduce its size.
  • Page 18 Device panel shows all the connected devices of NVR. A device can be an NVR, IP camera or a network I/O module. The device node will be shown in red color in case of abnormal. Expanding each device will show subordinate devices, such as sensor input devices or alarm output devices on network I/O modules.
  • Page 19 Press to enter single view mode. Press to enter quad view mode. Press to enter 1+5 split view mode. Press to enter full screen view mode. Press to show video in original aspect ratio. Press to take a snapshot from focus camera view window.
  • Page 20 、 、 、 、 、 、 、 Press arrow( ) to adjust the TILT(up/down)/PAN(left/ right) position. Press to go the default position. Press to zoom in/zoom out the PTZ. Press to adjust the PTZ focus. Press to adjust the PTZ iris. Preset Press Up/Down arrow to the preset point, and then press Set to set the preset point...

  • Page 21: Emap Screen

    Event panel shows latest events from the NVR or its connected IP cameras, with their status, type, date/time, camera name, description and device IP information. New events are constantly appended to the top of the list and old events will be removed from the list. Icon Description Alarm happen and still exist...
  • Page 22 Emap panel shows all the connected maps and devices of NVR. A device can be an Emap, NVR, IP camera or a network I/O module. The device node will be shown in red color in case of abnormal. Expanding each device will show subordinate devices, such as sensor input devices or alarm output devices on network I/O modules.

  • Page 23: Playback Screen

    3.4 Playback Screen Most of the functions are the same as those seen in live display screen, but there are some differences in the playback screen. Playback screen Search panel There are several different types of search methods that can be performed on the NVR unit. The basic one is timeline search involves selecting the date, camera, time and then play.
  • Page 24 4. Click OK to begin search. Time line panel Select a time by dragging the red bar or clicking the left and right arrows to the right of the time display. icons can zoom in and out the timeline scale. And then the video can be played forwards, backwards, or frame-by-frame as following: Playback control Icon...
  • Page 25 LED panel The LED panel will show the playback date/time and the play control information when in playback screen.

  • Page 26: Chapter 4 System Setup

    Chapter 4 System Setup The Windows remote client allow you to optimize your NVR unit by adjusting settings like camera, record, event, account, storage, network, system, DIO, log and license. It is extremely important that you setup your NVR correctly. 4.1 Camera Setup Camera setup page Cameras can be added to Camera List in two ways: automatic or manual.
  • Page 27 2. Click Search button to list all the currently available cameras. 3. Select the check box next to the desired camera. 4. Specified the channel ID(of video server) for the desired camera. 5. Click Apply button to apply the change or Return button to cancel the change. 6.
  • Page 28 8. Click Apply button to apply the change or Cancel button to cancel the change. Manual add cameras Click an desired camera on the Camera List. Enter the Camera Name.
  • Page 29 Check Camera Enable and Audio Enable to active the video and audio channel Enter the IP Address and Port on the Device Column. Enter the Admin Account and Password. Select the Vendor and Model for your IP camera or click Detect button to obtain it automatically.
  • Page 30 1. Specify the number of video streams are provided by IP camera at the same time 2. Select a stream profile from the stream profiles drop-down menu for NVR Stream 1. 3. Change the default video codec (H.264, MPEG-4 or MJPEG), resolution, frame rate, bit rate/quality setting if needed.

  • Page 31: Record Setup

    Clicking the Image tab and then adjust the following sliders to change the camera image: Bright: move the Bright slider bar to the right or left to adjust the brightness. Contrast: move the Contrast slider bar to the right or left to adjust the lighting difference between dark and light areas of the image.
  • Page 32 1. Select a camera for recording. 2. Select Copy To Cameras for copy current settings to other cameras. 3. Select Always, Event, Schedule or No Record mode. Note: For event record mode, the camera will begin recording when NVR detects motion o from cameras (can be the same or other cameras) or digital input of network I/O modules.
  • Page 33 5. Event record mode: Specify Pre-Alarm Recording time (maximum 30 seconds), Post-Alarm Recording time (maximum 30 seconds) and event sources (motion or digital input). 6. Schedule record mode: Press left mouse button, drag a red rectangle over the Week Schedule area to specify a week day/time frame and then release the mouse button.

  • Page 34: Event Setup

    Click any blue bar (the blue bar will be shown with yellow border), click the Modify button and then change the from/to time for schedule modification. Click any blue bar (the blue bar will be shown with yellow border), click the Delete button to remove the schedule.
  • Page 35 Add an event 1. Click Add button. 2. Select the Event Type from the drop-down menu.
  • Page 36 3. Select the Source in case of video motion, camera disconnected, video loss and digital input events. 4. Enable the Schedule and specify the start/end time if the event can only be triggered within specified time. 5. Specify the event actions including event log, digital output (the delay time and duration time can be specified) and email alert with attached recording video (the clip length can be specified).

  • Page 37: Account Setup

    4.4 Account Setup The account setup is set to provide individual user role-based permissions, including access rights on specific channels while live view, playback, export, backup, PTZ control, DI/DO control, password change, Emap access, view/change setup. You can setup user accounts with different permissions.
  • Page 38 Add a user 1. Click Add button. 2. Fill in User Name, Password, Reconfirm (password must be typed twice for confirmation purposes), Type (administrator, power user, normal user or guest user), Enable (check this box to enable this account), and idle client timeout period (disconnected if remote client idle more than this period) information for the new account.
  • Page 39 4. Specify the permissions for specified channels including live view, playback, export, backup, PTZ control, DI/DO control, password change, Emap access, view/change setup for the specified channels. 5. Click Apply button to apply the change to Account List or click Cancel button to cancel the change.

  • Page 40: Storage Setup

    Delete a user Select a user on the Account List column. Click Delete button. Click Apply button to apply the change to Account List or click Cancel button to cancel the change. 4.5 Storage Setup Storage setup page shows all information related to HDD Drives installed on the NVR, it including: 1.

  • Page 41: Network Setup

    3. The summary column will show the total storage capacity, status and RAID rebuild progress in case of rebuild RAID. Change HDD mode 1. Select independent mode or RAID mode. 2. Check Auto-Format to format any new installed or crashed HDD when boot NVR. 3.
  • Page 42 To connect NVR to LAN or Internet, you need to: 1. Enter the NVR Host Name, HTTP port (default is 80), Streaming port (default is 8888) 2. Enable SSH (for remote maintenance purpose). 3. Enable UPnP(will show NVR information in Network of your Windows PC) 4.
  • Page 43 5. DDNS(Dynamic Domain Name Server) allows you to connect NVR with dynamic IP address. You can refer to http://www.no-ip.com/services/managed_dns/free_dynamic_dns.html and register an account, and then: Enter your account in User Name field. Enter your password in User Password field. iii. Select the Sync Period to setup interval for IP/DDNS synchronization.

  • Page 44: System Setup

    Enter your SMTP server. Enter User Name of SMTP server iii. Enter User Password of SMTP server Enter the sender address of event notifications 7. Click Apply button to apply the change or click Cancel button to cancel the change. 4.7 System Setup System setup page is used to show system information, modify time zone/system time, backup data, control local console and system maintenance.
  • Page 45 The system information tab shows the following items. • Model • Firmware Version • Camera Capacity • MAC Address • System Memory • CPU Usage Modify Time Zone/System Time...
  • Page 46 Select current Time Zone from the drop-down menu. Specify current year, month and day from the calendar. Specify current time and click Apply Time button to apply the change. (the default time is set according to the real-time clock on server. Select the mechanism for time sync.
  • Page 47 The NVR can backup recording video of previous day to ftp server as following: Enter the IP address of FTP server. Enter the User Name and Password. Set up the Backup Path for backup files. Enter the Backup Storage Capacity. Enter the Start Time for backup Select the cameras for backup Click Apply button to apply the change or click Cancel button to cancel the change.
  • Page 48 Backup/Load Configuration 1. Click Backup/Load button. 2. Browse a destination/file for backup/load. 3. Click the OK button. 4. A confirmation dialog pops up. 5. Click the OK button to confirm and start backup/load. 6. After configuration load, the NVR will restart automatically. Reset to Default Configuration 1.

  • Page 49: Dio Setup

    4.8 DIO Setup The NVR can handle the digital input/relay output devices via AP-SIO20 network I/O module. Digital input/alarm output devices are connected directly with AP-SIO20 network I/O module, and digital input/alarm output signals are converted to Ethernet through AP-SIO20 network I/O module.
  • Page 50 Select Model of network I/O module from the drop-down menu. Specify the IP Address for network I/O module. Specify the Din port (default is 103) and Dout port (default is 102). Specify the name and NC/NO connection for each digital input device.(blue LED stand for normal status, red LED stand for abnormal status) Specify the name for each relay output device and click ON/OFF button to turn on/turn off relay output device.

  • Page 51: Log

    4.9 Log The Log setup page shows recent event and login logs. In case of abnormal event or system malfunction, the logs can be searched to analyze the related events or system problems. Log page 1. Select Event or Login log. 2.

  • Page 52: Map

    video loss, storage full, hard disk failure, abnormal recording, backup failure, system boot-up, system shutdown and system configuration changed events) or Login’s username and source (local or remote). 3. Specify the search time range. 4. Click Search button will show the results in Log List column. 4.10 Map 1.
  • Page 53 4. Place Camera, NVR, network I/O module, Din, Dout and Map to anywhere on the top layer map by right click on the top layer map and select Add Object. 5. Select an object type and then enter their name, source IP, index and icon. 6.
  • Page 54 9. Add a Din object: 10. Add a Dout object: 11. Add a sub-layer map object:...
  • Page 56 12. Click Apply button to apply the change or click Cancel button to cancel the change.

  • Page 57: Chapter 5 Web Client

    Chapter 5 WEB Client Open Internet Explorer browser and enter NVR’s IP address in URL field. Go to the IP address, users have to choose a language and enter the correct User Name and Password to login this NVR system. Note: Using WEB client for the first time, please add this NVR as browser’s trusted sites to make sure WEB client has download privilege: 1.

  • Page 58: Chapter 6 Cms Client

    Chapter 6 CMS Client The CMS client is a multiple NVRs management software. You can operate NVR units via CMS client to monitor, playback the connected NVRs, import multiple-layered maps which display the location of all NVRs, IP cameras, network I/O modules and digital input/output devices and manage the functions of the NVR systems.

  • Page 59: Emap Screen

    6.3 Emap Screen Please refer to section 4.3 for the details. 6.4 Playback Screen Please refer to section 4.4 for the details. 6.5 CMS Setup Page NVR setup page NVRs can be added to NVR List in two ways: automatic or manual. Automatic add NVR 1.
  • Page 60 2. Click Search button to list all the currently available NVRs. 3. Select the check box next to the desired NVR. 4. Click Apply button to apply the change or Return button to cancel the change. 5. Click an available NVR on the NVR List. 6.
  • Page 61 Account setup page The account setup is set to provide individual user role-based permissions, including access rights on specific channels, Dins and Douts. Add a user 1. Click Add button. 2. Fill in User Name, Password. 3. Select NVR that the user has access rights. 4.
  • Page 62 Event setup page The event setup page shows recent event logs. In case of abnormal event or system malfunction, the logs can be searched to analyze the related events or system problems. 1. Check the Search Condition. 2. Specify the Start Time and End Time for search time range. 3.
