Pioneer VSX-822-K Specifications

AMPLIFICATION
› › Channels:›5.1
› › Amplification›Type:›Direct›Energy
› › 80›W/ch›(20›Hz›–›20›kHz,›THD›0.08›%›@›8›ohms›FTC)
› › 140›W/ch›(6›ohms›1›kHz›1›%›1ch›Driven)

AUDIO FEATURES

› › Dolby ® ›TrueHD/Dolby›Pro›Logic›IIz/Dolby›Digital›Plus
› › DTS-HD ® ›Master›Audio/DTS-ES/DTS›Neo:6
› › Digital›Core›Engine›with›Texas›Instruments›Aureus™›DSP
› › 192›kHz/24-bit›DAC
› › HDMI›Audio›Return›Channel
› › Pioneer›Auto›MCACC›Room›Calibration
› › Pioneer›Sound›Enhancements
•
Phase›Control
•
Advanced›Sound›Retriever›(2ch)
• Sound Retriever AIR
• Auto›Level›Control›(2ch)
•
Advanced›Surround›(9›+›1›Modes)
•
Front›Stage›Surround›Advance

VIDEO FEATURES

› HDMI 6 in/1 out
› › 3D›Ready›(Blu-ray›Disc ® ,›Broadcast,›and›Games)
› › Deep›Color›(36-bit),›x.v.›Color
› › 1080p›Transferring
* Pandora only available in the U.S.
** Available for free download from the iTunes App Store/Google Play
Bold denotes step-up features from VSX-522-K
VSX-822-K
5.1 Network ready AV Receiver featuring AirPlay
and iPad ® certification, 3D ready HDMI with ARC, and HTC Connect
HOME NETWORK FEATURES
› AirPlay Compatible
› HTC Connect
› DLNA Certified ® (1.5)
› Compatible with Windows 7
› Music File Playback via LAN/USB (WAV, MP3, WMA, AAC, FLAC)
• 192 kHz/24-Bit Audio playback (WAV, FLAC)
› Pandora Internet Radio*
®
› Internet Radio with vTuner
®
CONVENIENCE FEATURES
› iPod Digital Transmission via Front USB Terminal
› › Charges›iPod/iPhone/iPad,›USB›&›Video›Cable›Supplied
› ControlApp** Ready (iOS/Android)
› Bluetooth Ready (optional AS-BT200 adapter required)
› Air Jam App** Ready (iOS/Android) (optional AS-BT200 adapter required)
• Share music and create playlists via Bluetooth connection
› Firmware Update via USB
› Graphic User Interface (GUI) with Album Artwork (HDMI only)
› › Auto›Power›Down
› › AM/FM›Tuner›30›Presets
› › Sleep›Timer
› Preset Remote Control
