Summary of Contents for Gigafast EE400-R

  • Page 1: User Manual

    EE400-R Broadband Router User Manual EE400-R GigaFast Ethernet.
  • Page 2 They are used for identification purposes only. Specifications are subject to be changed without prior notice. GigaFast Ethernet. 1100 S Hatcher Ave #C City of Industry, CA 91748 USA Tel: 626-964-2960 Fax: 626-964-2690 e-mail: gfeusa@gigafast.com http://www.gigafast.com Copyright © 1998 - 2002, GigaFast Ethernet. All Rights Reserved. EE400-R GigaFast Ethernet.

  • Page 3: Fcc Interference Statement

    This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022/A1 Class B, and EN 50082-1. This meets the essential protection requirements of the European Council Directive 89/336/EEC on the approximation of the laws of the member states relation to electromagnetic compatibility. EE400-R GigaFast Ethernet.

  • Page 4: Table Of Contents

    3.1.4 EZ Setup - LAN..................20 3.2 T ..............24 ELNET ONSOLE ONFIGURATION 3.2.1 Device Information and Administration configuration in EE400-R ..25 3.2.2 WAN Setup....................27 3.2.3 LAN Setup....................29 3.2.4 Advanced function .................. 30 CHAPTER 4 ADVANCED FIREWALL FUNCTION............32 4.1 A ....................
  • Page 5 Appendix C Cabling and Pin Assignment..........48 Appendix D Configure IP manually........... 51 Appendix E Technical Information ........... 53 EE400-R GigaFast Ethernet.

  • Page 6: Chapter 1 Introduction

    Chapter 1 Introduction Congratulations on your purchase of this outstanding Broadband Router EE400-R. This product is the perfect option to connect a group of PCs to a high-speed Broadband Internet connection or to an Ethernet based Backbone (ETTH/ETTB: Ethernet To The Home/Building). Configurable as a DHCP server, this product is the only externally recognized server device on your local area network (LAN).

  • Page 7: Package Contents

    One CD-ROM (manual/utility) One power adapter One CAT-5 UTP cable One RS232 cable 1.3 System Requirement One Ethernet based broadband Internet connection (i.e. cable/DSL modem or other router) One PC with a NIC card and Installed TCP/IP protocol stack. EE400-R GigaFast Ethernet.

  • Page 8: Panel Description

    1.4.1 Front Panel Device Indicators PWR (power): The Power LED illuminates whenever the EE400-R is powered on. RDY (ready): The RDY LED blinks once per second when it is working normally, or it will blink faster or be off if there is something wrong.

  • Page 9: Rear Panel

    LAN Indicators Lnk/Act Lnk (link): ON means LAN PC/device is connected correctly to EE400-R. Act (activity): Blinking means there is data communication. If the LED is continuously illuminated, it means the LAN device is successfully connected or the port is working now.

  • Page 10: Chapter 2 Installation

    2.1 Hardware Connection to WAN Connect the network cable from the Cable/ DSL modem to the WAN port of the EE400-R (Figure 2-1). If the Link/Act light is off, check that the power and the network cable between the Cable/DSL modem and WAN port are plugged in correctly.

  • Page 11: Network Setting In Administrator ' S Computer

    2.3 Network Settings in Administrator’s computer In order to configure the EE400-R with a networked PC in the LAN, it is necessary for the administrator to have correct network settings in the PC, so that the communication between the EE400-R and the administrator ‘s PC is possible.
  • Page 12 The system may ask you to restart. If so, restart now. After restart, the connection should be established. Please check it as follows. Windows 9x/Me : Click Start and select Run… Type “winipcfg”, and click [ok]. EE400-R GigaFast Ethernet. P 11...
  • Page 13 192.168.8.1. If everything is correct, the network should be working now. Please go to the next Chapter to continue setup. If something is wrong, please refer to Chapter 5 for troubleshooting. EE400-R GigaFast Ethernet. P 12...

  • Page 14: Chapter 3 Device Administration

    No matter which method is used, this administration only allows one login session at a time. This is in consideration of database consistency. If anyone else tries to log in, it will fail and the EE400-R will pop-up an alert message.

  • Page 15: Device Information

    Type in the default Administrator password, ”admin”. Then click enter to login. 3.1.1 Device Information After login, the first page is the Device Information of the EE400-R. This page shows the detailed status of the EE400-R and displays the current WAN’s information about dial-up duration and traffic (bytes count) EE400-R GigaFast Ethernet.

  • Page 16: Administration

    Upgrade Firmware: Click [browse] to choose the correct firmware upgrade file (*.upg). When a file has been selected, click [Go] to send the request. The EE400-R’s firmware will be upgraded immediately. After a moment, EE400-R will restart automatically. Miscellaneous Commands: [View system events log] records system events such as system start , administrator log-in / log-out, dial/hang-up and hacker intrusion events.

  • Page 17: Ez Setup - Wan

    Resets the system settings to factory default, and restart automatically after completion. [Restart System]: Forces the EE400-R to restart immediately. 3.1.3 EZ Setup - WAN Click the EZ Setup-WAN link in the left frame. There are 4-connection types in this page.
  • Page 18 Static connection is used when a fixed IP address is used. Certain ISPs will assign a static, or unchanging, IP address. Please check with your ISP to find out. If you have a Static IP, select the “static” option and fill in the blanks according to the information provided by your ISP. EE400-R GigaFast Ethernet. P 17...
  • Page 19 WAN IP Address: The IP Address of the EE400-R as seen by external users on the Internet (including your ISP). WAN Subnet Mask: The EE400-R WAN IP address ranges. (i.e. 255.255.255.248) WAN Gateway: The ISP will provide you with the Gateway IP Address.
  • Page 20 C. PPPoE Connection If the EE400-R is connected to the Internet through a DSL line, ask the ISP if they use PPPoE for dial-up service. If they do, select the PPPoE option then fill in: Your PPPoE account and PPPoE password. (The PPPoE Service Name may be optional depending on the ISP).

  • Page 21: Ez Setup - Lan

    If something is wrong, please browse the system event log to check the dial/log-in activity. (refer to 3.1.2) 3.1.4 EZ Setup - LAN Click the EZ setup-LAN link on the left frame to setup LAN. EE400-R GigaFast Ethernet. P 20...
  • Page 22 The DHCP Server is enabled by default. If the LAN IP is changed, the administrator may lose the connection with the EE400-R when they are not in the same LAN segment. Administration operation will not work until they are in the same segment again.
  • Page 23 DNS Proxy: LAN computers get their DNS server from the EE400-R first. The EE400-R will search the ISP’s DNS automatically. IP pool from 192.168.8.x to 192.168.8.x: Whenever there is a request, the DHCP server will offer unused IPs from the IP address pool to the requesting computer.
  • Page 24 . DHCP Server Disabled Disable DHCP Server function of EE400-R. You just have to fill in LAN IP Address and then press [Save&Restart] button. EE400-R GigaFast Ethernet. P 23...

  • Page 25: Telnet/Console Configuration

    The telnet-based configuration is almost the same as console configuration. The difference is that console configuration requires being connected to the EE400-R with your computer by null modem cable (Please refer to Apendix C-2). Telnet configuration can only be used via Lan.

  • Page 26: Device Information And Administration Configuration In Ee400-R

    3.2.1 Device Information and Administration configuration in EE400-R When you select 1 to enter the device information, you can see the device information as follows: Press Esc to exit. Select 2 to enter administrator setup. EE400-R GigaFast Ethernet. P 25...
  • Page 27 Window’s built-in terminal does not provide this feature. Set Date/Time: Press 3 for this setting. Set the date and time separately. Date/Time needs to be initialized every time the EE400-R is reset. Whenever the administrator logs on via web browser, the date/time is calibrated automatically according to the login PC.

  • Page 28: Wan Setup

    ISPs will assign a static, or unchanging, IP address. Please check with your ISP to find out. If you have a Static IP, select the “static” option and fill in the blanks according to the information provided by your ISP. EE400-R GigaFast Ethernet. P 27...
  • Page 29 ISP). Dial on Demand: If you choose this option, EE400-R will attempt to connect with the ISP, if (1) there is at least one LAN user trying to access the Internet and (2) the current WAN connection is disconnected.

  • Page 30: Lan Setup

    3.2.3 LAN Setup The LAN Setup configuration in a telnet environment has 2 items. LAN IP Address: type in the IP address of the EE400-R as it is seen by the internal LAN computers. If Telnet is used and the LAN IP is changed, the administrator may lose connection with The EE400-R when they are not in the same LAN segment, so administration will not work until they are in the same segment again.

  • Page 31: Advanced Function

    DHCP Server enabled A. Enable/Disable DNS Proxy: LAN computers get their DNS server from the EE400-R first. The EE400-R will search the ISP’s DNS automatically. B. Set DHCP IP Pool Range: Whenever there is a request, the DHCP server will allocate an unused IP from the IP address pool to the requesting computer.
  • Page 32 Allow/Deny Respond to Ping from WAN: Allow or Deny responding if there are any Ping packet sent to WAN of the EE400-R. Allow/Deny Web Management from WAN: This function allows the administrator to configure the EE400-R from the outside Internet with a browser directly. In order to reserve HTTP service (port 80), which is used for virtual servers, the remote web administration function utilizes another port 64511 instead.

  • Page 33: Chapter 4 Advanced Firewall Function

    Click the Access Control link in the left frame. There you will see the 3 options shown below. Respond to Ping from WAN: Allow or Deny responding if there is any PING packet sent to the WAN of the EE400-R. This is very useful to avoid Internet intruders/hackers from probing the computer. Most likely, the hacker will not start to attack.

  • Page 34: Service Time Allocation

    This function allows the administrator to inhibit LAN users from using some Internet services for management purposes. For example, if the EE400-R is used in a SOHO environment and the administrator wants to inhibit LAN users from using Telnet services (like BBS, on-line chat), then it is easily achieved by blocking all packets to service port 23.
  • Page 35 “Service Time Allocation” allows the administrator to control the EE400-R’s LAN-to-WAN if the service is available or disabled at any time. This feature is implemented through two mechanisms. One method is to specify the maximum continuous service period. This is primarily used for parental control in home/family applications.

  • Page 36: Url Keyword Blocking

    LAN-to-WAN service is on or off according to a predefined daily schedule table. 4.3 URL Keyword Blocking In order to prevent LAN users from accessing specific websites, the EE400-R provides a function to perform such a filtering mechanism. The administrator can enter the URL keywords of which websites are to be rejected.

  • Page 37: Virtual Server

    Internet. However, some Internet servers (like WWW, FTP, E-mail) should be visible and accessible by the outside Internet. As a result, the EE400-R provides Virtual Server functions to meet this demand. In addition, the EE400-R also protects the servers and all other computers in the LAN simultaneously.

  • Page 38: Dmz

    There are more and more Internet applications need 2-way access right (like video and/or audio conference, on-line game..). EE400-R provide the similar features to make some computers in LAN to have unrestricted 2-way access privilege. As a result, all computers in DMZ are most compatible with Internet applications.

  • Page 39: Multiple Dmz Host

    If the WAN connection type is static and there is a range of IP addresses assigned to the WAN interface instead of a single IP (please refer to section 3.1), then the EE400-R allows 4 computers in the LAN to become DMZ hosts.
  • Page 40 For example, if the ISP provides IPs 210.65.226.1 through 210.65.226.7 (subnet mask 255.255.255.248), then the subscriber can have 6 computers at most accessing the Internet simultaneously. With the EE400-R, additional computers can access the Internet. (Please refer to Figure 4-1) EE400-R GigaFast Ethernet.
  • Page 41 EE400-R Figure 4-1 Bridging mode Unfortunately, the multiple DMZ host will not work with the Figure 4-1 configuration because the EE400-R can only handle one IP address, not 5 IP addresses. In such conditions, the bridging mode option is available for Multiple DMZ.

  • Page 42: Chapter 5 Troubleshooting

    Check to see that the EE400-R’s LAN connections are properly connected and the unit is powered on. Set the EE400-R to factory default condition. Ensure that your PC and the EE400-R are on the same network segment. If you are not sure, initiate the DHCP function to let the PC get an IP address automatically.

  • Page 43: Frequently Asked Questions

    Reset your cable/DSL modem by powering the unit off for 20 seconds and then turn it back on. Once it has completed its tests, reset the EE400-R by holding down the reset button for at least 5 seconds with the power on and try installation again.
  • Page 44 9. Is the EE400-R cross-platform compatible? Yes, any platform that supports Ethernet and TCP/IP is compatible with the EE400-R. 10. Can I use my own public IPs and Domain or do I have to use the IPs provided by the router? You can customize your own IPs through configuration of this router.

  • Page 45: Appendix A Tcp/Ip Well-Known Port

    Name (TCP) Description FTP-DATA FTP(data) FTP(command) TELNET Terminal Connection SMTP SMTP DOMAIN Name Domain Name Server FINGER Finger HTTP POP3 POP3 AUTH Authentication Service NETBIOS-SSN NETBIOS Session Service 1723 PPTP Point to Point Tunneling Protocol EE400-R GigaFast Ethernet. P 44...

  • Page 46: Appendix B Illustrated Typical Application

    Appendix B Illustrated Typical Application B-1 Home User Application EE400-R Figure B-1 Home user application - DSL/Cable modem EE400-R Figure B-2 Home user application - ISDN/V.90 Modem EE400-R GigaFast Ethernet. P 45...
  • Page 47 B-2 SOHO environment Application EE400-R Figure B-1 SOHO environment application – Simple IP sharing EE400-R Figure B-2 SOHO environment application - DHCP Server in the EE400-R EE400-R EE400-R GigaFast Ethernet. GigaFast Ethernet. P 46 P 47...
  • Page 48 EE400-R Figure B-5 SOHO environment application - DHCP Server in LAN EE400-R GigaFast Ethernet. P 47...

  • Page 49: Appendix C Cabling And Pin Assignment

    NIC card to a hub. Crossover cables are used for connecting a hub to another hub. (The EE400-R provides a built-in uplink/normal switch. Uplink mode is crossed internally, which allows you to link or connect hubs together with a straight-through cable.) C-1-1 RJ-45 pin assignment There are 8 thin, color-coded wires inside, running from one end of the cable to the other.
  • Page 50 Its interface presupposes a common ground between the DTE and DCE. RS232 is used to connect both the EE400-R and PC or Modem in this case. With different pin specifications, pin assignments are different between DTE (Data Terminal Equipment, usually a computer or terminal) to DCE (Data Circuit-terminating Equipment, usually a modem) and DTE to DTE.
  • Page 51 Signal Ground DCE Ready (DSR) Request to send Clear to send (Male) Ring indicator C-2-2 Connection between the EE400-R and PC console (DTE-DTE) Gate 2000 C-2-3 Connection between the EE400-R and Modem (DTE-DCE) Gate 2000 EE400-R GigaFast Ethernet. P 50...

  • Page 52: Appendix D Configure Ip Manually

    IP Address like 192.168.8.xxx. xxx can be numbers from 1to 253). Set the Subnet Mask to 255.255.255.0. In the Gateway tab, add the IP address of this product. (The default IP Address of this product is 192.168.8.1). EE400-R GigaFast Ethernet. P 51...
  • Page 53 Change to the DNSConfiguration tab. Enable DNS and add DNS values provided by your ISP into DNS Server Search Order. Click [ok] to finish. EE400-R GigaFast Ethernet. P 52...

  • Page 54: Appendix E Technical Information

    : 1lb 3.3 oz Certification : FCC class B, CE mark Operating Temperature : 0ºC to 40ºC (32ºF to 104ºF) Storage Temperature : -20ºC to 70ºC (-4ºF to 157ºF) Operating Humidity : 10% to 85% non-condensing EE400-R GigaFast Ethernet. P 53...
