Home Automation 62A05-1 User Manual

DESCRIPTION

The Model 62A05-1 Hi-Fi Remote Control is used for sending IR signal to a Volume-Source Control (VSC), which in turn, sends the
signal to the Hi-Fi processor. Upon receiving the IR data, the Hi-Fi processor can toggle mute, increment volume, decrement volume,
change source (one IR command for each of the six sources), and toggle power for the current zone.

USING THE REMOTE CONTROL

To use the Hi-Fi Remote Control, point it at the VSC in the desired
zone and press appropriate button(s) as follows:
1) Power: This button turns the zone on and off.
2) Mute: This button turns mute on and off.
3) Source: These buttons select the audio source
to be heard in the zone.
4) Volume Down: This button decreases the volume in the
zone.
5) Volume Up: This button increases the volume
in the zone.
