Mounting the Switch on a Rack
The GO-SW-16G /24G can be mounted on a wall. Two mounting slots
are provided on the bottom of the switch for this purpose. Please make
sure that the front panel is exposed in order to view the LEDs. Please
refer to the illustration below:
A.) Mounting on a cement wall
1. Mount the Nylon screw anchors into a cement wall.
2. Drive the T3 x 15L screws into the Nylon screw anchors.
3. Hook the mounting holes of the switch back on the screws;
you have completed the wall-mount.
B.) Mounting on a wood wall
1. Drive the T3 x 15 L screws into the wood wall.
2. Hook the mounting holes of the switch back on the screws;
you have completed the wall-mount.
16
