Abocom Mini SDIO 802.11b/g Wireless LAN Card SDW11gM Specification Sheet

Mini SDIO 802.11b/g
Description
The SDW11gM is a compact size wireless card for the PDA and other mobile computing
device. The card is designed in the concept to get friendly with battery. When
connected to a WLAN, the card is typically in listening mode almost the time except the short
period of packet being transmitted and received. That means your battery life will be
maximized.
The card works with a lot of wireless LAN security protocols. Open, 64-bit and 128-bit
WEP encryptions are supported.
Specification
Standards
IEEE802.11b/g
Connectors
SDIO
LEDs Power/ACT: always blue ON for power up / Blue blink for data
transferring
Data Rate 11g:6,9,12,1824,36,48,54(OFDM)Mbps
11b:1,2,5.5,11(DSSS/CCK)Mbps
Frequency Range 2.412 ~2.484 GHz band
Range Indoors: 100 meter
Outdoors: 300 meter
Physical
Dimensions: 27L x 20W x 1.4H mm
characteristics Weight: 1.30g
Power consumption Transmission: 330 mA (Max)
Approvals FCC / CE
Operating 0 to 55 ° C
Temperature
Storage Temperature -20 to 70 ° C,
Wireless LAN Card
Features
IEEE 802.11b/g compatible
Supports infrastructure and Ad Hoc Peer-to-Peer connectivity
Internal antenna reduces the card size
Security supported WEP, WPA, WPA-TKIP, WPA2
LED indicates link and activity status
Mini SDIO interface compatible
Support Pocket PC 2003, Mobile 4.2/5.0
Applications
