Midas DL152 Specifications

I/O Interfaces
24-Output Stagebox with
Dual-Redundant AES50 Networking
24 Active-Balanced Low Impedance
Line-level Outputs
Selectable 96 kHz or 48 kHz sample
rate operation
Dual AES50 Neutrik etherCON*
network ports with LED
status indicators
All settings programmable from
front panel controls or console
Remote operation up to 100 m
via CAT5 cable
PSU status indicator LEDs and
confi guration LCD display on
front panel
Rugged 2U rackmount chassis for
durability in portable applications
Auto-ranging universal switch-mode
power supply
3-Year Warranty Program**
Designed and engineered in England
*All third-party trademarks, including, but not limited to Neutrik and
etherCON are trademarks or registered trademarks of their respective
owners. Their use neither constitutes a claim of the trademark nor affi liation
of the trademark owners with MUSIC Group. Product names are mentioned
solely as a reference for DL152 compatibility, eff ects and/or components.
**For the applicable warranty terms and conditions and additional
information regarding MUSIC Group's Limited Warranty, please see
complete details online at music-group.com/warranty.
The DL152 delivers legendary MIDAS sound quality in a cost eff ective, discrete 2U chassis
that utilises time-tested and proven MIDAS technologies. Equipped with 24 balanced line
level outputs and dual redundant AES50 network ports, the DL152 is the ideal partner to the
PRO1 and PRO2 digital consoles – signifi cantly increasing the network capacity and number
of analogue outputs.
User interface controls and feedback is via an intuitively laid out front panel. The controls
and LED indicators provide ease of use and instant feedback at a glance. All primary
connections use high quality balanced XLR connectors.
Housed in a road-ready, rugged 19" 2U rack-mountable chassis, the DL152 is ideally suited
for storage in standard fl ight cases (not included).
Integration Within The MIDAS Product Range
Styled to match our existing console aesthetic, MIDAS high performance I/O has never
been easier to use - or more cost eff ective.
