GB OK
2-01-2003
14:05
GB
Thank you for choosing this coffee machine. To get
the very best out of your new coffee machine it is
advisable to read these instructions before using the
appliance. This is the only way to ensure optimum
results and maximum safety.
DESCRIPTION OF THE APPLIANCE
The following terms are used throughout the instruction
manual
1 Shelf for cups
2 Release lever
3 Coffee measure holder
4 Milk tank
5 Sliding lock
6 Froth regulator
7 Emulsion chamber lid
8 Milk tank lid
9 Water tank
10 Cup stand
11 Drip tray
12 Espresso boiler outlet
13 Pressing pad
14 Coffee measuring spoon
15 Filter holder for pods (if fitted)
16 Filter for pods (if fitted)
17 Filter holder for coffee
18 Filter for coffee with frother
19 ON/OFF switch
20 Espresso delivery switch
21 Steam switch
22 ON/OFF pilot light
23 Coffee-ready pilot light
24 Steam-ready pilot light
25 Cleaning brush
SAFETY WARNINGS
• This machine has been built to "make coffee" and to
"reheat beverages"; please be careful to avoid burns
from the sprays of hot water or steam and avoid any
improper use.
• When the appliance is in use, do not touch any of the
machine's hot surfaces.
• After unpacking, make sure that the machine is
complete and undamaged. In case of doubt, do not
use the appliance and seek the advice of a qualified
service professional.
• Packaging materials (plastic bags, foam polystyrene,
etc.) should not be left within the reach of children as
this could be a potential source of danger.
• This appliance is to be utilised for domestic use only.
Any other use is to be considered improper and
12
Pagina 12
therefore, dangerous.
• The manufacturer takes no responsibility for damage
derived from improper use.
• Never touch the appliance with wet or damp hands.
The appliance is not intended for use by young
•
children or infirm persons without supervision.
Young children should be supervised to ensure that
•
they do not play with the appliance.
• In case of breakdown or malfunctioning, turn off the
appliance immediately and do not touch it. For
repairs, please contact a Service Centre authorized
by the manufacturer and request the use of original
replacement parts only. The lack of respect for this
point may compromise the safe use of the appliance.
• The power supply cable of this appliance must never be
replaced by the user, because its replacement requires
the use of special tools. If the cable should become
damaged, or in case it needs to be replaced, please go
to a Service Centre authorized by the manufacturer.
• When the appliance is not in use, turn off and
disconnect the plug from the socket.
INSTALLATION
• Place the coffee maker on flat work surface at a safe
distance from taps and sinks.
• Check that the voltage corresponds to that indicated on
the appliance rating plate. The appliance must always
be connected to a well-earthed socket rated at 10 A
minimum. The manufacturer is not liable for damage
caused by inadeguate earthing of the appliance.
• n the event of incompatibility between the plug on the
appliance and the socket, have the plug replaced
with another of the right type by a qualified
professional.
If the cable is damaged or requires replacing,
contact a service centre authorised by the
manufacturer only.
• Never install the machine in an environment that can
reach a temperature less than or equal to 0°C (if the
water in it freezes, the coffee maker may be damaged).
