3M Aqua-Pure AP817 Specifications

Spec #
Quantity

Applications:

• Particulate/Rust*
• Chlorine Taste and Odor (CTO)*
AP817
AP817-2

Product Specifications:

Dimensions
Model No.
(Part No.)
Height
AP817
9-7/8" (25.1 cm)
(56027-01)
AP817-2
20-1/8" (51.1 cm)
(56027-07)

At a Glance:

• Polyethylene Outer Shell
• PolyKLEAN
• Granular Activated Carbon

Product Benefits:

• 25 micron sediment is captured on the rigid polyethylene outer shell
• 40,000 gallon carbon reduction capacity at 10 gpm provides up to 6 months service
for all your home's water
• Radial flow design allows for use of finer, more effective activated carbon and
yields a very low pressure drop
• Double open ended design fits most large diameter housings. Cartridge will filter
water regardless of which way it is installed in housing
• Neoprene gaskets on both top and bottom provide exceptional sealing in any hous-
ing, helping to prevent bypass of unfiltered water down-stream
Flow Rate
Diameter
4-5/8" (11.7 cm) 10 gpm (37.9 lpm)
4-5/8" (11.7 cm) 20 gpm (75.7 lpm)
Models:
AP817 / AP817-2
Whole House Water Filters
™ Center Core
Max. Water Temp. Degree of Filtration
100°F (37.8°C)
100°F (37.8°C)
* Claims not tested or certified by NSF
25 micron nominal
25 micron nominal
