Husky HSK037 User Manual

Portable ac/dc power system
Hide thumbs
Table of Contents

Advertisement

Quick Links

HSK037 ENG MANUAL 090105
9/1/05
5:48 PM
Page 1
HSK037
Portable AC/DC
Power System
USER'S MANUAL
& WARRANTY INFORMATION
I I I I M M M M P P P P O O O O R R R R T T T T A A A A N N N N T T T T S S S S A A A A F F F F E E E E T T T T Y Y Y Y I I I I N N N N F F F F O O O O R R R R M M M M A A A A T T T T I I I I O O O O N N N N , , , , S S S S A A A A V V V V E E E E T T T T H H H H E E E E S S S S E E E E I I I I N N N N S S S S T T T T R R R R U U U U C C C C T T T T I I I I O O O O N N N N S S S S
TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND
THIS INSTRUCTIONAL MANUAL. THIS MANUAL CONTAINS IMPORTANT
INFORMATION REGARDING THE OPERATION AND WARRANTY OF THIS
PRODUCT. PLEASE RETAIN FOR FUTURE REFERENCE.
4140 S.W. 30th Ave., Ft. Lauderdale, FL 33312 U.S.
Toll Free: (866) 584-5504

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSK037 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Husky HSK037

Summary of Contents for Husky HSK037

  • Page 1: Warranty Information

    HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 1 HSK037 Portable AC/DC Power System USER’S MANUAL & WARRANTY INFORMATION I I I I M M M M P P P P O O O O R R R R T T T T A A A A N N N N T T T T S S S S A A A A F F F F E E E E T T T T Y Y Y Y I I I I N N N N F F F F O O O O R R R R M M M M A A A A T T T T I I I I O O O O N N N N , , , , S S S S A A A A V V V V E E E E T T T T H H H H E E E E S S S S E E E E I I I I N N N N S S S S T T T T R R R R U U U U C C C C T T T T I I I I O O O O N N N N S S S S TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND THIS INSTRUCTIONAL MANUAL.

  • Page 2: Table Of Contents

    HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 2 CONTENTS 1. INTRODUCTION ................5 2. AC and DC CHARGING/RECHARGING ..........8 2.1 Viewing Battery Vol t age Level ............8 2.2 120 Volt AC Charging ..............8 2.3 12-Volt DC Charging ..............9 3. USING JUMP-START POWER STATION AS A JUMP-STARTER ....9 3.1 Jump-starting Instructions ..............10...

  • Page 3: Important Safety Instructions

    HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 3 IMPORTANT SAFETY INSTRUCTIONS Warning statements identify conditions or practices that may result in WARNING: personal injury or loss of life. W W W W A A A A R R R R N N N N I I I I N N N N G G G G : : : : R R R R I I I I S S S S K K K K O O O O F F F F E E E E X X X X P P P P L L L L O O O O S S S S I I I I V V V V E E E E G G G G A A A A S S S S E E E E S S S S Working in the vicinity of a lead acid battery is dangerous.
  • Page 4 HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 4 If battery acid comes in contact with skin, rinse immediately S S S S K K K K I I I I N N N N : FIRST AID: wi t h water, then wash thoroughly with soap and water. If redness, pain, or irritation occurs, seek immediate medical attention.

  • Page 5: Introduction

    1. INTRODUCTION Congratul a ti o ns on sel e cti n g the HUSKY® PORTABLE POWER SYSTEM. Thi s compact Power System i s uni q ue i n the amount of energy i t can suppl y for i t s si z e. The i n ternal battery i s a hi g h densi t y seal e d, l e ad-aci d battery that stores and del i v ers energy comparabl e to l a rger j u mp-starters.
  • Page 6 HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 6 FEATURES: • Powers 110/120 Volt AC appliances • Powers 12 Volt DC appliances • Jump-starts vehicle engines • Provides portable lighting • Built-in inflator • Built-in 400 watt inverter • Includes non-spillable, maintenance-free, heavy-duty, seal e d battery •...
  • Page 7 HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 7 FIGURE - 1A FRONT VIEW FIGURE - 1B REAR VIEW 1 Built-in AC Charger Adapter 1 Unit front panel 2 Rubber handle 2 Rear panel cover latch 3 Rear panel cover...

  • Page 8: Ac And Dc Charging/Recharging

    Use a common household extension cord for charging ( cord not supplied ). For maximum battery l i f e, we recommend the HUSKY® POWER SYSTEM be kept fully charged at all times. If the battery is allowed to remain in a discharged state, battery life will be shortened.

  • Page 9: 12-Volt Dc Charging

    HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 9 The DC recharging method will NOT recharge the unit as effecti v el y as recharging from 120 Vol t AC. The 12 Volt DC recharging procedure is recommended only when it is necessary since continued use of the 12 Volt DC recharging procedure may shorten the battery system’s life.

  • Page 10: Jump-Starting Instructions

    This system is NOT designed to be installed as a replacement for a vehicle battery. This HUSKY® PORTABLE POWER SYSTEM is equipped with a manual ON/OFF switch. Once the connections are properly made, turn the switch ON and you are ready to jump-start the vehicle.

  • Page 11: Volt Power Supply

    HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 11 8. After vehicle starts, turn the safety power swi t ch to off, remove clamps (disconnect the frame or engine clamp first), followed by the battery cable and replace them on the built-in clamp tabs. Squeeze the handles and slide the clamp into position and release your grip.

  • Page 12: Emergency Area Light

    N N N N O O O O T T T T E E E E : The Husky HSK 037 inflator has an “overheat” automatic shutdown feature. Around 15 min. of continuous use, the unit shuts down automatically and restarts approx.

  • Page 13: Inflating Other Articles Without A Val V E Stem

    HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 13 5. When desired pressure is reached, slide the inflator switch to OFF; open thumb latch and remove connector from valve stem. 6. Store inflator hose and tire fitting in storage compartment.

  • Page 14: Ac Power Supply

    The AC Power Supply is designed for maintaining today's modern life while traveling in vans, RVs, automobiles, trucks, or vehicle that has a 12 Volt battery power supply and a means to recharge those batteries. The HUSKY® PORTABLE POWER SYSTEM comes with: 1.

  • Page 15: Powering Externally

    HSK037 ENG MANUAL 090105 9/1/05 5:48 PM Page 15 7 7 7 7 ..2 2 2 2 A A A A C C C C P P P P O O O O W W W W E E E E R R R R S S S S U U U U P P P P P P P P L L L L Y Y Y Y O O O O P P P P E E E E R R R R A A A A T T T T I I I I O O O O N N N N 1.

  • Page 16: Volt Specifications

    9. 12 VOLT DC SPECIFICATIONS Model ..... .HSK037 Portabl e Power System Battery ... . .12 volt DC rechargeable, maintenance-free Internal battery type .
  • Page 17 If such a product i s returned more than 30 days but l e ss than three years after the purchase date, Husky Power Products wi l l repai r the uni t or, at i t s opti o n, repl a ce i t free of charge.
