User Manual Pyxis-MM Carrier Module for GPS, Land Line Modem, and Wireless Modem Revision 1.0 November 23, 2004 Copyright 2004 Diamond Systems Corporation 8430-D Central Ave. Newark, CA 94560 Tel (510) 456-7800 www.diamondsystems.com... -
Page 2: Table Of Contents
TABLE OF CONTENTS DESCRIPTION ..........................3 THEORY OF OPERATION .......................4 BLOCK DIAGRAM ........................4 PYXIS-MM PRODUCT CONFIGURATIONS ................5 I/O HEADER PINOUTS......................6 JUMPER SETTINGS ........................9 REGISTER MAP ........................11 OEM MODULES ........................12 SPECIFICATIONS........................15 10. OEM SOFTWARE INCLUDED IN DSC CD-ROM ..............15 765300 - Pyxis User Manual... -
Page 3: Description
1. DESCRIPTION The product is a PC/104 carrier board that can be used to install a GPS module, a wireless modem, and a land line modem. The GPS can be used simultaneously with either modem. Either but not both modems can be used at one time. The board contains serial port circuitry connected to the PC/104 bus to provide communication links with the add-on modules. -
Page 4: Theory Of Operation
2. THEORY OF OPERATION Pyxis-MM provides a connection for the 3 OEM modules listed to the PC-104 bus via an on board 16C2850 dual UART or to an external RS-232 DCE style connector to interface with standard DTE ports. A fairly simple switch is designed into a XC9572 CPLD which is controlled by hardware jumpers to select whether the OEM modules TTL level RS-232 signals are routed to the PC-104 bus through the UART or to a RS-232 transceiver and external connector. -
Page 5: Pyxis-Mm Product Configurations
4. PYXIS-MM PRODUCT CONFIGURATIONS The configurations listed below are the only valid combinations of OEM modules. Never connect a Multitech and Cirronet modem in the same Pyxis-MM board because the signal lines are connected together and can possibly damage both modems. -
Page 6: I/O Header Pinouts
Hardware Kit (DSC# 680009) 681041 Screw,4-40 x 1/4",Pan Hd,PH,Zn 681201 Screw, #2x56x5/8, Flat, Ph, Zn 682021 Nut, #2-56, Zinc 683022 Washer, #2, Locking 683044 Washer, #4 Locking 684244 Standoff, #4-40x.375"x.187" FF 684501 Standoff, Locking, Nylon .25" *For stand alone operation 5. - Page 7 Land line modem connectors RING ~RESET DGND DCD LED RX LED DTR LED TX LED ~RTS ~RXD ~TXD ~DSR ~CTS ~DCD ~DTR DGND AGND SPKR others See Multitech MT5634SMI-ENI product specification for more information. 765300 - Pyxis User Manual Page 7...
- Page 8 Serial Port Headers J5 6-pin header (1x6 right-angle pin header) for connection to Prometheus J10 20-pin header for DCE connection to EMM-XT or C-DB9F-2 DCD 1 DTR 1 TXD 1 CTS 1 RXD 1 RTS 1 DSR 1 RI 1 1-PPS DCD 2 DTR 2...
-
Page 9: Jumper Settings
6. JUMPER SETTINGS J4 3-pin landline modem power input select (1x3 pin header) +5VDC POWER In to LL Modem +3.3VDC Jumper across pins 1 and 2 for +5VDC commercial grade modem module. Jumper across pins 2 and 3 for +3.3VDC industrial grade modem module. CAUTION: Always check the Multitech modem modules data sheet prior to setting this jumper as the wrong input voltage can damage the modem! J6 6 pin base address selection (2x3 pin header) - Page 10 J13 6 pin Serial port direction selection (2x3 pin header) PORT1 *GPS MAIN PORT TO PYXIS UART 1 GPS MAIN PORT TO PYXIS XCVR 1 PORT2 GPS AUX PORT TO PYXIS UART 2 GPS AUX PORT TO PYXIS XCVR 2 *MODEM TO PYXIS UART 2 MODEM TO PYXIS XCVR 2 GPS AUX PORT TO MODEM...
-
Page 11: Register Map
7. REGISTER MAP Note: These registers can only be accessed if the Pyxis-MM is on the PC-104 bus. Base + 0 Read INTERRUPT STATUS Bit No. Name PRT2_LB PRT1_LB INTB INTA Definitions: INTB Port 2 has a pending IRQ. INTA Port 1 has a pending IRQ. -
Page 12: Oem Modules
Base + 2 Read SWITCH CONFIG STATUS Bit No. Name Definitions: Reads current jumper setting. Same. Same. Same. 8. OEM MODULES Trimble’s Lassen SKII Trimble's Lassen™ SK II board is a miniature GPS receiver module with less than half-watt power consumption. - Page 13 Mobile. Used with the companion SNAP2410 access point, the WIT2410 provides seamless roaming. With 16 million factory-set addresses available, the 2410 can move from access point to access point without the need for re-synchronizing. This means the application can be in constant communication with each 2410,...
- Page 14 LED driver outputs for visual monitoring of Carrier Detect, Transmit Data, Receive Data and DTR signals Low cost data only module available Three-number storage for automatic dialing capabilities and non-volatile memory (NoVRAM) to store user profiles Full duplex over dial-up lines TIA-602 AT command compatible Auto-dial, redial and auto-answer 60 character command line buffering...
-
Page 15: Specifications
9. SPECIFICATIONS General Power supply +5VDC +/- 10% Current consumption 198mA typical w/o OEM modules (measured) 268mA Idle w/WIT2410M 199mA Idle w/ WIT2410M in sleep mode 397mA Idle w/ MT5634SMI-ENI 296mA Idle w/ Lassen SK-II 10. OEM SOFTWARE INCLUDED IN DSC CD-ROM Cirronet Setup.exe Installs Cirronets WinCOM24 software.
