CONFIDENTIAL
LCD PROJECTOR
PRODUCT SPECIFICATIONS
MODEL PJ-TX10 (C10H)
PJ-TX10W for Asia, Canada and USA(HAL-HED)
PJ-TX10E for Europe
PJ-TX10W(AU) for Australia
VER.1.1
Approved by
Date
History
Ver 1.1
3.4
CIE SATURATION
Blue center value y = 0.05 -> 0.04
August 04, 2003
Hitachi, Ltd.
Digital Media Division
Minoru Kato
Senior Engineer

Advertisement

Table of Contents
loading

Related Manuals for Hitachi PJ-TX10

Summary of Contents for Hitachi PJ-TX10

  • Page 1 CONFIDENTIAL LCD PROJECTOR PRODUCT SPECIFICATIONS MODEL PJ-TX10 (C10H) PJ-TX10W for Asia, Canada and USA(HAL-HED) PJ-TX10E for Europe PJ-TX10W(AU) for Australia VER.1.1 Approved by Date History Ver 1.1 CIE SATURATION Blue center value y = 0.05 -> 0.04 August 04, 2003 Hitachi, Ltd.
  • Page 2 1.GENERAL 1.1 OPTICAL STRUCTURE 3 LCD panels, one projection lens, RGB shutter method 1.2 LCD PANEL 0.55inch, P-Si TFT panel x 3, Stripe pixel configuration 854 dots x 480 lines x 3 panels Drive method: TFT Active Matrix, with micro lens 1.3 LENS F1.6~2.9 (f=14.2 ~ 28.4mm) Manual Zoom...

  • Page 3: Additional Features

    1.13 ADDITIONAL FEATURES Mirror Reverse Image Up-side Down Image Picture Freeze by RS-232C Magnify 4 times by RS232C My Memory 3D Y/C Separation for NTSC composite signal 2-3 Pull Down for NTSC 3D Noise Reducer Digital Gamma Correction R/G/B Color Adjustment ASPECT selection For Video: 4:3/16:9/Wide/MOVIE-1/MOVIE-2 For RGB: 4:3/16:9/15:9/31:15...

  • Page 4: Power Supply

    R.G.B in (RGB) 15 Pin D-Sub Pin assignments NO. RGB Component Video Component Video Cr/Pr N.C. PLUG DETECT Green Blue Cb/Pb N.C. N.C. SDA (DDC) H/Composite Sync GND(Red) GND(Cr/Pr) Vsync GND(Green) GND(Y) SCL (DDC) GND(Blue) GND(Cb/Pb) Control (RS232C) 9 Pin D-sub Pin assignments 1.16 POWER SUPPLY AC90 ~ 132V / AC198 ~ 264V (50/60Hz), 3 Wire Grounded 1.17 POWER CONSUMPTION 100 ~ 120V/220 ~ 240V, 50/60Hz 2.4 /1.1A typ., Max.
  • Page 5 1.22 CONTAMINATION Filtration at intake vent Dust Protection to prevent visible dust collection all optical component on or near the focal plane. (*) *) At just focused position on image, dust is not clearly noticed and size is 16 pixels maximum (4x4, 3x5, 2x8) 1.23 KENSINGTON SLOT 1.24 REGULATORY (AGENCY, SAFETY, EMI/RFI) APPROVALS...

  • Page 6: Included Accessories

    1.25 INCLUDED ACCESSORIES Power Cord For US/Canada/Asia; (US, Euro, UK) x 1 For Europe; (UK, Euro) x 1 For Australia; (Au) x 1 RCA Video/Audio Cable (3 m) x 1 Wireless Remote Control Unit "AA" Batteries x 2 Rivet x 1 Strap x 1 Scart Adapter x 1 (Supplied by HEL and packed exclusively for Europe) Language Operator's Manual x 2 ( 5 languages each)
  • Page 7 OUTWARD PJ-TX10W/E/W(AU) ver 1.1...

  • Page 8: Electrostatic Discharge

    2. ENVIRONMENTAL CONDITION 2.1 AMBIENT TEMPERATURE Operating 0 ~ 35 °C Storage -20 ~ 60 °C 2.2 HUMIDITY Operating 10 ~ 85% RH Without condensation Storage 10 ~ 85% RH Without condensation 2.3 ALTITUDE From sea level to 6000 feet 2.4 SHOCK (HANDLING) Withstand 50 mm drop on bottom on wooden table 2.5 GAS...

  • Page 9: Image Quality

    3. IMAGE QUALITY Apply following condition except where noted. • Apply heat-running for 10 minutes or more before checking • Ambient temperature is 23 °C • Whisper: Normal, Gamma: Normal, • Vertical Lens shift: 1:1, Horizontal Lens shift: 1:1 • Zoom: Wide max, Foot adjust: Retracted (Set should be even with the ground. 3.1 BRIGHTNESS 560 lumens minimum (Note 1) ANSI 9 point Standard measurement at Screen size 40inch, Meter CL-200...

  • Page 10: Contrast Ratio

    CONTRAST RATIO 120:1 minimum 200:1 Typical (Target) (Note) ANSI standard measurement. Vertical Lens shift: 10:0. (A black-and-white " chessboard " pattern consisting of 16 equal rectangles) All white, All black 560:1 Minimum, 800:1 Typical (Target) (Note) Vertical Lens shift: 10:0. 3.4 CIE SATURATION at Default setting White...
  • Page 11 DOT DEFECT (1) SPECIFICATIONS ITEM Max. NUMBER Mode Color A-Zone B-zone Total Transmittance Green More than 10% See below *1 Sparkle Red Blue Green Area Black More than 75 % Blue * ; not defined • A sparkle mode defect and a faint sparkle mode defect When a pixel is partially or completely transmittable during an entirely black raster.

  • Page 12: Video Signal Input

    4. ELECTRICAL VIDEO SIGNAL INPUT (1) Composite 1.0 ± 0.1 Vp-p at 75 Ω terminated Amplitude Input impedance 75Ω (2) S-VIDEO Y: 1.0 ± 0.1 Vp-p at 75 Ω terminated with composite sync Amplitude C: 0.3 ± 0.1 Vp-p at 75 Ω terminated Input impedance 75Ω...

  • Page 13: Audio Signal Input

    4.3 AUDIO SIGNAL INPUT Amplitude 200 mV rms 47K Ω Input impedance 4.4 REMOTE CONTROL Range with new battery Front Front: 5.0m minimum ±30 ° (Horizontal, Vertical) PJ-TX10W/E/W(AU) ver 1.1...
  • Page 14 5. PACKING 5.1 PACKAGING FORM See Figure 5.1 Packaging materials; Plastic bag, cushion and carton box ＷｘＨｘＤ 459x 333 x 401 mm (nominal) Gross weight 7.6 kg Pallet size 1223 x 1132 x 938 mm (W x H x D) 5.2 VIBRATION There shall be no damage or change of performance out of this specification after the following vibration test with factory fresh packing.
  • Page 15 Figure 5.1 PJ-TX10W/E/W(AU) ver 1.1...
