LG LS181HSV3 Information

Job Name/Location:
Date:
PO No.:
Architect:
Engr:
Rep:
(Company)
LS181HSV3
High Efficiency Single Zone Inverter
Outdoor Unit (ODU) - LSU181HSV3
Performance:
Cooling:
Capacity (Btu/h)
SEER
EER
SEER - Seasonal Energy Efficiency Ratio EER - Energy Efficiency Ratio
Heating:
Capacity (Btu/h)
HSPF
HSPF - Heating Seasonal Performance Factor
Cooling Nominal Test Conditions:
Indoor: 80°F DB/67°F WB
Outdoor: 95°F DB/75°F WB
Electrical:
Power Supply (V¹/Hz/Ø)
Outdoor Unit:
MOP (A)
MCA (A)
Cooling Rated Amps (A)
Heating Rated Amps (A)
Compressor (A)
Fan Motor (A)
MOP - Maximum Overcurrent Protection MCA - Minimum Circuit Ampacity
Total Power Input:
Cooling Power Input (kW)
Heating Power Input (kW)
Piping:
Liquid Line (in, OD)
Vapor Line (in, OD)
Additional Refrigerant (oz/ft)
Max Pipe Length (ft)²
Piping Length (no add'l refrigerant, ft)
Max Elevation (ft)
Controls Features:
•24-Hour on/off mer •Chaos wind
•4-Way auto swing •Condensate Sensor
•Auto changeover Connection
•Auto restart •Energy saving
•Built-in low ambient standard, •Inverter (variable speed
down to 14°F (cooling mode) compressor)
Optional Accessories (sold separately)
LG Programmable Thermostat - PREMTB10U
Low Ambient Wind Baffle (Cooling operation to 0°F) - ZLABGP02A
PI485 - PMNFP14A0
For continual product development, LG reserves the right to change specifications without notice.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. "LG Life's Good" is a registered trademark of LG Corp. /www.lghvac.com
For:
GC:
Mech:
(Project Manager)
Indoor Unit (IDU) - LSN181HSV3
18,200
20.5
12.6
22,000
9.7
Heating Nominal Test Conditions:
Indoor: 70°F DB/60°F WB
Outdoor: 47°F DB/43°F WB
208-230/60/1
15.4
15.4
14.6
0.25
1.45
1.76
3/8
5/8
0.38
98.4
24.6
49.2
•Jet cool/Jet heat
•3M HAF Filter
•Self-cleaning indoor coil
•Sleep mode
•Cooling only func on
File Resubmit
Approval
Other
Operating Range:
Outdoor Unit:
Cooling (°F DB)
Heating (°F WB)
Indoor Unit:
Cooling (°F WB)
Heating (°F DB)
Unit Data:
Refrigerant Type
Refrigerant Control
Refrigerant Charge (lbs)
ODU Sound Pressure (±3 dB(A))³
IDU Sound Pressure (H/M/L) (±3 dB(A))³
ODU Net Unit Weight (lbs)
ODU Shipping Weight (lbs)
25
IDU Net Unit Weight (lbs)
19
IDU Shipping Weight (lbs)
Heat Exchanger Coating
Fan:
ODU Type
IDU Type
Fan Speeds (Fan/Cooling/Heating)
Quantity (ODU + IDU)
Motor/Drive
ODU Max Air Flow Rate (CFM)
IDU Air Flow H/M/L (CFM)
Dehumidification (pts/hr)
Notes:
1.Acceptable opera ng voltage: 187V-253V.
2.Piping lengths are equivalent.
3.Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4.All communica on/power cable to be minimum 18 AWG, 4-conductor, stranded,
shielded and must comply with applicable local and national code.
5.See Engineering Manual for sensible and latent capaci es.
6.Power wiring cable size must comply with the applicable local and na onal code.
7.The indoor unit comes with a dry helium charge.
8.This data is rated 0 above sea level, with 24.6 of refrigerant line and a 0 level
difference between outdoor and indoor units.
9.Must follow installa on instruc ons in the applicable LG installa on manual.
Tag #:
Brushless Digitally Controlled/Direct
DFS-SB-AA-029-US 013H23
14-118
-4-75
64-90
60-86
R410A
EEV
3.97
53
45/40/35
123
131
32
41
GoldFin™
Propeller
Cross Flow
6/6/6
1 + 1
2,119
622/509/399
5.5
Page 1 of 2
