- Page 1 HOME AUTOMATION, INC Owner's Manual Document Number 20R00-50 Rev. 2.11 January, 2006...
- Page 2 Copyright © 2001-2006 Home Automation, Inc. All Rights Reserved...
-
Page 3: Table Of Contents
INTRODUCTION... 1 Underwriter's Laboratories (UL) Listing ...1 OVERALL DESCRIPTION ... 2 Console Operation ...2 Normal Top-Level Display ...3 Display Menus ...3 Main Menu...4 Error Beeps ...4 Trouble Beeps...4 Confirmation Beep...5 Cancel ...5 Time Out...5 Areas ...5 Omni IIe Maintenance ...5 SECURITY SYSTEM OPERATION ... - Page 4 CONTROL ... 16 Control Commands ...16 About UPB...16 HAI Lighting Control (HLC) Format...17 About Rooms ...17 About Room Controllers...17 Room Controller LED Indicators...17 About House Controllers ...18 About CentraLite ...18 About Lutron RadioRA...18 About ALC...19 ALC Module Types ...19 About X-10 ...19 House Codes ...19 Unit Numbers...20 Scrolling Through Names ...20...
- Page 5 Status...35 Configuring HLC Devices ...35 Configuring HLC Devices using an Omni Console...35 Configuring HLC Devices using an OmniTouch Touchscreen ...36 Setup Mode for HLC Devices...36 Event Log...38 Show Events ...38 Messages...39 Show Message ...39 Log Message...40 Clear Message...40 Say Message ...40 Phone Message ...40 Send Message (Pro-Link) ...40 TELEPHONE CONTROL ...
- Page 6 SETUP... 52 Configuration and Advanced Control Programming (ACP) ...52 Set Up Codes...52 Authority Level...52 AUTHORITY ...52 1 = Master ...52 2 = Manager ...52 3 = User...52 Access Areas...52 Duress Code...53 Set Up Time ...53 Advanced Control Programming (ACP) ...54 1 = Add Programs ...54 2 = Show Programs...54 3 = Delete All Programs ...56...
- Page 7 Set Up Arming ...71 Entry Delay...71 Exit Delay ...71 Audible Exit Delay ...71 Entry/Exit Chime ...71 Perimeter Chime ...71 Enable Quick Arm ...72 Enable Auto Bypass...72 All On For Alarm...72 Beep On Trouble...72 Set up Miscellaneous ...72 High Security Mode...72 Announce Alarms ...72 Enable Freeze Alarm ...73 Flash For Alarm ...73...
-
Page 9: Introduction
INTRODUCTION Thank you for purchasing your new Omni IIe automation system. You are about to enjoy a new feeling of security, comfort, convenience, and control. Omni IIe coordinates lighting, heating and air, security, scenes, and messages based on your lifestyle and schedule. -
Page 10: Overall Description
OVERALL DESCRIPTION Console Operation The console is designed with everything that is necessary for you to program and operate your Omni IIe control and security system. Because we feel that it is very important for you to feel comfortable with the operation of your Omni IIe, we recommend that you start by becoming familiar with your console. -
Page 11: Normal Top-Level Display
6- UP ARROW The Up Arrow key is used to scroll through menus and lists. The Up Arrow is used to scroll back through a list (for example, if you have already used the down arrow to scroll to an item, the Up Arrow will bring you back to a previous item). 7- CONSOLE LED The Console LED is used to indicate whether the security system is currently armed or disarmed. -
Page 12: Main Menu
When using the arrow keys to scroll through lists of areas, buttons, codes, temperature zones, units, or zones, only the named items are displayed. If no text description has been given to an item, it will be skipped over when scrolling through that list. You can still enter any item number to access it directly, and then scroll up and down among the named items. -
Page 13: Confirmation Beep
Confirmation Beep When you have successfully completed a function, such as entering a program or changing a setup item, the console will beep once. Cancel If you are ever unsure and wish to return to the top-level display, press the ' * ' key. You may have to press it more than once, depending on how far into the function (menu) you are. -
Page 14: Security System Operation
SECURITY SYSTEM OPERATION Disarming the Security System and Silencing Alarms Before going any further, you should know how to disarm your security system in the event that the alarm sounds. Turning the system OFF disarms the burglar alarm, resets the fire and emergency alarms, and silences all sirens and sounders. Press the OFF key. -
Page 15: Using Shortcut Keys
2 = NIGHT The NIGHT mode is used when you are asleep and everyone in your household is at home. In the Night mode, your doors, windows, and non-sleeping area (i.e. downstairs) motion detectors are armed. In the Night mode, there is no entry delay. The alarm system sounder will be activated immediately if any door, window, or non-sleeping area (motion detector) is tripped. -
Page 16: Quick Arm
Quick Arm For extra convenience, the Omni IIe can be armed by simply pressing the DAY, NIGHT, or AWAY button twice, eliminating the need to enter the code. To quick arm the system in the Away mode, from the top-level display, press AWAY AWAY The quick arm feature only works if the alarm system is in the Off mode, and if no alarms are sounding. -
Page 17: Goto
#=GOTO To Bypass or Restore a zone in another area, you must first "go to" that area by selecting #=GOTO. AREA: ENTER AREA: At this point you may enter the area number followed by the ' # ' key, or use the down arrow key to scroll to the next area - See Area Arming for additional information. -
Page 18: Fire Alarm Activated
For more information on the digital and voice dialer - See Digital Dialer and Voice Dialer. • The system continues to sound all alarms and flash the flashing light for 1-30 minutes after the alarm is activated. • After a 1-30 minute period, the sounder is turned off, and the alarm system resets itself. The console beeper stays on. If a zone is tripped after a reset, the sounder will again be activated, and the dialer will again dial out. -
Page 19: Police Emergency
Police Emergency When the 1 key and the 3 keys are pressed simultaneously, the Police Emergency alarm is activated. This alarm operates exactly the same as described for Burglar Alarm Activated except: • The console display indicates: "BURGLARY! - POLICE EMERG TRIPPED". •... -
Page 20: Trouble Indications
Trouble Indications The Omni IIe constantly monitors the alarm zones and several internal matters and will alert you if it detects trouble. The particular trouble is indicated on the bottom line of the display and a trouble signal is given by beeping the console beeper continuously, 2 beeps per second. -
Page 21: Manager Code
Manager Code The Manager codes can arm/disarm the security system in assigned areas, during assigned times. The Manager code can access functions that are code protected in High Security mode. Managers may also access the system from an outside telephone line. User Code User codes can only be used to arm and disarm the security system in assigned areas when the time assigned to that code is valid. -
Page 22: Goto Area
If the ' 0 ' (ALL) key had been selected, the display will show: DISARM ALL AREAS ENTER CODE: As the four-digit code is entered, "X" characters are echoed after the "ENTER CODE:" prompt. If the Master code or a valid code is entered, the console will beep one time and Area 2 will be disarmed. Even if Auto Bypass is enabled, the system will not arm another area if any zones in that area are not ready. -
Page 23: Testing Your System
Testing Your System HAI recommends testing your system on a weekly basis to ensure that you are fully protected. Notify your Central Station that you intend to test the system. To test the siren, press the 1 and 3 keys simultaneously. Press OFF and enter your Code to cancel the alarm and silence the siren. -
Page 24: Control
CONTROL Control Commands The control features of the Omni IIe make it easy and convenient to control almost any light or appliance from the console or over the telephone. You may also have your heating and air conditioning (HVAC) under control of the system, which will allow you to save energy dollars by setting the temperature appropriately when you are home, asleep, or away. -
Page 25: Hai Lighting Control (Hlc) Format
When set to UPB, the Omni IIe controller can: Send commands (on, off, bright, dim and level) to individual switches and modules Receive commands and status from individual switches and modules Send commands to keypad controllers to change scenes and control LED backlight behind the keys Receive commands when buttons are pressed on keypad controllers to activate controller macros Send Link commands to switches, modules, and keypad controllers to activate scenes Receive Link commands when a button is pressed on a switch or on a keypad controller to activate controller macros... -
Page 26: About House Controllers
indicator is turned off. Likewise, if the “On” indicator or one of the scene indicators is illuminated, and then all of the lighting loads are turned off at HAI UPB™ Wall Switches and/or Dimmers, the “Off” indicator will illuminate and any others are turned off. -
Page 27: About Alc
When set to RadioRA, the Omni IIe controller can: Send commands (on, off, and level) to individual Switches and Dimmers Receive status (on and off) from individual Switches and Dimmers Receive commands when buttons are pressed on Master Controls Execute Phantom Button commands About ALC ALC is intended for installation in homes, which have been pre-wired for installation of ALC system products. -
Page 28: Unit Numbers
Unit Numbers Omni IIe systems have 128 total Unit Numbers. They consist of HLC, UPB, CentraLite, RadioRA, ALC, Compose, and X-10 module unit numbers, hardwire voltage output unit numbers, and internal flag unit numbers as follows: Omni IIe Unit Numbers Module / Output Unit Numbers HLC Room 1 and 2, UPB Unit ID 1-16, CentraLite loads 1-16, RadioRA Lighting Zones and 1 - 16... -
Page 29: Configuring Lighting Scenes In An Hlc Room
Configuring Lighting Scenes in an HLC Room Lighting scenes are created by configuring light levels for HLC lighting devices in a room. Each HLC device in a room can store up to four different preset lighting scenes (Scenes A-D) and one “On” Scene (preset lighting levels for each device when the room is turned on). -
Page 30: Controlling Radiora Units
Entry Lights 0=OFF 1=ON 2=DIM 3=BRT Entry Lights 4=LVL 5=RMP 9=TIM #=STA Press 0 (OFF) to turn the selected unit off. Press 1 (ON) to turn the selected unit on. 2 (DIM) does not affect CentraLite units. 3 (BRT) does not affect CentraLite units. Press 4 (LVL) to set the desired lighting level of the selected unit (0%-100%). -
Page 31: Ramp Command (Alc)
Press 0 (OFF) to turn the selected unit off. Press 1 (ON) to turn the selected unit on. Press 2 (DIM) to dim the selected unit (1-9 steps, each step is 10% from its current level). Press 3 (BRT) to brighten the selected unit (1-9 steps, each step is 10% from its current level). Press 4 (LVL) to set the desired lighting level of the selected unit (0%-100%). -
Page 32: Scene Command (Compose)
Scene Command (Compose) If Compose lighting switches are part of your installation, the Scene (SCN) command is used to set a group of lights to predefined lighting levels. There is an Off command, an On command, and 12 lighting scenes for each group of Compose lighting switches. SCENE: 0=OFF Enter 0, followed by the ' # ' key, to turn the lights that are part of the selected group off. -
Page 33: Controlling Outputs
When a counter is decremented to zero, the "When Unit Off" macro is executed. A counter will not decrement below zero. The counter will, however, roll over from 255 to 0 when incremented. The "When Unit Off" macro will be executed when the counter rolls over. -
Page 34: All Lights On
0=OFF 1=ON 2=SCN 3=LINK 4=PHANTOM 5=CENLIT All Lights On At the ALL prompt, press the 1 (LIGHTS ON) key. The console will beep, and a command will be sent that turns on all specified X-10 and ALC units and HLC Rooms. X-10 Appliance Modules do not respond when the All Lights On command is sent. All House Codes (1-4), by factory default, respond to the All-On command. -
Page 35: Scene Commands
Scene Commands Scene Commands are used to Set Scenes, issue a Scene On command, and issue a Scene Off command. To issue Scene Commands, press the 2 (SCENE) key. You are prompted to enter a Scene number. ENTER SCENE: 1-64 Enter the Scene number (1-64) followed be the ' # ' key. -
Page 36: Activating And Deactivating Links
Activating and Deactivating Links A special UPB command called “Link On” (activate) is used to command all of the devices that have the same Link to go to their preset light levels at their preset fade rates. For instance, in our “All On” and “All Off” example, when “Link 50 On” is transmitted by Omni IIe, each UPB Wall Switch with Link 50 will go to 100% to achieve the “All On”... -
Page 37: Buttons
Enter the CentraLite Scene number (1-255) followed be the ' # ' key. CENLIT SCENE 1 0=OFF 1=ON When a CentraLite Scene is turned on, all of the devices that are pre-programmed for that scene will go to their preset light levels. When a CentraLite Scene is turned off, all of the devices that are pre-programmed for that scene will turn off. -
Page 38: Hai Rc-Series Thermostats
HAI RC-Series Thermostats The following control actions are allowed for HAI Communicating Thermostats: • Set heating setpoints • Set cooling setpoints • Set system mode (Off / Heat / Cool / Auto) • Set fan (On / Auto) • Turn hold On and Off NOTE: Not all actions are applicable to every type of thermostat. -
Page 39: Programmable Energy Saver Modules (Pesms)
Upstairs FAN 0=AUTO Thermostats may be switched between hold mode and the normal run mode. While in hold mode, the thermostat does not respond to scheduled temperature changes but instead maintains the temperature at its current setting. The thermostat will then return to its scheduled operation setting once hold mode is removed. - Page 40 The following control actions are allowed on PESMs: • Turn Energy Saver On and Off • Turn Energy Saver On and Off for a specified time • Set heating setpoint • Set cooling setpoint You can turn the energy saver on, off, use a timed on/off, and change the Heat and Cool temperatures from the console or by telephone.
-
Page 41: Important Notes
0=OFF Downstairs 3=COOL ENTER TIME MINUTES (1-99) Downstairs 0=OFF The current status of a temperature zone may be displayed by selecting ' # ' (STAT) key from the main temperature menu. The status display differs depending on the temperature zone type. When you are finished, press the ' * ' key twice to return to the top-level display. -
Page 42: Temperature Control Of Appliances
For negative temperatures (-1 to -40 Celsius temperature may also be specified in 0.5 degree steps if three numeric digits are entered. The third digit adds a .5 to the first two digits if it is any- thing other than zero. Enter a leading zero if necessary. Temperature Control of Appliances You can control appliances (such as a ceiling fan) using Advanced Control Programming (ACP) of the Omni IIe. -
Page 43: Status
Status The Status function is used to display the status of various items in the system. To enter the status menu, from the top-level display or the main menu, press the 6 (STATUS) key on the console keypad. STATUS 1=CTRL 4=TEST 1 = CTRL (CONTROL UNITS) The Control Status menu allows you to view and scroll through the status of each control unit and to configure HLC and UPB... -
Page 44: Configuring Hlc Devices Using An Omnitouch Touchscreen
Press 1 (CTRL) to view the current status of each unit and to configure the HLC device that is assigned for each unit. The console will display: Porch Light STATUS You may enter a unit number to display the selected unit, or simply press the down arrow key to scroll through the list of named units. - Page 45 The Zone Status menu allows you to view and scroll through the status of each zone input. To enter the Zone menu, from the Status menu, press the 2 (ZONE) key on the console keypad. The system will display: Front Door ZONE 1 You may enter a zone number to start displaying the status with zone, or simply press the down arrow key to start with the first zone.
-
Page 46: Event Log
The next series of displays shows the current analog reading for each security zone input. The displays show the readings for zones 1-48. 1=147 4=146 THROUGH 43=148 46=145 Normal readings for zones are between 137 - 157 when secure. If Zones 1-4 are configured as Fire or Gas zone, normal readings are between 26 - 43 when secure. -
Page 47: Messages
To view your event log, from the top-level display or from the main menu, press the 7 key, then enter your code. The arrow keys may be used to scroll through the event log, starting with the most recent event. Each event log entry displays the time and date on the top line and a description of the event on the bottom line: 7:15 PM USER NAME... -
Page 48: Log Message
You may enter the message number followed by the ' # ' key to display that message, or simply press the down arrow key to scroll through a list of messages. Press the ' # ' key to display the selected message: Thu Oct 04, 01 TRASH NIGHT When the message is displayed, the console will beep 4 times and the console LED will flash continuously. - Page 49 The built-in serial ports (J1-J3) on the controller are assigned to Serial Port 1 - Serial Port 3, respectively. Serial port 4 is a Serial Interface Module connected to the Expansion port on the controller. Next, select the message to be sent. You may enter the message number followed by the ' # ' key to send that message, or simply press the down arrow key to scroll through a list of messages.
-
Page 50: Telephone Control
TELEPHONE CONTROL Telephone Interface Your Omni IIe is equipped with a built-in telephone response feature that allows you to control and access the status of your system from any Touch-Tone phone. The Omni IIe actually talks to you using a digital recording of an actual human voice, so the sound is incredibly life like. You send commands to the Omni IIe using the keys of your Touch-Tone telephone. -
Page 51: Phone Access Denied - Remote Lockout
Phone Access Denied - Remote Lockout The Omni IIe has a remote lockout feature to discourage youngsters (and adults who act that way) from trying to access your system. If four invalid codes are entered, the system will hang up and a one-hour lockout period will begin. During the lockout period, the Omni IIe will not answer a call after any number of rings, which should discourage the caller. -
Page 52: Control
1 - Control Press 1 from the MAIN MENU to get to the CONTROL menu. If voice descriptions have been programmed, after a three-second delay, the system will begin reading from the list of units (Omni IIe will say the unit number then its description). The Omni IIe will read three units, then say, "PRESS POUND TO CONTINUE."... -
Page 53: Status
Press the temperature zone you wish to control, then press #. Press the ' 0 ' key to select all HAI Thermostats. This is a simple way to broadcast the new Heat or Cool setting or change the system mode, fan mode, or hold mode of all HAI thermostats in your system. When an HAI Communicating Thermostat is entered: "THERMOSTAT 1 - THERMOSTAT 1 - TEMPERATURE IS (TEMP)."... -
Page 54: Phone
8 - Phone This command allows you to record and verify the address. If an optional HAI Two-Way Audio Module is being used, this command also allows paging and listening to the premises. Press 8 from the MAIN MENU to get to the PHONE menu. "PHONE - PLEASE CHOOSE: [3 INTERIOR] 8 PLAY ADDRESS, 9 RECORD ADDRESS *: CANCEL."... -
Page 55: Emergency Dial-Out
Emergency Dial-Out Emergency dial out consists of two distinct parts: the "digital dialer" and the "voice dialer." Digital Dialer The digital dialer (also called a "digital communicator") reports alarm events to a central station monitoring center. The digital dialer sends a digitally coded message to the central station's receiver and computer. The computer in the central station presents your name, address, and other information to a human operator who notifies the appropriate authorities. -
Page 56: What The Omni Iie Voice Dialer Does
What the Omni IIe Voice Dialer Does When an alarm is activated, the Omni IIe will wait the Dial Out Delay. If your system is monitored by a central station, it will be notified first. Then the voice dialer will dial out to the numbers as described above. If the alarm is turned off at the console while a voice dial-out is in progress, the dial-out will be canceled immediately and the voice dialer will hang up. -
Page 57: Pc Access
PC Access Omni IIe is capable of communicating with an IBM compatible personal computer (PC). The PC can be local (in-house) or remote. The PC must be equipped with a modem or serial port and running PC Access software. The Omni IIe has a built-in modem and can be accessed over the telephone or over a direct serial connection (RS-232/RS-485 through either the built-in or optional serial interface module). -
Page 58: Local Network
To connect to an Omni IIe controller on a local network using HAI PC Access, under Configure >> Network enter the controller’s IP address: (i.e. 192.168.0.101) Dynamic DNS If the controller is connected to the Internet via a dynamic IP address, to locate and communicate with the controller from remote locations over the Internet using HAI PC Access, you must subscribe to a Dynamic DNS (Domain Name Service). -
Page 59: Local / Wide Area Network
To connect to an Omni IIe controller on a local network using HAI PC Access, under Configure >> Network enter the controller’s IP address: (i.e. 10.0.0.230) Local / Wide Area Network Page 51 To connect to an Omni IIe controller from the Internet using HAI PC Access, under Configure >>... -
Page 60: Setup
SETUP Configuration and Advanced Control Programming (ACP) The Setup menu is used to configure operating parameters, program your system to do its automated control and security functions using ACP, and give text and voice descriptions to all of your zones, units, buttons, codes, temperatures, and messages. To enter the Setup menu, from the top-level display or from the main menu, press the 8 (SETUP) key on the console keypad. -
Page 61: Duress Code
You can specify the access (on/off) times for the code; this is, the time periods during which the code is valid. CODE 2 ON TIME: 8:00 AM MTWTF-- #=CHNG CODE 2 OFF TIME 5:00 PM MTWTF-- #=CHNG The times and days are changed by pressing the ' # ' key. Choose the 1 (TIME) key to change the On or Off times. You will be prompted to enter the new time. -
Page 62: Advanced Control Programming (Acp)
Advanced Control Programming (ACP) Your Omni IIe can be programmed to do automated control and security functions on a time schedule or in response to an event occurring in the system. You may program the following items: • Unit Numbers: On, Off, On for time, Off for time, Dim, Brighten, Dim for time, Brighten for time, Level, and Scene •... - Page 63 Menu 1 - Programs for a particular control unit number Menu 2 - All Security related programs Menu 3 - Programs for a particular macro button Menu 4 - Programs for All On/Off functions Menu 5 - Programs for a particular Temperature zone Menu # - Displays every program Selecting the 1 (CTRL) or 5 (TEMP) key will prompt you to specify the desired unit or temperature zone.
-
Page 64: Delete All Programs
The arrow keys are used to scroll through the programs. Pressing the ' # ' key while a particular program is displayed will allow that program to be edited or deleted. The display shows: SHOW PROGRAM 1=EDIT Press the 1 (EDIT) key to edit the selected program. The Edit Program menu is displayed which allows the various parts of the program to be changed - See Edit Program. -
Page 65: Edit Programs When
Edit Programs When Selecting the 1 (WHEN) key, from the Edit Program menu, allows the time or button/event that activates the program to be changed. The display shows: EDIT WHEN 1=TIMED 2=BUTTON Times Programs Selecting 1 (TIMED) sets the program to be activated at a specific time of day. You are prompted to enter the time and date or days of week. -
Page 66: Button And Event Programs
Button and Event Programs Selecting 2 (BUTTON), from the "Edit When" menu, sets up a program to be activated when a macro button is executed or an event occurs. The user is prompted to specify the button/event that activates the program: BUTTON: ENTER BUTTON A specific macro button may be activated by entering the button number followed by the ' # ' key, or by using the arrow keys to... -
Page 67: Security Mode Event Buttons
Switch Omni IIe UPB 6-Button Keypad On Button Off Button Security Mode Event Buttons Pressing the 2 (SEC) key allows you to select the event button that will be activated when a security mode changes: 0=OFF 3=AWAY After the security mode is selected, an additional menu appears which allows you to further specify the event button. For example, you would like to activate an event button when you arm the system into the 3 (AWAY) mode: WHEN AWAY: 1=DELAY 2=CODE... -
Page 68: Zone Event Buttons
Selecting 3 (AREA) allows you to specify that the event button is activated only when the specified area is armed or disarmed. You will be prompted to enter the area: AREA: ENTER AREA The area number should be entered followed by the ' # ' key, or the arrow keys may be used to scroll through a list of areas. WHEN C1 A1 AWAY: 1=DELAY 2=CODE Zone Event Buttons... -
Page 69: Upb Link Event Buttons
UPB Link Event Buttons When a program is created that uses “When Link On” as the trigger, the program will execute when a “Link Activate”, “Link Goto” (as long as the result of the Goto command is not “0”), or “Link Fade Start” (as long as the result to the Fade command is not “0”) message is received. -
Page 70: Miscellaneous Event Buttons
Finally, you are prompted to specify the command that activates the event button: WHEN X-10 A1: 0=OFF 1=ON 2=SCENE After specifying the X-10 House Code and X-10 Unit Code, select 0 for Off, 1 for On, or 2 for Scene. "Off"... -
Page 71: Switch Press Event Buttons (Centralite)
Pro-Link also has the capability to monitor the serial port for incoming text messages. When a text message is received, Pro-Link searches through all 64 text messages for a matching message. If one is found, the When Message Received event button corresponding to the matching message is activated. -
Page 72: Unit Toggle Command
If the selected unit is not capable of dim and bright commands, only a single menu is shown. Porch Light (Unit Name) 0=OFF 1=ON If the selected unit is UPB, press 6 (LED) to control an LED on a UPB Keypad. On the 6-Button Keypad: LED 1 is behind the “On”... -
Page 73: Program Button Commands
Select (0-6) to arm the system into the desired mode or select the 8 key to Bypass and the 9 key to Restore a security zone. If area arming is being used, the display will then prompt you for the area to be armed: AREA ENTER AREA Enter the area number followed by the ' # ' key, or use the arrow keys to scroll through a list of areas. -
Page 74: Program Message Commands
Program Message Commands Select the 8 (MESSAGE) key to show, log, clear, say, phone, or send a message. Specify the desired command - See Message. MESSAGE 1=SHOW 4=SAY The 1 (SHOW) key allows you to display the selected text message(s) on the console's top-level display. This can be a helpful reminder of special events and occasions. -
Page 75: Program Security Mode Conditions
The unit is displayed and the display prompts for the state of the unit: IF Porch Light: 0=OFF 1=ON Program Security Mode Conditions Press the 2 (SEC) key to specify that the program should only execute if the security system is armed in a particular mode. Select the security mode from the following menu: 0=OFF 1=DAY 2=NIT 3=AWY 4=VAC 5=DYI 6=NTD... - Page 76 Choose "NONE" when editing a program and choose not to conditionalize the program. SELECT CONDITION: NEVER Choose "NEVER" if you wish to temporarily deactivate a program without deleting it. Other conditions include: • IF LIGHT • IF DARK • IF ENERGY LO •...
-
Page 77: Set Up Dial
Set Up Dial The Set Up Dial menu is used to configure all of the telephone related items for the Omni IIe. To enter the Set Up Dial menu, from the Setup menu, press the 4 (DIAL) key. Use the arrows to scroll through the items. For each item, the top line displays a description of the item and its current setting. -
Page 78: Dial Out Number 1
Dial Out Number 1 Dial Out Number 1 is one of the 8 numbers that are stored in the system. In the event of an alarm, these numbers are dialed in the order that is set up in the Dial Out Order for the particular type of alarm. Dial out numbers 1 - 8 have On and Off times and days, so that no time is wasted calling you at the office at night or on a Sunday if the alarm is activated. -
Page 79: Set Up Arming
Set Up Arming To configure different arming and disarming options, from the Setup menu, press the 5 (ARM) key. Entry Delay The Entry Delay is the time, in seconds, that you have to turn off the alarm after entering your home. The Entry Delay only applies to the entry/exit zone (i.e. -
Page 80: Enable Quick Arm
Enable Quick Arm The Quick Arm feature allows the security system to be armed by pressing the desired mode key twice instead of having to enter your code. The default setting for Enable Quick Arm is No. Enable Auto Bypass The Auto-Bypass feature allows the system to automatically bypass an open zone when the system is armed, rather than setting off the alarm. -
Page 81: Enable Freeze Alarm
Enable Freeze Alarm If there are one or more Thermostat or PESM in a system, they can also be used to detect a freeze condition - See Freeze Alarm. The default for Enabled Freeze Alarm is No. Flash For Alarm You may enter one unit number that will flash on and off continuously when the alarm is activated. -
Page 82: Time Clocks
House Codes 1-4 All On This feature allows you to choose if House Code 1-4 will respond to the “All On” command. Press the 0 key to select No and the 1 key to select Yes. After selecting, press the down-arrow key to change this option for the next House Code. HC 1 ALL ON: 0=NO 1=YES The default setting for HC 1-4 All On is Yes. -
Page 83: Latitude, Longitude, And Time Zone
Latitude, Longitude, and Time Zone The system automatically calculates the time of sunrise and sunset each day. Sunrise/sunset can be specified as the time a scheduling command is executed, as an enable/disable time, or as a darkness condition on a scheduling command or event button. To enable the system to properly calculate sunrise and sunset times, you must enter your latitude, location north or south of the equator, longitude, location east or west of the Prime Meridian, and time zone. -
Page 84: Controller Ip Address
DST START WEEKEND: FIRST SUNDAY DST END MONTH: 1-12 0=DISABLE DST END WEEKEND: LAST SUNDAY Set the value for DST Start and End Months to "0" if Daylight Savings Time does not apply to your region, or to disable this automatic time update feature. -
Page 85: Encryption Key
Encryption Key Encryption and decryption of data between the Omni IIe controller and the connected device is based on the Advanced Encryption Standard (AES) using a 128-bit cryptographic key. A unique encryption key is randomly assigned to each Omni IIe controller at the factory (no records of these keys are kept at the factory). -
Page 86: Set Up Voice
Set Up Voice The Omni IIe can be set up to speak descriptive names such as "FRONT DOOR" for control zones, units, buttons, codes, temperatures, areas, and messages. These names will be spoken over the telephone along with the item number that is normally spoken. -
Page 87: Underwriter's Laboratories Requirements
UNDERWRITER'S LABORATORIES REQUIREMENTS For a complete list of requirements and restrictions when installing the Omni IIe panel in a UL Listed system, refer to the Underwriter's Laboratories Requirements section of the Installation Manual (20I00-50). When used in UL Listed Installations, the following items apply: The "High Security Mode"... -
Page 88: Federal Communication Commission Notice
FEDERAL COMMUNICATION COMMISSION NOTICE: This equipment complies with Part 68 of FCC Rules. On the door, inside of the Omni IIe enclosure, is a label that contains, among other information, the FCC registration number and Ringer Equivalence Number (REN) for this equipment. If requested, provide this information to your telephone company. -
Page 89: Canadian Industry Canada Notice
CANADIAN INDUSTRY CANADA NOTICE Notice: The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Industry Canada does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. -
Page 90: Appendix A - Dial Out Planner
APPENDIX A - DIAL OUT PLANNER Use the following dial-out planner to help you set-up the voice dial-out numbers: Omni IIe Voice Dial-Out Planner DIAL OUT NUMBER 1: __________________________________ AREA: _____________ DIAL OUT 1 ON: TIME: _______________ DAYS: _______________ DIAL OUT 1 OFF: TIME: _______________ DAYS: _______________ DIAL OUT NUMBER 2: __________________________________ AREA: _____________ DIAL OUT 2 ON:... -
Page 91: Instructions To Called Party
Dear ___________________________________________________________________ I have programmed my Omni IIe Home Automation system to call you if my alarm is activated. If it is activated, it will call and say: "Emergency... Emergency... The (burglar or fire) alarm has been activated at the following address:... -
Page 92: Appendix B - Text Description Character Codes
APPENDIX B - TEXT DESCRIPTION CHARACTER CODES CODE CHAR SPACE " & CODE CHAR CODE CHAR < > Page 84 CODE CHAR ¥ × ¯ à ß... -
Page 93: Appendix C - Voice Description Codes
APPENDIX C - VOICE DESCRIPTION CODES CODE DESCRIPTION (ADDRESS MSG) (BEEP) (MEMO MESSAGE) (PAUSE) (SHORT PAUSE) A. M. ABOVE AC POWER ACCESS ACTIVE ADDRESS AFTERNOON ALARM ALERT ALLEY AMPLIFIER ANNIVERSARY ANTIQUE APARTMENT APPLIANCE APPROACHING APRIL AREA ARMED ASLEEP ASSISTANCE ATRIUM ATTIC AUDIO AUGUST... - Page 94 CODE DESCRIPTION EXTERIOR FACTORY FAILURE FALL FAMILY FATHER’S FAULT FEBRUARY FENCE FIFTEEN FIFTY FILE FILTER FIRE FIRST FIVE FLAG FLOOD FLOOR FLOW FORCE FORTY FOUNDATION FOUNTAIN FOUR FOURTEEN FOYER FREEZE FREEZER FRIDAY FROM FRONT FULL FUNCTION FURNACE FUSE GALLERY GAME GARAGE GARDEN GATE...
- Page 95 CODE DESCRIPTION ONLINE ONLY OPEN OPTION OTHER OUTDOOR OUTLET OUTSIDE OVER OVERFLOW OVERHEAD P. M. PANIC PANTRY PARKING PARLOR PARTY PATIO PAUSE PERIMETER PERSONNEL PHONE PHRASE PIER PLACE PLANTS PLAY PLEASE CHOOSE PLUS POINT POLICE POOL PORCH POSITION POUND PRECIOUS PRESS PRESSURE PROGRAM...
- Page 96 CODE DESCRIPTION VACATION VALVE VANITY VAULT VIDEO VISITOR VOLUME WAITING CODE DESCRIPTION WALK WALKWAY WAREHOUSE WARNING WATER WEDNESDAY WELCOME TO OMNI WELCOME WEST Page 88 CODE DESCRIPTION WINDOW WINE WING WINTER WOOD WORK YARD ZONE...
- Page 98 NOTE TO INSTALLER Following installation, this manual shall be left for the homeowner's use. HAI • New Orleans, LA • U S A...
