Midas DL151 Specifications

I/O Interfaces
24-Input Stagebox with
MIDAS Mic Preamps and
Dual-Redundant AES50 Networking
24 award-winning MIDAS analogue
mic preamps with switchable +48 V
phantom power
Selectable 96 kHz or 48 kHz sample
rate operation
Dual AES50 Neutrik etherCON*
network ports with LED
status indicators
All settings programmable from
front panel controls or console
Remote operation up to 100 m via
CAT5 cable
PSU status indicator LEDs and
confi guration LCD display on
front panel
Rugged 2U rackmount chassis for
durability in portable applications
Auto-ranging universal switch-mode
power supply
3-Year Warranty Program**
Designed and engineered in England
*All third-party trademarks, including, but not limited to Neutrik and
etherCON are trademarks or registered trademarks of their respective
owners. Their use neither constitutes a claim of the trademark nor affi liation
of the trademark owners with MUSIC Group. Product names are mentioned
solely as a reference for DL151 compatibility, eff ects and/or components.
**Warranty details can be found at music-group.com
User interface controls and feedback is via an intuitively laid out front panel. The controls
and LED indicators provide ease of use and instant feedback at a glance. All primary
connections use high quality balanced XLR connectors.
Housed in a road-ready, rugged 19" 2U rack-mountable chassis, the DL151 is ideally suited
for storage in standard fl ight cases (not included).
Integration Within The
MIDAS Product Range
Styled to match our existing console
aesthetic, MIDAS high performance I/O
has never been easier to use - or more
cost eff ective.
The DL151 delivers legendary MIDAS
sound quality in a cost eff ective, discrete
2U chassis that utilises time-tested and
proven MIDAS technologies. Equipped
with 24 channels of MIDAS premium
mic-pre amplifi ers with 2.5 dB gain steps
and dual redundant AES50 networking
ports, the DL151 is the ideal partner
to the PRO 1 / PRO 2 digital consoles –
signifi cantly increasing the network
capacity and number of mic. inputs.
