- Page 1 Jasmine Sonata EL156-SE Tube Integrated Amplifier Owner’s Manual...
-
Page 2: Safety Precautions
Never place the Jasmine SONATA EL156-SE Tube Integrated Amplifier near heat sources such as radiators, fireplaces, stoves, or other appliances that produce heat. Avoid placing the Jasmine SONATA EL156-SE Tube Integrated Amplifier where it will be subject to direct sunlight or low temperatures. -
Page 3: Table Of Contents
A Brief of Jasmine The Design Philosophy of jasmine Installation Unpacking The Accessory Kit Installing Tubes Choosing a Location for the Jasmine Amplifier Connections Connecting to AC Power Connecting to the Signal Source Connecting to the Speakers Operation Before Power on the Amplifier... -
Page 4: Introduction
Introduction _______________________ All of us at Jasmine would like to offer thanks and congratulations to you for purchasing the Jasmine SONATA EL156-SE Tube Integrated Amplifier. We sincerely believe that your Jasmine SONATA EL156-SE Tube Integrated Amplifier is an intelligent purchase decision that will bring you many years of musical pleasure and satisfaction. -
Page 5: Installation
After carefully unpacking your Jasmine SONATA EL156-SE Tube Integrated Amplifier, inspect for any shipping damage and call your dealer immediately if any is found. Do not plug your Jasmine SONATA EL156-SE Tube Integrated Amplifier into any outlet if you find shipping damage. -
Page 6: Choosing A Location For The Jasmine Amplifier
Choosing a Location for the Jasmine Amplifier The sound quality of all high-performance digital and analog components can be degraded by vibration. Although the Jasmine SONATA EL156-SE Tube Amplifier uses some most advanced noise-reduction circuitry available, it too will benefit from any efforts taken to reduce vibration. -
Page 7: Connections
Connections _______________________ This section provides instructions to connect the Jasmine SONATA EL156-SE Tube Amplifier to the rest of your music system. Below is an illustration of the Jasmine SONATA EL156-SE Tube Amplifier rear panel, showing all inputs and outputs. Right SP... -
Page 8: Connecting To The Signal Source
You can directly connect your CD player, Tuner to the Jasmine SONATA EL156-SE Tube Amplifier. But Turntable, You have to connect your turntable to the Jasmine SONATA EL156-SE Tube Amplifier by a phono stage , except your turntable embedded phono stage inside. -
Page 9: Operation
Operation _______________________ This section describes how to operate the Jasmine SONATA EL156-SE Tube Amplifier. Before Power On the Amplifier To make sure the volume switch is turned to the minimum position before you turn on the power switch ! Please power on your signal source devices before turn on your Jasmine SONATA EL156-SE Tube Amplifier. -
Page 10: How To Adjust The Bias-Voltage
The lifetime of vacuum tube depend on the quality and used hours each day. Usually, one set of tubes can be used for 3 ~ 5 years. After you used Jasmine SONATA EL156-SE for several years and find the sound quality degraded markedly. -
Page 11: Step Two: Power On The Amplifier
Step Two: Power on the amplifier 1. Before power on the Jasmine SONATA EL156-SE, be sure the speaker cables are connected! 2. Carefully turn on the power switch, waiting for 5 minutes till the tubes warmed up. Using a multi-meter, setting to direct voltage 20V... -
Page 12: Step Three: Adjusting Bias-Voltage Of The Tubes
0.85V Repeating the steps above for each power tube. Please keep in mind for that the bias voltage of each tube is best at same level. Congratulation! You just updated your Jasmine Piano SONATA EL156-SE Tube Amplifier! -
Page 13: Warranty
90 day warranty on parts and labor. 7. The customer is responsible for shipping the unit to Jasmine. 8. Jasmine product is only warranted in the country of original sale. -
Page 14: Specifications
110 ~120V / 50~60Hz or 220 ~ 240V/ Voltage Model: 50~60Hz Net Weight: 22Kg Size: 370(W) x 470(D) x 210(H) mm Power Consumption: 150W (static status) @ 2006 Jasmine audio Block B1-5C, Digital Tech. Park, Southern Keji Rd., Shenzhen, GD, China 518057 Subject to change without notice.
