Gigafast WF717-APR Specifications

GigaFast
54Mbps Wireless Broadband Router
GigaFast's WF717-APR is an IEEE802.11g compliant 54Mbps Wireless Broadband Router used to share broadband
internet connections to Ethernet and Wireless computers. The Wireless Broadband Router has a built-in Internet Firewall to
protect your network from being hacked by outside intruders. It brings high-speed Internet Access to all the computers on your
network and is also protected by 64/128-bit WEP (Wired Equivalent Privacy) encryption, preventing anyone outside of your
network from accessing information on it. Operating in the 2.4GHz frequency range using OFDM (IEEE802.11g), the
GigaFast Wireless Broadband Router is able to provide transparent bridging and roaming capabilities to any other wireless
connections. The WF717-APR is complete with web-based administration, configuring requires nothing but a standard web
browser. No additional software is required to operate the WF717-APR.
Functions:
2.4G
Usage Diagram:
Internet
Wireless Broadband
Router
Desktop (Wireless
USB Adapter)
Wireless
Auto
Uplink
Cable/DSL Modem/Ethernet
Notebook (Wireless
PCMCIA Adapter)
Features:
Share files and resources using built-in switch with
LAN and Wireless LAN
Built-in firewall to prevent unwanted access
High data rate 54/48/36/24/18/12/9/6Mbps
Wired Equivalent Privacy Algorithm (WEP) (64-bits /
128-bits)
Simple web based interface for easy access

Specifications:

WAN Interface
One RJ-45 port, IEEE802.3 100Base-T, CSMA/CD
WAN Cabling
UTP Category 5 (10/100Mbps)
LAN Interface
Four RJ-45 ports, IEEE802.3u, 100Base-T, CSMA/CD
LAN Cabling
UTP Category 5 (switched 10/100Mbps)
Multiple WAN Connection type
Static IP: for lease line or router-router interconnect
DHCP client: for most cable modem service
PPPoE: for dial-up ADSL service
PPTP client: for some European Dial-up
ADSL or L2-VPN application
Wireless LAN
IEEE802.11b, support 1/2/5.5/11Mbps
IEEE802.11g, support 6/9/12/18/24/36/48/54Mbps
Operating Channels
11 channels (US, Canada), 13 channels (Europe)
Encryption
64/128-bit WEP (Wired Equivalent Privacy)
Operating Temperature
0°C ~ 40°C (32F to 104F)
Radio Technology
802.11b - Direct Sequence Spread Spectrum (DSSS)
802.11g - Orthogonal Frequency Division Multiplexing
(OFDM)
Storage Temperature
-20°C ~ 70°C (-4F to 157F)
Operating Humidity
10% to 85% non-condensing
Power Input
DC 9V/1A
Warranty
3-years Limited & Free Technical Support (US Only)
WF717-APR
