Whirlpool ADP 6920 Quick Reference Manual

w
Quick reference guide
(see at right for options description)
PROGRAM SELECTION START/RESUME BUTTON
BUTTON Push this button to start the selected program: the
Push "Programs" button indicator lights up and goes off at the end of the
(repeatedly) until the indicator program.
of the required program lights When the door is opened during a washing cycle,
up (see "Table of programs" the cycle is temporarily paused: the Start indicator
below). blinks. To resume the cycle close the door and
push Start button again.
Table of programs
P
Programs
1
Aqua Steam 40-70°C
2
Pre-Wash cold
3
Glasses 40°C
4
Quickwash 45°C
5 2)
50°C
Eco
6
Daily 60°C
1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional
options) and may vary depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the
appliance's automatic calibration system.
2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the
EN/Standard loading comparison test and other tests, contact the following address: "nk_customer@whirlpool.com".
3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.
CANCEL/OFF BUTTON
Push this button to switch off the control panel.
If pressed when a program is running it cancels the
program ongoing draining water for 1 minute (0:01
is shown into the display).
If pressed when the dishwasher is switched off, it
drains any possible liquids from dishwasher
(1minute process).
Available
Loading instructions
options
Normally or heavily soiled crockery, including
Delay
pots and pans. Thanks to steam action, soaking
Multizone
or hand pretreatment is no longer needed. In
Antibacterial
addition hygiene is ensured due to the high
rinse
temperature steam.
Delay
Crockery to be washed later.
Multizone
Delay
Light soiling, for example glasses and cups.
Multizone
Delay Lightly soiled crockery, with no dried-on
food.
Multizone
Delay
Multizone
Normally soiled crockery.
Antibacterial
rinse
Delay
Multizone
Normally to heavily soiled crockery.
Antibacterial
rinse
BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ
THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!
THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING
AUTOMATICALLY AFTER 30 SECONDS IF ANY CYCLE IS STARTED.
Options and display description
SALT INDICATOR
When lit (at the end of the cycle),
the salt reservoir needs to be
refilled.
WASH TIME DISPLAY
Indicated the cycle duration and the remaining time (h:min). With "Delayed start" selected it indicates
the time remaining until program start (h.00) - below 1h (0:mim).
If "Fx Ey" messages appears on the display, see page 6 - chapter "What to do if...".
Consumption
Deter-
MULTIZONE
gent
1) Allows you to choose the washing
Litres kWh
Minutes
zones. Press this button (repeatedly)
to select the wash zones:
X 7-14 1.00-1.80 70-185
— 4.0 0.03 14
X 10.0 0.85 100
ANTIBACTERIAL RINSE
This function activates an
X 11.0 0.80 30
antibacterial rinse at the end of the
wash cycle, guaranteeing a further
reduction of bacteria. Press the
button to activate or deactivate the
X 12.0 1.05 150
function. This function can be used
with the programs indicated in the
table of programs. The dishwasher
door must be kept shut for the entire
X 13.0 1.25 120
duration of the program in order to
guarantee reduction of bacteria. If
the door is opened the indicator lamp
starts flashing.
ADP 6920
ANY BUTTON EXCEPT CANCEL/OFF BUTTON.
FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES
both racks
only lower rack
only upper rack TABLET SETTING
This setting allows to
optimize the cycle
- indicator lits
performances according
the type of detergent
used. Push the Tablet
3)
button for 3 seconds (until
the indicator lights up) if
you are using the
combined detergents in
tablet (rinse aid, salt and
detergent in 1 dose). If you
are using powder
detergent or liquid
detergent, the Tablet
indicator on the control
panel has to be off.
Chart
RINSE AID INDICATOR
When lit (at the end of the cycle),
the rinse aid dispenser needs to
be refilled.
DELAYED START
BUTTON
Push the button
(repeatedly) to delay the
start of the program.
Adjustable from 1 to 24
hours. With each press of
the button, the delayed
start indicator increases
by one hour and after 24
restarts from 0. Then
press the START button.
The dishwasher will start
after the set time.
5019 396 01853
GB -1-
